Middle Atlantic DWR Series 12RU Pivoting Wall Mounted Rack - 22in Depth Wall Mounted Cabinet
The Middle Atlantic DWR Series Pivoting Wall Mounted Rack represents a premium, space-saving solution for professional AV and IT environments where accessibility and reliability are non-negotiable. This 12RU, 22-inch-deep wall-mounted cabinet is designed to maximize mounting capacity both on and off the rail, delivering flexible configurations that adapt to evolving gear footprints. With Forward rack rail compatibility and Lever Lock security, you can shop with confidence knowing you’ll achieve secure, tool-free installations that go together in minutes rather than hours. The DWR series is built to streamline installation workflows, offering a robust ecosystem of tool-free accessories that accelerate rack builds by up to five times, while maintaining clean cable management and improved airflow for critical equipment. Whether you’re outfitting a compact control room, a broadcast booth, a data closet, or an academic AV suite, the DWR Series brings together durability, versatility, and speed to help you deploy, service, and scale with ease.
- Forward rack rail compatibility and Lever Lock security provide maximum mounting capacity on and off the rails. This enables quick, tool-free transitions between on-rail and off-rail configurations, simplifying maintenance and gear upgrades while preserving secure mounting for every component.
- Tool-free accessories ecosystem accelerates installations. From mounting kits to cable management options, the DWR line is designed to reduce field time, minimize intrusive hardware, and streamline service calls, so technicians can complete complex rack builds in a fraction of the traditional time.
- Generous 12RU capacity supports a broad range of equipment. With ample vertical space, you can house patch panels, switches, compact servers, media encoders, and related devices in a tidy, accessible layout that respects air flow and heat dissipation.
- Deep 22-inch cabinet depth accommodates deeper gear and provides extra space for cabling behind the front-facing equipment. This depth, combined with thoughtful cable routes, helps you maintain clean, organized back-of-rack pathways and reduce tension on connectors.
- Pivoting design enhances serviceability. The pivot mechanism allows wide access to both front and rear gear, facilitating quick upgrades, inspections, and cable management without removing equipment from the rack or disassembling cabinets.
Technical Details of Middle Atlantic DWR Series 12RU Pivoting Wall Mounted Rack - 22in Depth Wall Mounted Cabinet
- Capacity: 12RU of usable mounting space for versatile equipment configurations.
- Depth: 22 inches, offering substantial clearance for deeper hardware and rear cable routing.
- Mounting type: Pivoting wall-mounted cabinet designed for both on-rail and off-rail deployment.
- Compatibility: Forward rack rail compatibility and Lever Lock support for secure, flexible mounting and quick service access.
- Accessories: Wide range of tool-free accessories built to speed installation and simplify ongoing maintenance.
How to install Middle Atlantic DWR Series 12RU Pivoting Wall Mounted Rack
- Plan the installation by selecting a suitable wall location with adequate structural support to bear the combined load of the cabinet plus mounted equipment. If mounting on drywall, locate studs and use appropriate anchors or fasteners rated for the expected weight. For concrete or masonry walls, use the correct anchors and masonry screws as specified by the hardware kit accompanying the rack.
- Prepare the DWR cabinet and rails according to the manufacturer’s guidelines. If you intend to use Forward rail configuration, align the rails with the cabinet’s mounting points and attach them securely to the wall or studs. Confirm that the pivot mechanism clears surrounding equipment and that there is sufficient clearance for hinge travel when opened.
- Mount the cabinet to the wall with the rails in the correct orientation. Ensure the assembly is plumb and level to prevent misalignment of equipment, improve cable management, and ensure the locking mechanism engages properly. Tighten mounting hardware to the specified torque without over-tightening.
- Install and organize equipment inside the cabinet. Begin with larger or heavier devices at the bottom to maintain a stable center of gravity, then add patch panels, switches, and smaller devices. Use the tool-free accessories to route cables neatly, separate power and data runs, and secure any reversible brackets as needed for future upgrades.
- Route power and data cabling with attention to airflow and heat dissipation. Leave sufficient space behind front-mounted equipment for air circulation and cooling, and utilize the lever-lock or forward-rail features to facilitate quick service access. Perform a final check of door operation, pivot action, and locking mechanism before powering up the system.
Frequently asked questions
- Q: What does DWR stand for in Middle Atlantic’s product line? A: DWR refers to Middle Atlantic’s wall-mount rack line featuring pivoting design and compatibility with forward rail systems, delivering flexible mounting options and streamlined service access.
- Q: How much equipment can I fit in a 12RU DWR rack? A: The 12RU capacity supports a range of AV and IT devices, including patch panels, switches, compact servers, and related gear. Exact capacity depends on the depth, width, and spacing requirements of each component.
- Q: Is the cabinet suitable for tight spaces? A: Yes. The pivoting wall-mounted design is intended to maximize accessibility in compact areas, making maintenance and upgrades easier without disassembling gear.
- Q: Can I use tool-free accessories with other racks? A: Tool-free accessories are designed to integrate with the DWR series to speed installation. Compatibility with other rack systems varies, so refer to the manufacturer’s documentation for cross-compatibility.
