Intel Wireless-AC 9560 CNVi CRF Adapter for Notebook – Bluetooth 5.1 + 2x2 802.11ac

The Intel Wireless-AC 9560 is a compact, high-performance CNVi (Connectivity Integration) companion RF module designed to bring next-generation wireless capabilities to modern notebooks. This integrated CRF (companion RF) solution combines cutting-edge 802.11ac Wi-Fi with Bluetooth 5.1 in a single, space-saving module, enabling slimmer laptop designs without compromising speed, reliability, or feature set. Built to support the first generation of Intel’s integrated wireless platform, the 9560 offers robust dual-band connectivity, 2x2 MIMO throughput, and enhanced Bluetooth performance that covers everyday tasks—from rapid file transfers and smooth video streaming to low-energy, low-latency gaming and immersive audio experiences. If you’re upgrading an older notebook or designing a new device, the Intel Wireless-AC 9560 provides a future-ready wireless core that pairs well with the latest CPUs, chipsets, and system architectures, delivering reliable performance across a wide range of environments.

• 2x2 MU-MIMO Wi-Fi performance delivers higher real-world throughput on both 2.4 GHz and 5 GHz bands, enabling faster downloads, snappier web experiences, and smoother streaming even in busy networks. This improves overall user experience in homes, offices, and campus environments where multiple devices contend for airspace.
• Bluetooth 5.1 support brings extended range, improved speed, and lower energy consumption for peripheral devices. Whether you’re pairing wireless headphones, mice, keyboards, speakers, or tactile controllers, Bluetooth 5.1 offers more reliable connections and superior audio performance with reduced latency for a truly seamless experience.
• CNVi-based CRF module represents Intel’s integrated wireless approach, combining CNVi and a companion RF module for a compact, design-friendly solution. This architecture simplifies OEM layouts, reduces PCB footprint, and supports streamlined integration with Intel platforms to optimize power efficiency and thermal performance in portable devices.
• Dual-band versatility supports both 2.4 GHz and 5 GHz networks, enabling flexible network selection for coverage, interference avoidance, and higher performance. The 5 GHz band typically delivers higher data rates ideal for HD video, gaming, and large file transfers, while 2.4 GHz offers broader range in challenging environments.
• Notebook optimization and longevity designed for modern system designs, the 9560 helps OEMs achieve slimmer chassis, better thermal profiles, and longer battery life without sacrificing wireless speed or reliability. The result is a future-ready wireless core that supports today’s workloads and tomorrow’s updates while staying easy to service and upgrade when needed.

Technical Details of Intel 9560

• Form factor: CNVi CRF module designed for notebook integration, enabling a compact, plug-ready wireless solution.
• Wireless standard: 802.11ac (Wi‑Fi) with 2x2 MIMO, offering robust performance in typical home, office, and public networks.
• Bluetooth: Bluetooth 5.1 for enhanced device connectivity, longer range, and improved energy efficiency.
• Interface: CNVi (Connectivity Integration) with companion RF module (CRF) for streamlined system design.
• Data throughput (theoretical): Up to ~1.73 Gbps combining 2x2 MU-MIMO capabilities on compatible networks.
• Frequency bands: 2.4 GHz and 5 GHz dual-band operation to maximize compatibility and performance across environments.
• Security and features: Modern Wi‑Fi security features plus Bluetooth capabilities that support a wide range of peripherals and accessories.
• Compatibility: Optimized for use with Intel platform designs; suitable for a broad range of notebooks and OEM configurations seeking integrated wireless solutions.

how to install Intel 9560

• Power down the notebook completely and disconnect any external power sources. Open the back panel or access door as required by your device’s service guide, and locate the existing wireless module or the CNVi/CRF slot if you’re performing a new installation.
• If replacing an existing module, carefully disconnect antenna cables (usually labeled as Main and Aux) from the current card and remove any screws securing the module to its slot. Keep track of screw size and position for reassembly.
• Align the Intel Wireless-AC 9560 CNVi CRF module with the slot, ensuring the notch and connector alignments match. Gently insert the module into the CNVi/CRF interface without applying excessive force, then secure it with the proper screw.
• Reconnect the antenna cables to the new module. Typically, the black/white or blue/grey color scheme helps ensure correct attachment. Confirm a firm but gentle connection to prevent intermittent wireless issues.
• Reassemble the notebook, boot the system, and install or update the latest Intel wireless drivers and Bluetooth software from Intel’s official support site or your device manufacturer’s support portal. After installation, run a quick network test to verify Wi‑Fi and Bluetooth connectivity across multiple devices.

Frequently asked questions

• What is the Intel Wireless-AC 9560? It is a CNVi-based companion RF module (CRF) that combines 802.11ac Wi‑Fi with Bluetooth 5.1 in a single, compact card designed for notebook integration. It provides dual-band connectivity and supports 2x2 MU‑MIMO for improved wireless throughput.
• Which devices are compatible with the 9560? The module is intended for notebooks and OEM devices that offer a CNVi/CRF slot. Compatibility depends on the notebook’s motherboard design, antenna layout, BIOS support, and driver availability for the platform. OEM integration guides and Intel’s official support are the best resources to confirm compatibility.
• Do I need any special drivers? Yes. After installing the card, install the latest Intel Wireless-AC 9560 drivers and Bluetooth software from Intel’s support site or your device manufacturer. Keeping drivers up to date ensures peak performance, security, and compatibility with new features or operating system updates.
• What are the main benefits of Bluetooth 5.1 with this module? Bluetooth 5.1 offers longer range, greater speed, and improved energy efficiency over previous Bluetooth versions. This translates to more reliable wireless peripheral connections, lower power draw for battery-powered devices, and better performance for audio devices, keyboards, mice, and IoT accessories.
• How does CNVi CRF integration help notebook design? CNVi CRF integration reduces board area and simplifies the overall wireless subsystem, enabling thinner, lighter laptops with faster integration cycles. It also supports tighter coupling with Intel platform features and can improve power efficiency and thermal management in compact notebooks.
