Middle Atlantic L5 Series Flat Frame IL5-FLATFR-WS23 — 23" W, 1 Bay

The Middle Atlantic International L5 Series Flat Frame IL5-FLATFR-WS23 is a premium, 23-inch wide, one-bay frame designed to anchor professional AV, IT, and broadcast installations with strength, modularity, and style. Built on a robust steel frame, this flat frame is purpose-built for Frame to Furniture integrations, offering clean integration with furniture and cabinetry while delivering industrial-grade performance. With a 200 lb weight capacity, it supports a wide range of gear, from network switches and media encoders to compact AV receivers and power distribution solutions. The IL5-FLATFR-WS23 combines durable construction, replaceable panels, and ready-to-install convenience, making it a dependable backbone for professional environments where reliability and speed matter. Its sleek black finish adds a professional aesthetic to any control room, rack room, or home theater cabinet, while its modular design enables quick configuration changes as your system evolves.

Designed to simplify installation and serviceability, this frame is part of Middle Atlantic’s Frame to Furniture philosophy, which emphasizes quick panel changes, tool-free upgrades, and a seamless transition between equipment and finished furniture. The flat-frame architecture minimizes depth while maintaining robust support, giving installers an elegant, low-profile mounting solution that stays out of the way of critical hardware. IL5-FLATFR-WS23 is engineered to ship assembled, so you can bring it directly into the shop or onto the job site and integrate it with confidence—reducing field labor and downtime without compromising on structural integrity or access to mounted gear.

• Frame to Furniture integration: Specifically designed to pair with Middle Atlantic’s Frame to Furniture ecosystem, this flat frame delivers a cohesive, professional look. Panels are replaceable, enabling fast customization and serviceability without disassembling the entire system.
• Compact, sturdy 23" W, 1 Bay footprint: The IL5-FLATFR-WS23 provides a tight, efficient footprint ideal for console desks, media centers, and cabinet enclosures, while offering reliable support for essential gear within a single bay.
• Heavy-duty steel construction with a black finish: Built to endure demanding environments, the steel frame is finished in a durable black powder coating that resists scuffs, stands up to daily use, and complements modern AV and IT installations.
• High capacity and future-ready flexibility: With a 200 lb weight capacity, this frame accommodates a wide array of equipment and can be reconfigured as your system changes, preserving investment and reducing the need for frequent replacements.
• Ships assembled and ready to install: The frame arrives ready to integrate, minimizing on-site assembly time and enabling faster project completion. Its modular design supports quick panel swaps and updates as needed.

Technical Details of Middle Atlantic International L5 Series Flat Frame

• Model: IL5-FLATFR-WS23
• Width: 23 inches (58.4 cm) overall
• Bay: 1
• Weight capacity: 200 lb (91 kg)
• Material: Steel
• Finish: Black powder-coated
• Series: L5
• Frame compatibility: Frame to Furniture
• Panels: Replaceable for quick customization and serviceability
• Assembly: Ships assembled
• Availability: Part of a three-width family within the L5 Series

how to install Middle Atlantic International L5 Series Flat Frame

• Unpack and inspect the IL5-FLATFR-WS23 to confirm model, dimensions, and finish match your project requirements. Check for any shipping damages and ensure all mounting hardware is accounted for.
• Plan the placement within your Frame to Furniture configuration. Confirm that a 23" wide, 1-bay footprint aligns with the available opening and that the surrounding furniture or cabinet provides secure support and access for maintenance.
• Position the flat frame in the designated space and align mounting points with the furniture structure or rack system. Because the frame ships assembled, you should be ready to secure it with the appropriate fasteners recommended by Middle Atlantic for the specific installation environment.
• Install replaceable panels as needed to match your equipment layout. The flat-frame design emphasizes panel interchangeability, allowing you to customize the face without disassembling the frame—ideal for frequent gear swaps or room reconfigurations.
• Mount equipment inside the frame, ensuring weight distribution does not exceed the 200 lb rating. Route cables cleanly and use cable management provisions as required by your project. Finally, verify level alignment and perform a functional check of connected devices to ensure proper operation within the Frame to Furniture ecosystem.

Frequently asked questions

• Q: What is the width and bay configuration of IL5-FLATFR-WS23? A: It is a 23" wide, 1-bay flat frame designed for the L5 Series and Frame to Furniture applications.
• Q: How much weight can the frame support? A: The frame supports up to 200 lb of equipment, assuming proper distribution and mounting per installation guidelines.
• Q: Are panels replaceable? A: Yes. The L5 Flat Frame features replaceable panels for quick customization and serviceability without extensive disassembly.
• Q: Does it ship assembled? A: Yes. The frame ships assembled and is ready for immediate integration in a shop or on-site installation, reducing labor time.
• Q: How many widths are available in the L5 Series? A: The L5 Series offers three width options to accommodate different furniture openings and rack configurations, allowing a seamless fit across various installations.
