Description
Mellanox Rack Mount for MSN2410 Network Switch – 1U Short Depth Rack Kit
The Mellanox Rack Mount for MSN2410 Network Switch is a purpose-built rack installation kit that secures MSN2410 series short depth, 1U wide systems into standard depth racks. This kit is engineered to streamline deployment in data centers and network closets, delivering precise fit, solid support, and clean cable management. Built to endure the rigors of busy environments, it helps maximize rack space utilization while ensuring reliable performance and easy maintenance for your Mellanox networking hardware.
- Compatibility and fit: Specifically designed for MSN2410 series short depth 1U wide systems, providing a snug, secure attachment to standard 19-inch racks. The design focuses on minimizing movement and vibration while preserving easy access for service or upgrades, helping technicians install and service equipment faster.
- Rack compatibility: Compatible with standard depth racks commonly deployed in data centers and network rooms, enabling seamless integration with existing infrastructure. This compatibility reduces the need for custom mounting solutions and simplifies rack management across multiple devices and vendors.
- Durable construction and support: Constructed from sturdy materials to withstand the weight of network switches and cabling, providing reliable long-term support in busy environments. The rugged build resists wear from repeated slide-ins and removals, contributing to a stable mounting solution over the device lifecycle.
- Space-efficient design and airflow considerations: Optimizes vertical rack space while accommodating the 1U height and the MSN2410’s compact depth, supporting clear airflow paths and easier cable routing. This design helps maintain proper cooling performance and reduces thermal impact on adjacent equipment.
- Cable management and serviceability: Includes structured pathways and accessible mounting points to organize power and data cables, simplify maintenance, and accommodate future reconfigurations. A tidy cabling layout minimizes interference and makes inspections quick and straightforward.
Technical Details of Mellanox Rack Mount for Network Switch
- Product type: Rack installation kit
- Designed for: MSN2410 series short depth 1U wide systems
- Rack compatibility: Standard depth racks
- Height form factor: 1U
- Construction: Metal rack mount framework designed to support weight and provide durability
how to install Mellanox Rack Mount for Network Switch
Step 1 — Prepare the rack: Confirm that your rack is a standard 19-inch rack with adequate depth for the MSN2410 unit and the mounting kit. Clear the mounting area and verify that the rails and hardware are compatible with the rack’s posts and mounting holes.
Step 2 — Attach mounting rails: Align the rack mount rails with the front and rear mounting holes on the rack. Secure the rails using the included hardware, ensuring they are level and firmly tightened to prevent any play or misalignment during installation.
Step 3 — Secure the MSN2410 switch: With the rails in place, position the MSN2410 short depth 1U wide switch into the rack mount kit. Carefully guide it into the rails and ensure that the device is seated squarely and securely within the mounting framework.
Step 4 — Route cables and power: Arrange power, network, and management cables along the cable management features of the kit and rack. Maintain clean, unobstructed airflow by avoiding sharp bends and overcrowding, and leave sufficient space for intake and exhaust around the switch.
Step 5 — Final checks and test: Tighten all mounting hardware to specification, verify that the switch is stable, and perform basic connectivity checks to ensure proper function after installation. Confirm that cables are labeled and accessible for future maintenance.
Frequently asked questions
-
Q: Is this rack mount compatible with the MSN2410 network switch?
A: Yes, the kit is designed specifically for MSN2410 series short depth 1U wide systems and is intended to fit standard depth racks.
-
Q: What rack types does it fit?
A: It is designed for standard depth racks commonly used in data centers and network closets; check your rack specifications to ensure compatibility with depth and mounting hole spacing.
-
Q: What is the form factor of the mounted device?
A: The installation kit supports a 1U height for the MSN2410 switch, enabling compact, space-efficient deployment in 19-inch racks.
-
Q: Are hardware components included?
A: The product description notes it as a rack installation kit; for precise hardware contents, refer to the packaging or official documentation accompanying the kit.
-
Q: Can I mount other equipment with this kit?
A: The kit is specifically designed for MSN2410 series short depth 1U wide systems; compatibility with other devices may vary and should be verified with Mellanox documentation or a technical specialist.
