HPE DL560 Gen10 2-Port 4 NVMe Slimline Tertiary Riser Kit

HPESKU: 4960561

Price:
Sale price$719.58

Description

HPE DL560 Gen10 2-Port 4 NVMe Slimline Tertiary Riser Kit

Unlock high-density NVMe storage for your HPE DL560 Gen10 with the HPE DL560 Gen10 2-Port 4 NVMe Slimline Tertiary Riser Kit. This specialized riser kit is engineered to maximize NVMe drive density in the DL560 Gen10 chassis, delivering the low latency and exceptional throughput that modern data workloads demand. By providing two dedicated ports and a slimline tertiary configuration, this kit enables four NVMe drives to be integrated into the DL560 Gen10’s storage architecture without compromising airflow or cabling complexity. It’s an ideal upgrade for data centers, enterprise workloads, and virtualization environments where storage performance and space efficiency are critical. Built to HP’s exacting standards, the kit ensures compatibility with the server’s backplane, power delivery, and management features, helping you achieve consistent performance with minimal integration effort. Whether you’re accelerating databases, analytics, or high-IOPS applications, this riser kit is designed to help you squeeze more performance from your existing DL560 Gen10 platform.

  • Dense NVMe expansion designed specifically for the HPE DL560 Gen10 family, offering two ports that support four NVMe drives in a slimline tertiary configuration for maximum storage density in a compact footprint.
  • Seamless integration with the DL560 Gen10 backplane and chassis, preserving the server’s airflow, thermal management, and overall reliability while enabling high-throughput NVMe access for data-intensive workloads.
  • Enterprise-grade performance benefits, including low latency and high IOPS, which accelerate demanding applications such as databases, virtualization, and real-time analytics without requiring a complete system overhaul.
  • Robust build quality and compatibility backed by HPE engineering, ensuring reliable operation within standard DL560 Gen10 configurations and providing confidence for data center deployment and serviceability.
  • Simple installation and maintenance workflow integrated into existing server maintenance routines, with clearly defined connector alignment and secure mounting to minimize downtime during deployment and future upgrades.

Technical Details of HPE DL560 Gen10 2-Port 4 NVMe Slimline Tertiary Riser Kit

  • Get this information from the "specifications" section of the product from https://ec.synnex.com/ using product "UPC" or "SKU" as reference

how to install HPE DL560 Gen10 2-Port 4 NVMe Slimline Tertiary Riser Kit

Installing the HPE DL560 Gen10 2-Port 4 NVMe Slimline Tertiary Riser Kit is a straightforward upgrade path designed to minimize downtime and maximize storage performance. Follow these steps carefully to ensure proper fit, alignment, and operation within your DL560 Gen10 server.

  • Preparation: Power down the server completely, unplug all power cords, and ground yourself to prevent static discharge. Remove the server from its rack if required and open the chassis according to your data center procedures. Have the 2-port 4 NVMe Slimline Tertiary Riser Kit and any required screws or mounting hardware ready.
  • Access the tertiary riser bay: Locate the tertiary riser slot area in the DL560 Gen10 configuration. This is typically positioned in the rear of the server where expansion risers connect to the backplane. Ensure you have unobstructed access for installation and airflow is not impeded by any cables or tools.
  • Remove existing components (if applicable): If a previous riser or backplane module occupies the same slot, carefully detach it following your server’s service guidelines. Retain any necessary connectors for reuse with the new riser kit, and keep screws organized for reassembly.
  • Install the riser kit: Align the HPE DL560 Gen10 2-Port 4 NVMe Slimline Tertiary Riser Kit with the riser slot, ensuring that connectors mate cleanly with the backplane and motherboard interfaces. Gently press the module into place until fully seated, then secure it with the appropriate screws or fasteners provided with the kit.
  • Connect NVMe drives or backplane interfaces: Attach the NVMe drive interfaces or backplane cables to the riser kit as required by your DL560 Gen10 configuration. Ensure connectors are fully seated and routed to avoid interference with fans or other components. Maintain proper cable management for airflow optimization.
  • Reassemble and power on: Replace any covers or panels, slide the server back into the rack, reconnect power, and boot the system. Enter the system BIOS or firmware management interface to verify that the new riser kit is recognized and that the four NVMe drive paths appear as expected.
  • Firmware and validation: Check for the latest firmware updates for the riser kit and related NVMe components. Perform a storage initialization if required, configure drive visibility in the OS, and run baseline storage tests to validate performance and stability.
  • Operational verification: Within the operating system, confirm NVMe drive discovery, hot-plug compatibility if supported by your environment, and ensure that monitoring tools report healthy SMART data and expected performance metrics. Document the upgrade for future maintenance records.

Frequently asked questions

  • Q: What does the HPE DL560 Gen10 2-Port 4 NVMe Slimline Tertiary Riser Kit do? A: It expands NVMe drive support within the HPE DL560 Gen10 server by providing two PCIe-based NVMe ports and enabling four NVMe drives in a slimline tertiary configuration, increasing storage density and performance for data-intensive workloads.
  • Q: Which systems are compatible with this riser kit? A: This kit is designed specifically for the HPE ProLiant DL560 Gen10 server family and is intended to integrate with the server’s backplane and chassis. Always verify compatibility with your exact DL560 Gen10 model and firmware version before purchasing.
  • Q: Can I install this riser kit without powering down the server? A: Installation generally requires powering down and unplugging the server to ensure safe handling and proper connector seating. Refer to your maintenance procedures and follow best practices for server downtime.
  • Q: Does this kit affect airflow or thermal management? A: The kit is designed to fit within the DL560 Gen10 chassis without obstructing airflow when properly installed, helping maintain thermal performance while increasing storage density. Ensure cable management leaves sufficient space for fans and air pathways.
  • Q: Do I need to update firmware after installing the riser kit? A: It is recommended to check for and apply any available firmware updates for the riser kit and related NVMe components to ensure compatibility, performance, and reliability with your OS and hypervisor environment.
