Kramer 2x2 to 16x16 Modular 4K60 4:2:0 Managed Digital Matrix Switcher

The VS-1616DN-EM is a high-performance, scalable matrix switcher chassis designed to route AV signals with precision, versatility, and reliability. Engineered for modern conference rooms, control rooms, broadcast facilities, and corporate environments, this Kramer solution grows with your needs—from a compact 2x2 setup to a full 16x16 matrix—without replacing the core hardware. Its modular architecture, 4K60 (4:2:0) capability, and optional dual power supplies deliver a robust foundation for demanding AV deployments that require flexible routing, multi-format support, and enterprise-grade uptime.

• Modular scalability and flexible I/O expansion

  The VS-1616DN-EM is a modular matrix switcher chassis designed to scale in increments of two inputs and/or two outputs, allowing you to evolve from a 2x2 configuration up to a 16x16 matrix as requirements change. This architecture provides an economical path to future-proofing your installation, supporting growing collaboration spaces, multi-zone environments, and complex AV distributions without a complete system overhaul. Because the chassis is populated progressively, integrators can tailor the exact IO count to match room size, signal complexity, and budget, then expand later with confidence.

  In practice, this means easier planning for retrofits, less downtime during upgrades, and a single, centralized platform for routing a broad mix of sources to multiple displays, projectors, or capture devices. The design prioritizes clean signal paths and organized wiring, which simplifies maintenance and reduces the physical footprint in AV racks while preserving headroom for future port additions.

• High-performance 4K60 4:2:0 multi-format routing

  At its core, the VS-1616DN-EM delivers high-bandwidth, low-latency routing suitable for demanding modern AV ecosystems. It supports 4K at 60 Hz with 4:2:0 chroma subsampling, enabling reliable, visually accurate distribution of ultra-high-definition content across larger installations. The multi-format nature of the switcher means it can handle a variety of signal formats commonly encountered in corporate, educational, and hospitality settings, including blends of HD, 1080p, and 4K sources, all routed through a unified matrix. This versatility is particularly valuable in environments where different rooms require different formats yet share a common control plane, ensuring seamless, synchronized presentations and show content with minimal delay.

  Beyond raw bandwidth, the switcher emphasizes signal integrity with careful management of timing, EDID handling, and routing fidelity to preserve image clarity and color accuracy as signals traverse multiple inputs and outputs. Operators appreciate the predictable performance under load, which translates to stable room configurations during time-sensitive events such as executive briefings, training sessions, and live broadcasts.

• Reliable uptime with optional dual redundant power supplies

  For deployments where continuous operation is non-negotiable, the VS-1616DN-EM offers optional dual redundant power supplies. This configuration helps maximize uptime by providing a hot-swappable, backup power path that can take over seamlessly in the event of a primary PS failure. In enterprise and mission-critical environments, redundancy reduces the risk of signal disruption due to power issues, allowing AV teams to rely on the matrix for long sessions, essential meetings, and multi-day events without interruption. The chassis design also supports sensible power budgeting and thermal management, contributing to stable performance in rack environments where heat and airflow must be carefully managed.

  With redundant power, operators gain peace of mind and operational resilience, particularly in installations where IT and AV systems coexist in shared racks or data centers. The ability to upgrade power reliability without replacing the matrix chassis aligns with long-term architectural planning and simplifies maintenance windows.

• Comprehensive management and control

  The VS-1616DN-EM emphasizes centralized, intuitive management to simplify complex routing tasks. Built for professional AV deployments, it provides straightforward configuration of routing matrices, channel labeling, and status monitoring across all inputs and outputs. Operators can plan and execute routing changes quickly, whether during a live event, a formal presentation, or daily classroom use. The management features are designed to integrate with control systems and room automation workflows, offering a cohesive control surface for technicians and end-users alike. Status indicators, diagnostic data, and streamlined routing tables enable rapid fault detection and resolution, helping maintain a smooth user experience even when multiple sources are active simultaneously.

