HPE StoreFabric B-Series 100GbE QSFP28 SR4 Transceiver

HPESKU: 7585560

Price:
Sale price$16,249.81

Description

HPE StoreFabric B-Series 100GbE QSFP28 SR4 Transceiver

Take your data-center interconnects to the next level with the HPE StoreFabric B-Series 100GbE QSFP28 SR4 Transceiver. Built to enhance reliability, reach, and performance, this optical module is engineered for high-bandwidth, low-latency connections between compute nodes and switch nodes within HPE StoreFabric M-Series deployments. The QSFP28 SR4 optics deliver a full 100 Gb/s of aggregate bandwidth through four parallel 25 Gb/s lanes, enabling dense, scalable fabrics that meet the demands of modern workloads—from virtualization and storage systems to AI/ML pipelines and large-scale analytics. Designed for seamless integration with HPE switches and servers, these transceivers simplify deployment while ensuring consistent, predictable performance across your fabric. With robust testing, rigorous quality standards, and compatibility with industry standards, the StoreFabric B-Series transceiver helps you reduce downtime and accelerate time-to-value in even the most demanding data-center environments.

  • High-bandwidth, quad-lane design: 100 Gb/s of aggregate throughput via four 25 Gb/s lanes in a compact QSFP28 form factor, optimized for dense, scalable data-center fabrics.
  • SR4 optics for reliable MMF transmission: 850 nm SR4 multimode optical technology designed for short-reach interconnects with low latency and high signal integrity.
  • MPO/MTP fiber connector and MMF compatibility: Supports standard MPO/MTP fiber cabling, enabling straightforward deployment in leaf-to-spine and top-of-rack scenarios across HPE environments.
  • Hot-pluggable, enterprise-grade reliability: hot-swap capable and built for the rigors of 24/7 data-center operation, helping to minimize downtime during maintenance and upgrades.
  • Designed for StoreFabric ecosystems: specifically tuned to work with HPE StoreFabric B-Series and M-Series fabrics, delivering optimized performance, interoperability, and simplified management within your HPE infrastructure.

Technical Details of HPE StoreFabric B-Series 100GbE QSFP28 SR4 Transceiver

  • Data Rate: 100 Gb/s total, implemented as 4 x 25 Gb/s lanes
  • Optical Type: SR4 multimode transmitter and receiver (850 nm)
  • Fiber Type & Distance: Multimode fiber (MMF); typical reach up to 100 meters on OM4, up to 70 meters on OM3
  • Connector: MPO/MTP interface for fiber, supporting four lanes across a single module
  • Form Factor: QSFP28 hot-pluggable transceiver
  • Wavelength: 850 nm (short-reach optical channel)
  • Operating Temperature: 0 to 70 C for standard data-center environments
  • Compliance: IEEE 802.3 100GBASE-SR4 standard, designed for interoperability in multi-vendor environments
  • Power Consumption: Typical ranges in line with similar SR4 transceivers; designed to balance performance with data-center power budgets
  • Mounting & Compatibility: Plug-and-play with supported HPE switches and servers; hot-swappable in compatible platforms

How to install HPE StoreFabric B-Series 100GbE QSFP28 SR4 Transceiver

  • Power down or prepare for hot-swapping if your platform supports it, and verify that the target port is labeled for 100 Gb/s operation. Review your device’s maintenance guidelines before proceeding.
  • Handle the transceiver by the body to avoid touching the optical connectors or contacts. Ground yourself with proper ESD protection to prevent static damage.
  • Remove the existing module from the QSFP28 slot if upgrading, or prepare an empty slot for installation. Align the module with the slot orientation and slide it in firmly until it seats and the retention latch engages.
  • Route the fiber harness correctly and connect the MPO/MTP cable to the transceiver’s connector. Use appropriate polarity and lane mapping as dictated by your network design (check switch port documentation for any required A-to-B or A-to-A configurations).
  • After installation, power on the device (or restore power if you performed a hot-swap) and verify link status using your switch management interface. Confirm that the 100 Gb/s link comes up on all four lanes and monitor for any errors or alignment issues. Run basic loopback tests if needed to validate end-to-end connectivity.

Frequently asked questions

  • Q: What is 100GbE SR4? A: 100GbE SR4 is a short-reach, multi-lane optical transceiver standard that uses four 25 Gb/s lanes on a QSFP28 module to deliver 100 Gbps of data rate over multimode fiber, typically for datacenter interconnects within a few hundred meters.
  • Q: Is this transceiver compatible with non-HPE hardware? A: While it is engineered for HPE StoreFabric ecosystems, SR4 QSFP28 transceivers generally conform to IEEE 802.3 100GBASE-SR4 and may work with other vendors’ switches that fully support SR4 optics; however, cross-vendor interoperability can vary by firmware and platform. Always confirm compatibility with your specific hardware.
  • Q: What fiber cables and connectors do I need? A: Use multimode fiber (OM3 or OM4) with MPO/MTP connectors to connect the SR4 transceiver. The exact length and fiber grade should align with your distance requirements and installation environment.
  • Q: Can I hot-swap this transceiver? A: Yes. The HPE StoreFabric B-Series 100GbE QSFP28 SR4 transceiver is designed for hot-swapping in supported systems, enabling minimal downtime during maintenance and upgrades. Follow standard ESD guidelines and platform-specific procedures.
  • Q: What should I do if the link doesn’t come up? A: First, verify physical connections and fiber polarity. Ensure the module is properly seated and recognized by the system firmware, and confirm the switch port is configured for 100G operation. Check for lens cleanliness, ensure correct lane mapping, and review event logs or interface counters for errors related to NRZ, lane alignment, or signal integrity.
