HPE ProLiant DL360 Gen10 Plus 2SFF SAS/SATA 12G BC Drive Cage Kit

Unlock scalable, high-performance storage for your HPE ProLiant DL360 Gen10 Plus with the 2SFF SAS/SATA 12G BC Drive Cage Kit. Designed to maximize density in a compact 1U rack environment, this drive cage kit delivers two hot-swappable 2.5-inch (SFF) drive bays backed by a 12 Gbps SAS/SATA backplane. Built to meet the demanding needs of virtualization, databases, and mission-critical workloads, it combines robust construction, seamless integration, and easy maintenance, enabling you to expand capacity and accelerate data access without downtime. Whether you’re upgrading an existing DL360 Gen10 Plus or deploying new storage for a lean data center, this cage kit provides a reliable, plug-and-play path to higher IOPS, better throughput, and simplified drive management.

• Two hot-swappable 2.5-inch SFF drive bays supported by a 12G SAS/SATA backplane (12G BC), delivering rapid data transfer and flexible storage expansion for DL360 Gen10 Plus workloads. This configuration is ideal for environments that prioritize compact rack density and fast drive swaps during maintenance windows.
• Optimized for HPE ProLiant DL360 Gen10 Plus servers, ensuring seamless compatibility, consistent performance, and a clean integration with HP’s management ecosystem. The kit preserves server reliability while enabling straightforward capacity growth as your data needs evolve.
• Tool-free, front-access design with a robust cage and latch system that minimizes downtime during drive installation or replacement. The combined cage-backplane assembly is engineered for dependable operation in busy data-center racks and reduces the risk of drive misalignment or connection issues.
• Durable construction tailored for enterprise use, featuring a sturdy metal cage, precise mounting points, and a finish designed to withstand daily rack activity, vibration, and thermal variations typical of data-center environments.
• Comes with all necessary hardware and installation components to simplify deployment, including mounting screws and hardware that align with standard 1U front-drive cages. This makes it easier to retrofit existing DL360 Gen10 Plus systems or scale out storage in multi-node configurations while maintaining a tidy, serviceable front end.

Technical Details of HPE ProLiant DL360 Gen10 Plus 2SFF SAS/SATA 12G BC Drive Cage Kit

• Product Type: Drive Cage Kit for HPE ProLiant DL360 Gen10 Plus
• Drive Bays: 2 x 2.5-inch SFF bays (hot-swappable)
• Backplane: 12 Gbps SAS/SATA backplane (12G BC)
• Compatibility: Specifically designed for HPE ProLiant DL360 Gen10 Plus servers; compatible with standard HP drive trays
• Mounting Form Factor: Front-access drive cage intended for 1U rack-mount chassis
• Material and Finish: Durable steel construction with a black finish suitable for data-center environments
• Includes: Cage assembly, backplane, mounting screws, and necessary installation hardware
• Weight (approximate): 1.5–2.5 kg depending on configuration and included components
• Warranty: Standard HP enterprise warranty coverage applicable to replacement parts and service

How to install HPE ProLiant DL360 Gen10 Plus 2SFF SAS/SATA 12G BC Drive Cage Kit

• Power down the DL360 Gen10 Plus server, unplug all cables, and discharge static electricity before handling components to protect the backplane and drives.
• Remove the existing front bezel or drive cage if you are upgrading an existing configuration. Follow your server’s maintenance procedure to access the front panel safely.
• Align the drive cage with the designated 1U chassis mounting holes and slide it into the front of the server chassis. Secure the cage using the provided mounting screws, ensuring a firm, vibration-free fit.
• Connect the 12G SAS/SATA backplane to the server’s appropriate internal cables or connectors as specified by HP’s installation guide. Confirm that power and data connections are fully seated to avoid intermittent drive recognition issues.
• Install two 2.5-inch SAS/SATA drives into the SFF trays (if not already installed). Slide each drive tray into the corresponding cage slot until the latch engages and the drive is firmly seated.
• Reinstall any front bezel or cooling components removed earlier. Reconnect external cables and power up the server. Enter the system BIOS/RAID controller utility during POST to verify that both drives are detected and available for configuration.
• In the operating system or RAID controller, configure your storage as required (e.g., RAID 0/1, JBOD, or pass-through). Perform a basic integrity check and initialize any new arrays or logical drives, then monitor drive health and performance through HP management tools.
• Record the drive cage kit part number and serial information for warranty and maintenance, and update server documentation to reflect the new storage topology. This ensures quick diagnostics and future upgrades.

Frequently asked questions

• What does the drive cage kit include, and are drives included? The kit provides the cage assembly, 12G SAS/SATA backplane, and installation hardware. Drives are not included; you’ll need to supply your own 2.5-inch SAS/SATA drives or reuse existing drives from another setup.
• Is this kit compatible with other HP ProLiant servers beyond the DL360 Gen10 Plus? This kit is specifically designed for the DL360 Gen10 Plus family. While some components may be compatible with other HP servers, full compatibility and performance are guaranteed only when used with the DL360 Gen10 Plus.
• Can I hot-swap drives with this cage kit installed? Yes. The design supports hot-swapping for maintenance windows and rapid rebuilds, minimizing downtime in production environments.
• What kind of performance can I expect from the 12G backplane? The 12G SAS/SATA backplane offers high-bandwidth data transfer with low-latency access for 2.5-inch SAS/SATA drives, ideal for intensive IO workloads and virtualization scenarios commonly deployed on DL360 Gen10 Plus servers.
• What warranty and support are available for this kit? HP enterprise kits typically come with a standard warranty and access to HP support services. The exact coverage may vary by region and purchase agreement; consult your HP sales representative for precise terms.
