Description
Kramer DigiTOOLS TP-580Rxr Video Extender Receiver
The TP-580Rxr is a high-performance HDBaseT receiver designed to unlock long-distance, pristine 4K HDR playback with integrated control. Engineered for pro AV installations, this receiver brings HDMI, RS-232, and IR signals over a single CAT cable while preserving video integrity and synchronized control. Capable of delivering 4K at 60 Hz (4:2:0) with 24-bit color depth, it ensures sharp, lifelike image quality across large conference rooms, classrooms, home theaters, and performance venues. Built as part of Kramer’s DigiTOOLS family, the TP-580Rxr focuses on reliability, ease of installation, and flexible deployment, making it an essential component for modern, unified AV systems.
- Extended 4K reach over CAT cable: The TP-580Rxr extends HDMI signals over twisted pair CAT copper cables up to 100 meters (330 feet), delivering stable 4K@60Hz (4:2:0) 24bpp video to the display. This long-range capability makes it ideal for large venues, classroom setups, and multi-room installations where source devices cannot be placed near the display.
- HDBaseT receiver with multi-signal support: This receiver is built to carry HDMI video and audio, along with RS-232 and IR control signals, over a single cable. By consolidating video, control, and power-management signals, it reduces cable clutter and simplifies installation in aesthetically sensitive environments such as boardrooms or auditoriums.
- High-quality video at enterprise-friendly resolutions: The TP-580Rxr supports up to 4K at 60 Hz with 4:2:0 chroma sampling, ensuring smooth, artifact-free images for digital signage, presentations, and high-definition media playback. The 24bpp color depth provides rich color without compromising performance in professional deployments.
- Flexible integration for control systems: With RS-232 and IR passthrough, you can manage the source and display devices from the remote end. This makes it ideal for centralized AV control systems and classrooms where instructors or technicians need seamless, uninterrupted access to connected equipment.
- Professional-grade reliability for varied environments: Designed for permanent installations in corporate, educational, and entertainment spaces, the TP-580Rxr features rugged construction and a form factor suited to rack-mount or shelf-based setups, ensuring dependable performance even in demanding environments.
Technical Details of Kramer DigiTOOLS TP-580Rxr Video Extender Receiver
- Type: HDBaseT receiver for extended-range HDMI, RS-232, and IR signals
- Maximum video resolution: Up to 4K at 60 Hz (4:2:0) with 24-bit color depth
- Maximum transmission distance: Up to 100 meters (330 feet) over CAT copper cables
- Signal families supported: HDMI video + audio, RS-232, and IR control signals
- Communication technology: HDBaseT-driven extension over twisted-pair cabling
- Cable requirements: Standard CAT copper cables suitable for HDBaseT transmission
- Compatibility: Designed as part of the Kramer DigiTOOLS TP-580Rxr family for integrated system deployments
- Power considerations: Refer to product documentation for power input specifications and recommendations
- Installation environment: Suitable for professional installation in boardrooms, classrooms, venues, and home theaters
- Notes: Specifications sourced from the product line; for exact values and official sheet details, consult the supplier’s specifications section
How to install Kramer DigiTOOLS TP-580Rxr Video Extender Receiver
- Step 1: Plan the installation layout. Decide the locations for the TP-580Rxr receiver near the display and the corresponding TX unit near the source. Ensure there is a clear path for the CAT cable run and access to power outlets.
- Step 2: Connect the display. Use an HDMI cable to connect the receiver’s HDMI output to the display or projector. Verify that the display supports the intended resolution (up to 4K@60Hz) and that the input source is set correctly.
- Step 3: Prepare the control path. If RS-232 control is required, connect the RS-232 control lines between the receiver and the control system or display equipment as specified in the installation manual. Attach IR emitters/receivers if you are implementing IR control passthrough.
- Step 4: Link the transmitter and receiver. Run a CAT cable from the TP-580Rxr receiver to the corresponding TP-580Tx transmitter. Ensure the cable is rated for HDBaseT use and maintains the required length without excessive bends or interference.
- Step 5: Power up. Connect power adapters to both the transmitter and receiver (or use any recommended PoE solution if the system supports it). Turn on the source device, the transmitter, and then the display. Check for a stable video signal and confirm the RS-232/IR control paths operate as expected.
- Step 6: Configure EDID and control settings as needed. If your installation requires specific EDID behavior or control routing, access the system setup through the control processor or the projector/display’s native menus to align timing, color space, and resolutions.
- Step 7: Test in real-world scenarios. Validate 4K playback, color accuracy, and latency under working conditions. Confirm that external controls respond reliably and that any IR commands are properly relayed to the source.
Frequently asked questions
- Q: What is the maximum distance for 4K @ 60 Hz transmission with the TP-580Rxr? A: The TP-580Rxr supports extended reach up to 100 meters (330 feet) over CAT copper cables, delivering 4K@60Hz (4:2:0) 24bpp video to the display.
- Q: Which signals can be transmitted over the HDBaseT link? A: HDMI video and audio, RS-232, and IR control signals can be transmitted over the same CAT cable using the TP-580Rxr in conjunction with its transmitter.
- Q: Is EDID management supported? A: EDID handling is typically configurable through the system’s control interface or display settings; consult your installer resources for optimized EDID profiles in your environment.
- Q: Can the TP-580Rxr be used in educational or corporate venues? A: Yes. Its extended reach, multi-signal capability, and professional-grade construction make it well-suited for classrooms, boardrooms, auditoriums, and similar spaces requiring reliable long-range AV distribution.
- Q: Do I need special cables or accessories? A: Use standard HDBaseT-compatible CAT cables suitable for the installation length. Depending on your setup, RS-232 and IR accessories may be required for full control functionality.
- Q: Is power supplied to the receiver via a PoE solution? A: Power requirements are specified in the product documentation; refer to the official spec sheet for exact power input details and any PoE compatibility notes.
