HPE DL38X Gen10 x16/x16 Riser Kit

HPESKU: 4960355

Price:
Sale price$161.14

Description

HPE DL38X Gen10 x16/x16 Riser Kit

The HPE DL38X Gen10 x16/x16 Riser Kit is a purpose-built expansion solution designed to maximize I/O density and bandwidth within the HPE DL38X Gen10 server chassis. With two full-height, full-length PCI Express x16 slots, this riser enables rapid expansion for graphics accelerators, high-speed storage controllers, networking adapters, and other PCIe-based add-in cards. Engineered to meet data-center reliability standards, it preserves chassis airflow and system integrity while delivering robust signal integrity and dependable performance in demanding enterprise environments. Whether you’re upgrading for AI workloads, virtualization, data analytics, or GPU-accelerated processing, this riser kit provides a streamlined path to higher I/O capacity without requiring major motherboard changes or complex cabling. Built to align with HPE’s Gen10 architecture, the riser kit integrates smoothly with your server’s firmware, management tools, and service ecosystem, helping you sustain operations with minimal downtime and predictable firmware compatibility.

  • Dual PCIe x16 expansion - Supports two PCI Express x16 cards, enabling high-bandwidth GPUs, accelerator cards, NVMe adapters, or other PCIe-based expansion devices to accelerate compute, storage, and I/O workloads.
  • Full-height, full-length design - Specifically engineered for the DL38X Gen10 chassis to maximize compatibility with a wide range of PCIe add-ins while preserving internal clearance and airflow patterns.
  • Enterprise-grade reliability - Built with a rigid frame and Shielding to minimize EMI and signal loss, engineered for steady operation in data centers with rigorous uptime requirements.
  • Efficient space and airflow optimization - The compact riser layout maintains clean cable routing and optimized airflow, reducing turbulence and helping maintain consistent temperatures across the server interior.
  • Gen10-focused compatibility - Tested for integration with HPE Gen10 server firmware, management tools, and OS drivers, ensuring a cohesive experience within the HPE service ecosystem.

Technical Details of HPE DL38X Gen10 x16/x16 Riser Kit

  • Riser type: PCIe x16/x16 dual-riser
  • Slots: 2 x PCI Express x16
  • Form factor: Full-height, Full-length
  • Designed for: HPE DL38X Gen10 servers
  • Airflow considerations: Designed to preserve chassis airflow with minimized obstruction
  • Installation considerations: Mounts into the dedicated riser backplane slot within the DL38X Gen10 chassis
  • UPC/SKU: Not provided

How to install HPE DL38X Gen10 x16/x16 Riser Kit

  • Power down the server, unplug all power cords, and ground yourself to prevent static electricity from damaging components.
  • Remove the server access panels or chassis covers as required to expose the riser backplane area and the dedicated PCIe riser slot.
  • If an existing riser or blanking plate is present, carefully remove it following vendor guidance to reveal the DL38X Gen10 riser connector.
  • Align the HPE DL38X Gen10 x16/x16 Riser Kit with the backplane slot, ensuring the connectors line up with the PCIe backplane interface. Press firmly until seated and secure with the provided mounting hardware.
  • Install PCIe expansion cards into the riser slots as needed, then route any required power or data cables. Verify that all cards are fully seated and that airflow is unobstructed before reassembling the chassis.

Frequently asked questions

  • Q: Is this riser kit compatible with all DL38X Gen10 configurations?

    A: This kit is designed for HPE DL38X Gen10 servers and provides two PCIe x16 expansion slots. For exact compatibility with your chassis revision and firmware, consult your server’s documentation or HPE support.

  • Q: How many PCIe devices can I install with this riser?

    A: The riser supports two PCI Express x16 cards, allowing you to add two high-bandwidth devices such as GPUs or fast storage controllers.

  • Q: Do I need to update firmware when installing the riser?

    A: It’s recommended to ensure your server firmware and OS drivers are up to date to maximize compatibility and performance with new PCIe hardware.

  • Q: Will installation affect server cooling?

    A: The riser kit is designed to maintain airflow within standard DL38X Gen10 configurations. Ensure proper airflow clearance around added cards and confirm that fans and vents are unobstructed after installation.

  • Q: Does this kit require removing or modifying the motherboard?

    A: No major motherboard removal is required; the riser attaches to the designated backplane slot. Follow the server’s service guide and power-down procedures for safe installation.
