Marshall - 7.60 mmf/2 Fixed Lens for M12-mount

Designed for demanding industrial imaging, the Marshall - 7.60 mmf/2 Fixed Lens for M12-mount delivers exceptional image quality with sharp corners, minimal distortion, and reliable performance in compact camera systems. This fixed focal length lens is engineered to maximize sensor efficiency while maintaining a small footprint, making it an ideal choice for machine vision, embedded applications, and surveillance deployments. Its combination of glass optics, precision mechanical construction, and RoHS-compliant materials ensures durability and consistency across production runs, even in challenging environments.

• Unmatched edge-to-edge sharpness and low distortion: Experience crisp imaging with minimal barrel or pincushion distortion, helping you accurately measure, detect, and analyze every frame from the camera. The 7.60 mm focal length is optimized for small-format sensors common in M12-mount configurations, delivering a natural perspective that suits close-range inspection, barcode reading, and high-contrast scenes.
• Bright f/2 performance for low-light applications: The wide maximum aperture of f/2 provides generous light transmission, enabling faster exposure in dim environments without sacrificing depth of field control. This makes the lens excellent for machine vision in warehouses, process monitoring, and security systems where lighting is variable.
• Robust, compact build with tactile adjustment: The lens is housed in a compact, anodized aluminum body with a smooth tactile adjustment mechanism. This ensures repeatable focus and reliable alignment when installed on tight spaces or in rugged industrial enclosures, supporting quick field setups and repeatable calibration.
• Flexible mount options for diverse systems: While optimized for M12-mount cameras, the Marshall lens family also offers variants for CS-Mount and S-Mount interfaces. This versatility lets you pair the fixed focal length with a wide range of sensors and housings, simplifying integration across existing lines and new projects.
• Glass optics and RoHS-compliant construction: Precision-engineered glass elements deliver high-contrast imagery with consistent performance over time. The anodized aluminum housing is designed for durability, and the entire assembly complies with RoHS standards for responsible electronics manufacturing.

Technical Details of Marshall - 7.60 mmf/2 Fixed Lens for M12-mount

• Focal length: 7.60 mm
• Aperture: f/2
• Mount variants: M12-mount (primary), with CS-Mount and S-Mount configurations available for compatible models
• Optics: Glass optics
• Housing: Anodized aluminum for durability and corrosion resistance
• Compliance: RoHS compliant
• Designed for: Industrial cameras, machine vision, surveillance, and embedded imaging systems
• Key benefits: Sharp corners, low distortion, compact form factor, tactile adjustment

How to install Marshall - 7.60 mmf/2 Fixed Lens for M12-mount

Installing the Marshall 7.60 mmf/2 lens is designed to be straightforward within standard machine-vision setups. Follow these steps to ensure reliable performance and optimal image quality:

• Power down the camera or imaging device before beginning the installation to prevent damage to electronics.
• Identify the correct mounting interface for your system (M12, CS-Mount, or S-Mount) and select the appropriate variant if you are upgrading from a different interface.
• Mount the lens into the camera housing or lens adapter, threading gently until the lens seats properly. Avoid cross-threading or overtightening, which can misalign the optical axis.
• Align the lens axis with the sensor plane. If your setup uses a CS-Mount or S-Mount adapter, ensure the back focal distance is set correctly according to your camera’s focus documentation.
• Power up the device and use the camera’s focus control to achieve sharp image focus across the entire field of view. Fine-tune focus while observing a representative target or calibration chart to verify edge clarity.
• Secure any locking screws or mounting rings to lock the lens position in place. Recheck alignment and ensure there is no lens drift after vibration or temperature changes.
• Conduct a quick image quality check under typical operating conditions. If necessary, perform minor adjustments to the camera’s exposure and gain settings to maximize optical performance with the fixed focal length.

Frequently asked questions

• Q: What mount does the Marshall 7.60 mmf/2 lens support?

  A: It is designed primarily for M12-mount cameras and is also available in CS-Mount and S-Mount configurations depending on the model variant you choose.

• Q: What is the aperture of this lens?

  A: The lens features a bright f/2 aperture, which supports strong performance in low-light environments while maintaining a shallow depth of field suitable for targeted inspection tasks.

• Q: Is the lens RoHS compliant?

  A: Yes. The Marshall 7.60 mmf/2 is RoHS compliant, reflecting careful selection of materials and manufacturing processes for environmentally responsible electronics.

• Q: What applications is this lens best suited for?

  A: It is well-suited for industrial machine vision, embedded vision for robotics, quality control inspection, barcode scanning, and compact surveillance systems where space is at a premium.

• Q: How do I choose between M12, CS-Mount, and S-Mount variants?

  A: Choose based on your camera’s native interface. If you are using a compact, low-profile camera with an M12 sensor, select the M12-mount variant. For broader compatibility with standard CCTV or machine-vision housings, CS-Mount or S-Mount variants are available. Always confirm the back focus and thread type before purchasing.
