KanexPro FLEX-IN-HDBT4K: One-Input 4K HDBaseT Card with Embedded Audio

The KanexPro FLEX-IN-HDBT4K is a precision-built HDBaseT input card designed for the FLEX-MMX modular switcher ecosystem. This single-input card delivers pristine 4K video, smooth 1080p/60 HD performance, and PC resolutions up to 1920x1200@60Hz with the convenience of embedded PCM analog audio. Engineered for reliability in professional AV deployments, it supports HDCP protection and offers EDID management directly from the switcher, helping you ensure consistent source-to-display behavior across a wide range of displays and projectors. Built to integrate seamlessly into KanexPro’s FLEX-MMX chassis, this card provides a scalable, modular path to high-quality AV routing in conference rooms, classrooms, control rooms, and digital signage installations.

• One input HDBaseT card with embedded PCM audio: Transmit high-quality video and audio over a single CATx cable, enabling a clean, simplified installation with less cabling and reliable long-distance performance.
• 4K and HD performance: Supports video resolutions up to 4K, with 1080p/60 HD compatibility and computer/PC resolutions up to 1920x1200@60Hz, making it suitable for modern 4K sources as well as legacy displays.
• HDCP compliant with EDID management: Ensures secure content protection while giving the switcher control over EDID to optimize source compatibility and display behavior for a stable viewing experience.
• Designed for FLEX-MMX chassis: A purpose-built component that integrates into KanexPro’s FLEX-MMX modular system, enabling scalable routing solutions and easy expansion as your AV needs grow.
• Embedded audio and reliable routing: PCM analog audio is embedded alongside video, simplifying audio routing and synchronization for presentations, video walls, and AV installations.

Technical Details of KanexPro FLEX-IN-HDBT4K

• FLEX-IN-HDBT4K
• One-input HDBaseT card for FLEX-MMX chassis
• Up to 4K resolutions (3840x2160) with 60 Hz support; 1080p/60 Hz; PC resolutions up to 1920x1200@60Hz
• Embedded PCM analog audio accompanying the HDBaseT video signal
• HDCP-compliant for secure content protection
• EDID control and management from the FLEX-MMX switcher for stable compatibility across devices
• Specifically designed for KanexPro FLEX-MMX modular switcher systems
• Card-based integration within the FLEX-MMX backplane

How to Install KanexPro FLEX-IN-HDBT4K

• Power down the FLEX-MMX chassis and all connected source and display devices to prevent any electrical damage during installation.
• Open or access the FLEX-MMX chassis according to the manufacturer’s guidelines, and locate an available slot for a new input card.
• Insert the FLEX-IN-HDBT4K card firmly into the appropriate slot in the FLEX-MMX backplane until it seats securely and any latches or retention mechanisms engage.
• Connect the HDBaseT input from your source device to the card’s HDBaseT input port using a high-quality CAT6/6a/7 cable, ensuring a proper connection for both video and embedded audio signals.
• Power on the FLEX-MMX chassis and the connected source. Use the switcher’s EDID management controls to set the preferred display parameters or allow automatic EDID negotiation if your deployment supports it.
• Configure any required routing or matrix settings within the FLEX-MMX user interface, and verify that the 4K/60 or 1080p/60 output is correctly routed to the intended displays with synchronized audio from the embedded PCM stream.

Frequently Asked Questions

• What is the KanexPro FLEX-IN-HDBT4K? It is a single-input HDBaseT input card designed for the FLEX-MMX modular switcher system, enabling 4K video, HDCP protection, and embedded PCM audio over a single cable.
• What resolutions does it support? It supports 4K video up to 3840x2160 at 60 Hz, 1080p at 60 Hz, and PC resolutions up to 1920x1200 at 60 Hz.
• Does it require EDID configuration? Yes. The card supports EDID management from the FLEX-MMX switcher, allowing reliable compatibility with sources and displays, and it can be adjusted as needed for specific installations.
• Is the card HDCP compliant? Yes, the FLEX-IN-HDBT4K is HDCP compliant to ensure secure distribution of protected content when used in A/V environments.
• What is the purpose of embedded PCM audio? The embedded PCM analog audio provides synchronized audio alongside the transmitted video, simplifying audio routing and reducing the need for separate audio cabling in many installations.
• How does installation work? It installs into a FLEX-MMX chassis as a plug-in card, connects to the source via HDBaseT, and is managed through the FLEX-MMX control interface for EDID and routing settings.
