Kramer DGKat-OUT2-F16: 2-Channel HDMI & RS-232 over DGKat Output Card for VS-1616

The Kramer DGKat-OUT2-F16 is a high-performance two-channel HDMI and RS-232 output card designed for the VS-1616 Series Modular Multi-Format Digital Matrix Switchers. This DGKat-based solution brings HDMI video and RS-232 serial control to remote displays and devices with a single, streamlined twisted-pair link. Engineered for professional AV environments, the DGKat-OUT2-F16 delivers reliable, distortion-free signal transmission over standard DGKat copper cabling, minimizing clutter while maximizing versatility. With its robust data rate, extended reach, and seamless integration into the Kramer ecosystem, this card is a smart choice for installers seeking scalable, future-proof distribution of HDMI and serial control across medium to large installations.

• Two-channel HDMI and RS-232 outputs over DGKat: The DGKat-OUT2-F16 provides two independent HDMI channels and two RS-232 control channels, all transmitted over a single DGKat twisted-pair link. This enables streamlined routing from the VS-1616 chassis to remote displays or serial-controlled devices, reducing cabling complexity without sacrificing performance.
• High data rate for crystal-clear video: Maximum data rate is 4.95 Gbps, ensuring support for high-quality HDMI signals at common professional formats. This bandwidth supports 1080p60 with room for additional color depth and format payloads, making it suitable for contemporary AV installations and dynamic display content.
• Extended reach over DGKat twisted pair: System range extends up to 90 meters (300 feet) at 1080p@60Hz. This generous distance capability enables centralized control rooms and distant display zones to share reliable HDMI and RS-232 connections without signal degradation.
• Seamless integration with the VS-1616 Series: Built specifically for Kramer’s modular multi-format digital matrix switchers, the DGKat-OUT2-F16 plugs into the VS-1616 chassis to extend its routing and control capabilities. It’s designed for plug-and-play use within Kramer’s ecosystem, simplifying installation and ongoing maintenance.
• Versatile RS-232 control for displays and devices: The RS-232 outputs enable serial communication with displays, projectors, receivers, and other control-enabled equipment. This allows centralized control of remote devices as part of automated AV presentations, conferences, or signage networks, enhancing interoperability and orchestration across multiple rooms.

Technical Details

• Product family: DGKat output card for the VS-1616 Series Modular Multi-Format Digital Matrix Switchers
• Channels: 2-channel HDMI outputs and 2-channel RS-232 signals over DGKat
• Data rate: Up to 4.95 Gbps
• Transmission medium: DGKat twisted-pair cabling
• Maximum range: Up to 90 meters (300 feet) at 1080p@60Hz
• Compatibility: Specifically designed for Kramer VS-1616 Series Modular Multi-Format Digital Matrix Switchers
• Key benefit: Combines HDMI distribution and RS-232 control over a single DGKat connection for streamlined installations

How to Install DGKat-OUT2-F16

• Power down the VS-1616 chassis and unplug any connected peripherals before installing the card.
• Insert the DGKat-OUT2-F16 into the appropriate slot in the VS-1616 Series chassis, ensuring a secure, locked connection.
• Connect your DGKat twisted-pair cable from the VS-1616 DGKat port to the remote DGKat receiver(s) or displays that will utilize the HDMI and RS-232 outputs.
• Attach HDMI-enabled displays or devices to the two HDMI outputs on the card or through the corresponding distribution path in your matrix configuration. Connect RS-232-enabled displays or control devices to the two RS-232 ports as needed for serial communication.
• Power up the chassis and configure the matrix routing via the Kramer control interface. Route the appropriate HDMI and RS-232 paths to the target destinations, and perform a quick verification with test content and device control commands to confirm stable operation over the DGKat link.

Frequently Asked Questions

• What is the DGKat-OUT2-F16?

  The DGKat-OUT2-F16 is a two-channel HDMI and RS-232 output card for the Kramer VS-1616 Series. It enables HDMI video and RS-232 serial control signals to be transmitted over DGKat twisted-pair cabling from the chassis to remote destinations.

• How many HDMI and RS-232 channels does it support?

  It supports two HDMI outputs and two RS-232 channels, all transmitted over DGKat cabling from the VS-1616 chassis.

• What is the maximum data rate of this card?

  Maximum data rate is 4.95 Gbps, enabling high-quality HDMI signal transmission compatible with common 1080p60 content and related formats.

• How far can signals travel over DGKat with this card?

  The system supports up to 90 meters (300 feet) at 1080p@60Hz, making it suitable for mid-to-large installations where displays or control devices are physically distant from the matrix.

• Which equipment is compatible with the DGKat-OUT2-F16?

  It is designed for use with Kramer VS-1616 Series Modular Multi-Format Digital Matrix Switchers and works in conjunction with DGKat cabling to extend HDMI and RS-232 reach.

• Can I use RS-232 control over long runs?

  Yes. The RS-232 channels provided by the card facilitate serial control of connected devices across the DGKat link, enabling centralized automation and display management as part of a networked AV installation.

• Is installation plug-and-play?

  For the most part, yes. The card is designed to integrate with the VS-1616 chassis with minimal configuration beyond routing decisions in the control software. Some setups may require RS-232 port configuration on connected devices.

• Do I need any special cables?

  You will need DGKat twisted-pair cables to connect the DGKat ports between the VS-1616 chassis and the remote receivers/displays. Use high-quality DGKat cables recommended by Kramer to ensure optimal performance over distance.

• Will this card support future HDMI formats?

  The DGKat-OUT2-F16 is designed to deliver HDMI signals over DGKat with a high data rate suitable for prevalent formats like 1080p60. For compatibility with newer HDMI specifications, verify support within the VS-1616 firmware and Kramer product guidance as part of ongoing updates.