  In addition to on-device controls, the matrix supports remote management capabilities typical of enterprise AV hardware. This enables IT teams and system integrators to program, monitor, and troubleshoot the matrix from a central location, reducing on-site visits and accelerating project deployment timelines. The combination of multi-format support, scalable IO, and centralized control makes the VS-1616DN-EM a practical backbone for unified AV distribution in multi-room environments.

• Rugged, enterprise-grade design for reliability

  The system is built to endure the rigors of professional installations. Its rugged chassis and modular architecture are designed to stand up to continuous operation, frequent reconfigurations, and the demands of high-traffic AV environments. The modular approach not only simplifies future upgrades but also supports easier field maintenance and part replacement, reducing maintenance downtime. Visual indicators and robust connectors help technicians quickly assess system health during routine checks, while the scalability of the platform ensures you can adapt to evolving AV standards and room configurations without costly replacements.

  Overall, the VS-1616DN-EM combines durability with flexibility, delivering a dependable matrix solution that scales with your AV strategy while maintaining a clean, organized rack presence and straightforward management for operators and technicians.

Technical Details of Kramer 2x2 to 16x16 Modular 4K60 4:2:0 Managed Digital Matrix Switcher

• Model: VS-1616DN-EM
• Input/Output Capacity: Configurable from 2x2 up to 16x16 in increments of two inputs and/or two outputs
• Video Format: Supports 4K@60Hz signals with 4:2:0 chroma subsampling; multi-format digital matrix routing
• Chassis Type: Modular AV matrix switcher chassis designed for scalable expansion
• Power: Optional dual redundant power supplies available to maximize uptime
• Management: Built-in management capabilities for routing configuration and status monitoring; supports centralized control workflows

How to install Kramer 2x2 to 16x16 Modular 4K60 4:2:0 Managed Digital Matrix Switcher

• Plan your configuration by mapping the required IO count and identifying the locations for the matrix chassis within a standard equipment rack. Ensure adequate ventilation and clear access for front-panel indicators and rear connectors.

• Install the chassis in the rack and secure it with rack rails. If using redundant power, install the second power supply and connect power according to the installation guide. Ensure proper cable management to minimize strain on connectors and to simplify future maintenance.

• Populate inputs and outputs to match your intended configuration. Begin with a conservative 2x2 setup and gradually expand by adding two-input/two-output modules as needed, testing each expansion step to confirm stable routing.

• Connect AV sources to the inputs and displays or capture devices to the outputs using appropriate high-quality cables. Verify signal integrity and confirm that EDID and resolution expectations align between sources and displays.

• Connect any control devices or management interfaces (LAN/ Ethernet, RS-232, or USB as applicable) and perform initial software setup. Use the built-in management interface to configure routing, labeling, and monitoring, and test routing paths thoroughly before going into full operation.

Frequently asked questions

• Q: What is the maximum I/O configuration supported by this switcher?

  A: The VS-1616DN-EM supports configurations from 2x2 up to 16x16 in increments of two inputs and two outputs, allowing scalable routing for a range of room sizes and use cases.

• Q: Which video format does it support?

  A: It supports 4K@60Hz with 4:2:0 chroma subsampling and is designed for multi-format digital routing to accommodate a variety of AV sources and displays.

• Q: Does it offer redundant power?

  A: Optional dual redundant power supplies are available, providing increased uptime for critical deployments. The system is designed to operate with reliable power while maintaining performance under load.

• Q: How is the system managed?

  A: The matrix includes built-in management features for routing configuration and status monitoring, suitable for centralized control workflows in professional AV environments. It supports integration with control systems for streamlined operation.

• Q: Is installation difficult for non-experts?

  A: While professional installation is recommended, the modular design and clear management interface are intended to simplify planning, expansion, and ongoing maintenance for qualified AV technicians. Following the provided setup steps will help ensure a reliable deployment.
