HPE Outdoor MIMO Antenna Kit ANT-3x3-2005
Introducing the HPE ANT-3x3-2005 Outdoor MIMO Antenna Kit—a purpose-built trio of omnidirectional antennas designed to optimize wireless performance in outdoor environments. Built for 2.4–2.5 GHz operation, this kit is tailor-made for 802.11ac and 802.11n MIMO mesh links and client access, delivering reliable coverage across campuses, stadiums, warehouses, and outdoor public spaces. With two vertical antennas and one horizontal antenna, the ANT-3x3-2005 provides flexible deployment options to suit diverse topographies and deployment geometries. Its omnidirectional radiation pattern ensures broad, uniform coverage without the need for precise aiming, while the 3x3 MIMO configuration harnesses multiple RF paths to boost throughput, reduce dead zones, and improve network resilience in challenging outdoor conditions. Whether you’re building a new outdoor wireless mesh from the ground up or upgrading an existing network, this kit offers a scalable, cost-effective path to higher capacity and better user experiences in open-air settings.
- Three omnidirectional antennas tuned for 2.4–2.5 GHz to support 802.11ac and 802.11n networks, enabling strong coverage for mesh links and client access in outdoor environments.
- 3x3 MIMO configuration with two vertical and one horizontal antenna, providing deployment flexibility to optimize radiation patterns and maximize signal reach across complex outdoor layouts.
- Outdoor-ready design built to withstand weather, wind, and temperature variations, ensuring reliable performance in harsh outdoor deployments over time.
- Enhanced network performance through improved spatial diversity and multiple RF paths, increasing throughput, reducing interference impact, and expanding coverage for outdoor hotspots and campuses.
- Easy integration with compatible HPE access points and mesh devices, reducing setup complexity and enabling rapid rollout for enterprise outdoor networks.
Technical Details of HPE Outdoor MIMO Antenna Kit ANT-3x3-2005
- Frequency Range: 2.4–2.5 GHz
- Antenna Type: Omnidirectional
- MIMO Configuration: 3x3 kit comprising three antennas (two vertical, one horizontal)
- Quantity per kit: 3 antennas
- Deployment: Outdoor-use for MIMO mesh links and client access
How to install HPE Outdoor MIMO Antenna Kit ANT-3x3-2005
- Plan your installation: Choose a high, unobstructed outdoor location with clear line-of-sight to the associated APs or mesh nodes. Consider nearby sources of interference and physical mounting options to support wind loads and weather exposure.
- Mount the antennas: Securely fasten the two vertical antennas and the one horizontal antenna to a sturdy outdoor mast, pole, or mount. Ensure all mounting hardware is rated for outdoor use and that the antennas are oriented to maximize coverage in the target area.
- Route cabling: Run weatherproof cabling from each antenna to the network equipment. Use appropriate seals, grommets, and cable glands to prevent moisture ingress and to maintain a clean RF path back to the radios.
- Connect and align: Connect the antennas to the corresponding radio ports on your outdoor APs or MIMO radios. While the omnidirectional pattern reduces the need for precise aiming, verify that the rotational orientation supports optimal coverage for the client layout and minimizes potential interference.
- Test and optimize: Power on the network, monitor link quality, signal strength, and throughput across the 2.4 GHz band. Make small orientation or placement adjustments if necessary to eliminate coverage gaps and to balance uplink/downlink performance.
Frequently asked questions
-
Q: What is the ANT-3x3-2005 used for?
A: It is an outdoor MIMO antenna kit designed to improve coverage and throughput for 2.4–2.5 GHz networks, supporting 802.11ac and 802.11n mesh links and client access with a 3x3 antenna configuration. -
Q: How many antennas are included?
A: The kit includes three omnidirectional antennas—two vertical and one horizontal—to enable flexible 3x3 MIMO deployments. -
Q: Can this kit be used with 802.11ac devices?
A: Yes. It is designed for 802.11ac and 802.11n networks operating in the 2.4–2.5 GHz range, enabling higher performance in outdoor environments. -
Q: Is the antenna kit weatherproof?
A: The kit is intended for outdoor use and is built to withstand typical outdoor conditions. Proper mounting and weatherproof cabling are recommended to ensure long-term reliability. -
Q: How difficult is installation?
A: Installation is moderately straightforward for networking professionals or technicians familiar with outdoor wireless deployments. It involves mounting, cabling, and basic radio configuration to align with existing APs or mesh devices.
