Description
The HPE DL360 Gen10 2SFF SAS/SATA Backplane Kit is a purpose-built storage solution engineered to unlock compact, high-performance storage within the versatile HPE DL360 Gen10 1U server platform. Designed for data-intensive workloads, this backplane kit provides two hot-swappable 2.5-inch SAS/SATA drive bays, delivering efficient I/O paths, streamlined maintenance, and scalable storage for virtualization, databases, and enterprise applications. Built to meet the reliability standards of modern data centers, this kit integrates seamlessly with HPE controllers and the Gen10 ecosystem to maximize throughput, reduce latency, and improve overall system uptime. Whether you’re expanding capacity, optimizing I/O efficiency, or ensuring smooth upgrade paths, the DL360 Gen10 2SFF backplane helps you extract more performance from your 1U server without sacrificing space or manageability.
- The kit provides 2 SFF SAS/SATA drive bays in a compact 1U backplane, enabling powerful, space-efficient storage expansion for HPE DL360 Gen10 servers.
- Hot-swappable drive support and tool-less drive trays allow rapid maintenance and minimal downtime during upgrades or replacements, keeping critical workloads online.
- Optimized signal paths and compatibility with HPE storage controllers deliver reliable performance, lower latency, and predictable throughput for enterprise applications and virtualization environments.
- Designed for high-density data centers, the backplane integrates cleanly with DL360 Gen10 chassis wiring and internal connectors, reducing cabling complexity and enhancing airflow for better cooling efficiency.
- An economical, scalable upgrade option that preserves existing controller investments while enabling future growth through additional SFF SAS/SATA storage whenever needed.
Technical Details of HPE DL360 Gen10 2SFF SAS/SATA Backplane Kit
- Drive bays: 2 SFF (2.5-inch) SAS/SATA backplane for the HPE DL360 Gen10 family
- Interface compatibility: SAS/SATA data pathways designed to work with supported HPE controllers and the Gen10 architecture
- Form factor: 1U rack-mount backplane compatible with HPE DL360 Gen10 servers
- Connectivity: Internal backplane connectors engineered for seamless integration with the chassis and drive trays
- Warranty and support: Manufacturer terms apply; references to enterprise service options and replacement parts are available through HPE channels
How to install HPE DL360 Gen10 2SFF SAS/SATA Backplane Kit
Installing the HPE DL360 Gen10 2SFF SAS/SATA Backplane Kit is a straightforward process that minimizes downtime and preserves existing system reliability. Follow these general steps to upgrade storage capacity and improve drive management within your 1U DL360 Gen10 server:
- Power down the server, unplug all cables, and discharge static electricity before opening the chassis to access the internal components.
- Remove the server cover and identify the drive backplane area and adjacent drive sleds. Ensure you have the correct replacement kit for your Gen10 model.
- Align the backplane kit with the chassis backplane connectors and the drive sled mounting points. Secure the backplane using the appropriate screws or retention mechanisms provided with the kit.
- Connect the SAS/SATA data and power headers from the backplane to the server’s controller and power distribution area, ensuring snug, secure connections to prevent intermittent drive detection issues.
- Reinstall any drive trays or sleds, making sure they seat properly into the hot-swappable bays. Close the chassis, reconnect cables, and power up the system to verify drive detection and operation.
- Enter the system BIOS/UEFI and confirm that the two SFF bays are recognized by the server’s storage controller. Update firmware if necessary to maximize compatibility and performance.
Frequently asked questions
- Q: What does the HPE DL360 Gen10 2SFF SAS/SATA Backplane Kit do? A: It adds two hot-swappable 2.5-inch SAS/SATA drive bays to a DL360 Gen10 server, enabling compact, scalable storage expansion and streamlined drive maintenance within a 1U chassis.
- Q: Is this backplane compatible with all DL360 Gen10 configurations? A: It is designed for the DL360 Gen10 family and works with supported storage controllers and the Gen10 backplane architecture. Check your exact model and controller compatibility before purchase.
- Q: Can drives be hot-swapped with this backplane? A: Yes. The design supports hot-swappable SAS/SATA drives, allowing drive replacement without powering down the server in many deployment scenarios.
- Q: Do I need additional cables or adapters? A: The backplane kit includes the primary backplane components needed for drive connectivity. Depending on your controller and rack setup, you may require standard internal cables or connectors supplied by HPE or your integrator.
- Q: How do I know if I should upgrade to this backplane? A: If you need to expand storage capacity in a DL360 Gen10 system, improve drive maintenance efficiency with hot-swappable bays, or align with a preferred storage controller strategy for virtualization or database workloads, this backplane kit offers a streamlined upgrade path.
- Q: Where can I find firmware and compatibility information? A: Firmware and compatibility details are available through HPE support portals and your authorized HPE reseller. Always verify the latest firmware versions for the backplane and compatible controllers.
