Middle Atlantic AX-SX Rack Frame (29U, 19" x 20")

Designed for professional AV and IT environments, the Middle Atlantic AX-SX Rack Frame delivers robust, adaptable rack storage that helps you organize heavy equipment with confidence. With a 29U rack height, a standard 19" rack width, and a 20" depth, this black steel frame is built to support a wide range of gear—from servers and network appliances to AV receivers and power distribution units. The AX-SX is crafted to maximize space, improve airflow, and simplify installation in both compact rooms and larger rack enclosures. If you’re seeking a reliable foundation for your equipment rack that blends durability with a clean, professional look, this frame is a practical choice that scales with your system as it grows.

• The AX-SX Rack Frame provides a sturdy 29U vertical space and standard 19" mounting compatibility, allowing you to house multiple devices in a single, secure chassis. This setup is ideal for data centers, audio-visual installations, broadcast environments, and technical rooms where organized, accessible equipment is essential.
• With a 20" depth profile, the frame accommodates a wide range of rack-mountable gear while maintaining manageable footprint in spaces with limited room to spare. The deeper profile supports larger switches, uninterruptible power supplies (UPS), and other rack-mounted devices without compromising clearance for cabling and ventilation.
• Constructed from durable steel and finished in black, the AX-SX frame delivers the strength needed to hold substantial loads—up to 650 lb—while resisting daily wear and tear. The powder-coated exterior provides a professional appearance and helps resist scuffs, scratches, and corrosion in busy environments.
• Designed for practical organization, this rack frame supports efficient cable management and tidy equipment layouts. The rigid frame works with accessories from the Middle Atlantic AX series and other 19" components, enabling cleaner Power, AV, and data pathways. The result is easier maintenance, improved airflow, and a more professional presentation for clients or stakeholders.
• Trusted by integrators and technicians, the AX-SX combines reliable construction with a brand reputation built on precision engineering and service. Its proven performance under demanding workloads makes it a dependable base for mission-critical gear, ensuring your investment remains stable through upgrades and reconfigurations over time.

Technical Details of Middle Atlantic AX-SX Rack Frame

• Dimensions: 29U rack height x 19" rack width x 20" rack depth
• Weight capacity: up to 650 lb maximum load
• Material: Steel
• Finish: Black powder-coated
• Compatibility: 19" rack-mount devices; suitable for standard 19" equipment racks
• Design notes: External-style rack frame intended to provide a solid mounting platform suitable for a variety of AV and IT gear

How to install Middle Atlantic AX-SX Rack Frame

• Prepare your installation space: Confirm there is a suitable 19" rack opening and a stable surface to support the AX-SX frame. Clear the area of debris and ensure ventilation around the rack to promote airflow for heat-sensitive equipment.
• Position the frame: Slide or place the AX-SX rack frame into your rack enclosure, aligning it with the mounting rails. Ensure there is adequate clearance at the top, bottom, and sides for cables and hot air to move freely.
• Secure the frame: Use the appropriate screws or mounting hardware designed for 19" rack installations to fasten the AX-SX frame to the rack or cabinet. Tighten hardware evenly to prevent warping and to maintain level alignment across the rack face.
• Arrange equipment and cabling: Begin mounting your equipment from the bottom up to distribute weight evenly. Use standard 19" rack ears and accessories as needed. Plan cable routes and tie-downs to minimize tangling and improve airflow; group related cables for easier future maintenance.
• Test and verify: Re-check that all devices are securely fastened and that cables are not under tension. Verify that the total load remains within the 650 lb capacity and ensure sufficient clearance around devices for cooling and service access. Close the rack enclosure if applicable and perform a brief functional test of powered equipment.

Frequently asked questions

• Q: What is the weight capacity of the AX-SX Rack Frame? A: The AX-SX rack frame supports up to 650 pounds, providing a sturdy foundation for servers, switches, AV gear, and other rack-mount equipment.
• Q: What are the key dimensions of this rack frame? A: It offers 29U of vertical space, with a 19-inch rack width and a 20-inch depth, sized to accommodate a wide range of standard 19" equipment.
• Q: What material and finish are used? A: The frame is constructed of steel and finished in black powder coating for durability and a professional appearance.
• Q: Is this frame compatible with all 19" equipment? A: Yes, the AX-SX is designed to support standard 19" rack-mounted hardware, making it suitable for typical data, AV, and telecom gear.
• Q: How does the AX-SX improve space and organization? A: By providing a robust, organized platform with ample depth and height, it helps distribute weight efficiently, streamline cable management, and maintain clean, accessible equipment layouts in racks and cabinets.
