Panasonic USB-A + HDMI + Serial xPAK Rear Expansion Module

PanasonicSKU: 6599161

Price:
Sale price$214.43

Description

Panasonic USB-A + HDMI + Serial xPAK Rear Expansion Module

Unlock expanded, turnkey connectivity for your Panasonic system with the USB-A + HDMI + Serial xPAK Rear Expansion Module. Designed to drop into the rear expansion area, this module delivers a compact, reliable upgrade path that keeps your workflow seamless, whether you’re managing presentations, control systems, video routing, or multimedia playback. Featuring USB-A at high speed (5 Gbps), HDMI 2.0 capable 4K output, and a true Serial interface, it consolidates critical ports into a single, space-efficient expansion module. User-replaceable with included screws, the xPAK Rear Expansion Module is built for quick upgrades, straightforward servicing, and minimal downtime—so you can upgrade your system without disrupting operations or adding bulky external adapters. This module is ideal for workplaces, control rooms, classrooms, and rental fleets that demand flexible, high-performance connectivity in a compact form factor.

  • The USB-A + HDMI + Serial xPAK Rear Expansion Module adds essential ports inside the Panasonic chassis, consolidating data transfer, video output, and control signaling into one clean, integrated expansion card for a streamlined workflow.
  • With USB-A 5 Gbps, you gain rapid peripheral connectivity, efficient file transfers, and reliable device compatibility for external drives, adapters, wireless dongles, and other high-speed USB accessories, all without clogging your main ports.
  • HDMI 2.0 support delivers robust 4K video output and bandwidth for modern displays and projectors, enabling crisp image quality, accurate color reproduction, and smooth, high-frame-rate playback across compatible screens.
  • The Serial interface provides true RS-232 style control connectivity, empowering integration with room controllers, automation systems, projectors, and legacy equipment that still rely on serial command sets for reliable operation.
  • Designed for easy installation, the module is user-replaceable, includes mounting screws, and fits neatly into the rear expansion area, minimizing service time and hardware clutter while preserving the integrity of your Panasonic system’s enclosure.

Technical Details of Panasonic USB-A + HDMI + Serial xPAK Rear Expansion Module

  • Interfaces: USB-A (5 Gbps), HDMI 2.0 (4K capable), Serial (True RS-232)
  • Expansion type: Rear Expansion Module designed to mount in the dedicated rear expansion area
  • Connector and form: Compact xPAK module that integrates with compatible Panasonic chassis and backplanes
  • Installation: User-replaceable with included screws; requires standard chassis access and power-down procedure
  • Compatibility: Built to integrate with Panasonic systems that support xPAK rear expansion configuration

how to install Panasonic USB-A + HDMI + Serial xPAK Rear Expansion Module

  • Power down the Panasonic system completely and unplug from the power source to ensure a safe installation environment.
  • Remove the chassis cover or access panel as required by your model, exposing the rear expansion area where the xPAK module will mount.
  • Align the xPAK module with the designated rear expansion slot, ensuring the connectors match the backplane and seating is level to avoid bent pins.
  • Secure the module with the included screws, tightening evenly to avoid warping while ensuring a solid, vibration-free fit.
  • Reconnect any external USB-A devices, HDMI cables, and serial cables to the ports on the module, then replace the chassis cover and power on the system to verify proper recognition and operation.

Frequently asked questions

  • Q: What benefits does the Panasonic USB-A + HDMI + Serial xPAK Rear Expansion Module provide over external adapters?
  • A: It offers a compact, integrated solution that lives within the Panasonic chassis, reducing cable clutter, preserving airflow, and ensuring stable connectivity with high-speed USB, 4K HDMI output, and a true serial port all from a single expansion card.
  • Q: Does the HDMI output support 4K at 60Hz?
  • A: Yes—the HDMI 2.0 interface on this xPAK module supports 4K video output, enabling high-resolution displays and smoother playback for modern presentations and multimedia use cases.
  • Q: Is the Serial port compatible with standard RS-232 devices?
  • A: The module provides a true Serial interface typically compatible with RS-232 control devices, automation systems, and legacy hardware that rely on serial communication protocols.
  • Q: Are screws included for installation?
  • A: Yes—the package includes the necessary screws for secure mounting in the rear expansion area, ensuring a straightforward, tool-assisted installation.
  • Q: Is this module user-replaceable?
  • A: Absolutely. The xPAK Rear Expansion Module is designed for user replacement, allowing quick upgrades or field maintenance without professional service in most standard Panasonic configurations.
