KanexPro FLEX-OUT-HDBT4K: Flexible One Output HDBaseT Card with Audio

Elevate your AV distribution with the KanexPro FLEX-OUT-HDBT4K, a purpose-built HDBaseT card engineered for the FLEX-MMX chassis. This single-output card delivers reliable 4K video transport alongside a de-embedded PCM analog audio path, enabling clean, flexible routing for classrooms, conference rooms, rental schemes, and pro AV installations. Designed to maximize the potential of KanexPro’s modular FLEX-MMX ecosystem, the FLEX-OUT-HDBT4K blends advanced video compatibility with robust audio support, making it an ideal backbone for scalable, long-reach AV networks. Whether you’re upgrading a legacy system or building a new hybrid solution, this card provides the precision, reliability, and ease of integration you expect from KanexPro’s professional line.

• The FLEX-OUT-HDBT4K offers a seamless one-output HDBaseT solution that integrates directly into the FLEX-MMX chassis, enabling a clean, compact, modular path for distributing high-resolution video and audio over standard category cables to distant displays or receivers.
• With de-embedded PCM analog audio output, you can route high-fidelity audio independently from the video signal. This feature simplifies integration with external mixers, speakers, or room audio systems without compromising video integrity, making it ideal for conference rooms and multimedia classrooms.
• Video support covers modern needs: up to 4K resolution for today’s demanding displays, plus 1080p/60 for legacy equipment. It also accommodates PC resolutions up to 1920x1200 at 60 Hz, ensuring sharp text, smooth graphics, and reliable performance across a variety of sources and displays.
• The card is HDCP compliant, helping to enforce content protection standards while maintaining compatibility across a wide range of displays and sources. In addition, EDID management from the sink ensures the optimal handshake and display compatibility, reducing setup friction and hand-off issues when different displays are connected.
• Built for FLEX-MMX chassis integration, the FLEX-OUT-HDBT4K supports scalable AV configurations—from small rooms to larger multi-display deployments—allowing installers to expand their system footprint without sacrificing performance or control. Its design emphasizes reliability, easy installation, and long-term compatibility within KanexPro’s modular architecture.

Technical Details of KanexPro FLEX-OUT-HDBT4K

• Model: FLEX-OUT-HDBT4K
• Card Type: One-output HDBaseT input/output card for the FLEX-MMX chassis
• Video Support: 4K resolution support (up to 60 Hz) and 1080p/60; PC resolutions up to 1920x1200@60 Hz
• Audio Support: De-embedded PCM analog audio output for external routing
• HDCP Compliance: Yes, standard HDCP compliance for protected content viewing
• EDID Management: EDID management from the sink to ensure proper source/display compatibility
• Interface: 1 x HDBaseT output for distribution to a compatible receiver or display
• Chassis Compatibility: Designed for KanexPro FLEX-MMX modular chassis for scalable installations
• Power and Connectivity: Integrated within the FLEX-MMX ecosystem; power and control are supplied through the chassis system

How to install KanexPro FLEX-OUT-HDBT4K

• Power down the FLEX-MMX chassis and locate an available slot that supports the FLEX-OUT-HDBT4K card. Carefully align the card with the backplane and firmly seat it into place, ensuring a secure connection.
• Secure the card with any required retaining hardware provided by the chassis, then reassemble the chassis to prepare for power-up. Verify that all cooling and ventilation paths remain unobstructed to maintain performance and longevity.
• Connect the source device (e.g., a video processor, media server, or computer) to the appropriate input on the FLEX-MMX system if required by your deployment, and connect the single HDBaseT output from the FLEX-OUT-HDBT4K to the corresponding HDBaseT receiver or display location. Use a high-quality CAT cable rated for the needed distance to maintain signal integrity.
• Power on the chassis and the connected devices. Use the FLEX-MMX control interface to confirm recognition of the FLEX-OUT-HDBT4K card, verify HDBaseT transmission, and check EDID negotiation with the sink. If EDID issues arise, adjust the sink settings or EDID management parameters to optimize compatibility.
• Configure audio routing as needed: route the de-embedded PCM analog audio to the desired audio system, mixer, or speaker array, while the video path continues through the HDBaseT link. Test both video and audio playback at the display to confirm synchronization and quality across your installation.

Frequently asked questions

• Q: What resolutions does the FLEX-OUT-HDBT4K support?
  A: The card supports 4K video up to 60 Hz and 1080p/60, with PC resolutions up to 1920x1200 at 60 Hz, accommodating modern displays and typical PC workstations.
• Q: Does this card provide audio capabilities?
  A: Yes. It features a de-embedded PCM analog audio output, enabling separate routing of audio to external devices without impacting the video path.
• Q: Is the FLEX-OUT-HDBT4K HDCP compliant?
  A: Yes, it is designed to comply with HDCP standards to protect copyrighted content across compatible displays and sources.
• Q: Can EDID be managed for compatibility with different displays?
  A: Yes. The card supports EDID management, typically from the sink, to help ensure proper display compatibility and a stable handshake.
• Q: Is the card compatible with the FLEX-MMX chassis?
  A: Absolutely. The FLEX-OUT-HDBT4K is built specifically for KanexPro FLEX-MMX chassis, enabling scalable, modular AV configurations.
