Legrand Rack PDU Network Metered 1U, 16A, 208V – (8) C13, L6-20P Cord

Introducing the Legrand Rack PDU Network Metered, a compact 1U power distribution unit engineered for precision energy visibility and proactive IT power management. This Ethernet-enabled, line-level metered PDU delivers real-time load data, making it an essential accessory for data centers, server rooms, and high-density equipment racks. With a clear Color LCD display on the unit and seamless remote reporting to tablets and smartphones, it empowers IT teams to optimize capacity, minimize downtime, and optimize energy costs with confidence.

• Real-time line-level power metering: Monitor current draw, voltage, and power usage as it happens to keep critical equipment within safe operating ranges.
• Clear local visibility: Color LCD screen provides at-a-glance energy and load information right at the PDU, enabling quick decisions without interrupting network operations.
• Full remote monitoring and alerting: Configure custom notifications and user-defined conditions to stay informed about power events and thresholds anywhere, anytime.
• 1U rack-mount design with robust outlets: Accommodates eight C13 outlets and ships with an L6-20P input cord, optimized for 208V environments and up to 16A per outlet bank.
• Efficient, scalable power distribution: Ideal for growing IT environments, enabling accurate usage reporting, capacity planning, and centralized management for multiple PDUs across the data center.

Technical Details of Legrand Rack PDU

• Product type: Network Metered PDU
• Form factor: 1U rack-mountable
• Voltage: 208V
• Maximum current: 16A
• Outlets: 8 x C13 receptacles
• Cord type: L6-20P input cord
• Metering: Line-level power metering with local display
• Display: Color LCD screen for on-device visibility
• Mounting: 19-inch rack compatibility
• Monitoring: Network-enabled for remote access and reporting

how to install Legrand Rack PDU

• Power down and prepare your rack space: Ensure you have a suitable 208V power source and a clear rack area for safe installation.
• Mount the PDU in the rack: Slide the unit into a standard 19-inch rack and secure it using compatible mounting hardware or rails designed for 1U PDUs.
• Connect the input power: Attach the L6-20P input cord to a properly rated 208V power outlet that matches the PDU’s specifications, ensuring a secure connection.
• Attach equipment to outlets: Plug servers, switches, and other critical devices into the eight C13 outlets, distributing loads according to your power plan.
• Configure metering and monitoring: Use the Color LCD screen for initial setup and navigate to the network/metering settings to enable remote reporting, set alert thresholds, and customize notifications. Verify connectivity from a desktop or mobile device to confirm data is flowing to your monitoring tools.

Frequently asked questions

• What is a Network Metered PDU? A Network Metered PDU provides real-time power metering and monitoring at the line level, enabling visibility into energy usage, load, and conditions across attached devices.
• What outlets does it include? The unit ships with eight C13 outlets, suitable for common server and networking equipment in data centers and server rooms.
• What voltage and current are supported? It operates at 208V with a maximum current rating of 16A, designed for data-center-grade power distribution.
• Does it offer remote monitoring? Yes. It provides remote visibility of power usage, load levels, and configurable alerts to keep administrators informed via connected devices.
• How do I install and configure it? Mount the PDU in a 19-inch rack, connect the L6-20P cord to a 208V power source, plug devices into the C13 outlets, and use the local Color LCD or a remote interface to configure metering, notifications, and reporting.
