Middle Atlantic AX-SXR Rack Frame — 22U x 19" x 20" Black Steel

Elevate the organization and reliability of your network, AV, and pro-audio gear with the Middle Atlantic AX-SXR Rack Frame. Built for demanding environments where space is precious and equipment demand is high, this rack frame delivers solid performance without compromising accessibility. With 22U of mounting space, a standard 19" rack width, and a compact 20" depth, it strikes a balance between capacity and footprint—perfect for control rooms, broadcast suites, post-production editing bays, data centers, and IT closets. The AX-SXR is crafted from durable steel and finished in a professional black powder coat, giving you a resilient, professional look that fits seamlessly into any rack or enclosure. Designed with reliability in mind, it provides stable support for servers, switches, patch panels, power distribution units, audio processors, and other 19" equipment, while keeping cabling organized and airflow unblocked. Whether you’re expanding an existing rack, building a compact studio rack, or consolidating gear in a budget-friendly solution, the AX-SXR helps you maximize space, minimize clutter, and simplify maintenance by offering clear access to front and rear equipment. In environments ranging from corporate AV rooms to live event venues, this rack frame helps you optimize cable routing, reduce vibration, and improve cooling efficiency, ensuring your gear operates at its best for longer lifespans and fewer downtime events.

• 22U of mounting height provides ample room for growth, stacked equipment, and future upgrades without crowding the rack interior.
• Standard 19" rack width guarantees broad compatibility with a wide range of 19" equipment, from patch panels to rack-mounted servers and audio processors.
• 20" overall depth offers a compact footprint that fits tight spaces while still accommodating deeper devices and cabling behind the rack rails.
• Heavy-duty steel construction with a black powder-coated finish delivers long-term durability in busy sites, studios, or broadcast racks.\u00a0The finish resists scuffs, corrosion, and daily wear from equipment installation and rearrangements.
• High weight capacity up to 450 lb means you can mix heavier devices with lighter components without compromising frame stability or safety.

Technic Details of Middle Atlantic AX-SXR Rack Frame

• Height: 22U
• Width: 19 inches
• Depth: 20 inches
• Material and Finish: Steel with durable black powder coat
• Maximum weight capacity: 450 lb

how to install Middle Atlantic AX-SXR Rack Frame

• Assess your space and verify that the AX-SXR’s dimensions fit within your rack cabinet or stand-alone rack enclosure, ensuring there is adequate clearance for cable management, airflow, and door access.
• Position the rack frame inside the enclosure and align mounting holes with existing rails or securing points. Use appropriate screws, cage nuts, or mounting hardware compatible with your rack system.
• Secure the frame firmly to the rack structure, making sure it sits level and stable before adding equipment. Re-check after mounting the initial devices to confirm alignment and support.
• Begin installing equipment using the heaviest items first to maintain balance and prevent tipping during load distribution. Plan cable routing behind and between devices to preserve airflow and simplify future maintenance.
• Connect power and data cables with care, employing cable managers, ties, and labels to keep the interior tidy. Leave space for air circulation and consider adding ventilation or blanking panels if required to optimize cooling.

Frequently asked questions

• Q: What equipment will fit in the AX-SXR rack frame? A: The AX-SXR is designed for standard 19" equipment and supports up to 22U of mounting height with a depth of 20", making it suitable for servers, switches, patch panels, audio processors, and other 19" devices commonly used in AV, IT, and pro audio environments.
• Q: How much weight can the AX-SXR hold? A: The frame supports up to 450 lb of equipment, providing robust support for mixed-load configurations while preserving rack integrity and safe operation.
• Q: What finish does the AX-SXR have? A: It features a durable black powder-coated steel finish designed to withstand daily use, resist scratches, and maintain a professional appearance in busy racks and studios.
• Q: Is the AX-SXR compatible with existing rack rails and accessories? A: Yes. Its standard 19" width aligns with most rack rails, panels, and accessories, enabling easy integration with your current setup and future expansion.
• Q: Can I install the AX-SXR in a standalone rack or in a cabinet? A: The AX-SXR is suitable for both standalone rack frames and enclosed rack cabinets that support 19" equipment and 22U height, allowing flexible placement in studios, data rooms, or residential setups.
