Panduit Mounting Clip – Beam Clamp & Conduit Clip

The Panduit Mounting Clip is a compact, high-performance mounting solution that combines a sturdy beam clamp with a snap-closed conduit clip for streamlined, space-saving installations. Designed to fit 9/16" to 3/4" flange beams and to secure 1/2" to 3/4" conduits, this side-mount mounting clip delivers dependable support with a focus on efficiency and ease of use. Whether you’re wiring panels, cabinets, or industrial enclosures, this versatile mounting clip helps you organize and route cables with precision, while maintaining a clean, professional finish. With a vertical static load capacity of 25 pounds, it’s engineered to handle a range of common electrical and mechanical installation needs without sacrificing reliability or safety.

• Flange compatibility for versatile mounting: This beam clamp is designed to fit 9/16" to 3/4" flanges, enabling secure attachment to a wide range of standard beam sizes found in commercial and industrial environments.
• Conduit support with a snap-closed clip: The integrated conduit clip accepts 1/2" to 3/4" conduits and closes with a simple snap, ensuring a reliable hold that’s quick to install and easy to adjust if needed.
• Side-mount design for flexible routing: The side-mount configuration keeps conduits and cables neatly aligned along the work plane, reducing obstruction and enabling cleaner, more accessible layouts.
• Strong vertical load capacity: With a static load rating of 25 pounds, the Panduit Mounting Clip provides dependable support for cables, conduits, and related hardware without sagging or shifting over time.
• Enhanced mounting efficiency: By combining beam clamping and conduit securing in a single, compact piece, this mounting clip saves space, minimizes assembly steps, and improves overall installation speed and reliability.

Technical Details of Panduit Mounting Clip

• Static load capacity (vertical): 25 lbs
• Beam clamp flange compatibility: 9/16" – 3/4"
• Conduit clip size: 1/2" – 3/4" (snap closed)
• Mounting orientation: Side mount
• Product type: Mounting Clip / Beam clamp with integrated conduit clip

How to Install Panduit Mounting Clip

Installing the Panduit Mounting Clip is a straightforward process designed to minimize time on site while maximizing security and performance. The steps below reflect best-practice guidelines that align with common installation workflows for electrical and mechanical enclosures. Always follow local codes and your organization’s safety procedures when performing any mounting work.

• Prepare the mounting area: Identify a suitable section of a 9/16" to 3/4" flange beam where the mounting clip will be placed. Ensure the surface is clean, dry, and free of debris that could interfere with the clamp’s grip or the conduit clip’s lock.
• Position the beam clamp: Open or loosen the clamp portion if necessary and place it over the flange, aligning the clip so that the conduit channel sits along the intended routing path. The side-mount feature should face the desired side for cable management, with the conduit clip oriented to accept the incoming conduit.
• Secure the clamp to the flange: Engage the clamp’s fastening mechanism and tighten to a secure fit. Use the appropriate fasteners recommended by your installation standards (e.g., screws or bolts appropriate for the flange material). Do not overtighten to avoid flange damage, and verify that the clamp holds firmly without slipping.
• Install the conduit: Insert the 1/2" to 3/4" conduit into the snap-closed conduit clip. Gently press until you hear or feel the locking mechanism engage, indicating a secure hold. Ensure the conduit is properly seated and aligned with the desired routing direction.
• Test and finalize: Gently apply a light load to the mounted assembly to confirm stability. Confirm that the conduit is fully secured and that the vertical load does not cause any movement beyond the expected 25 lb rating. If necessary, re-tighten fasteners and adjust the conduit clip for optimal clearance and alignment.

Frequently Asked Questions

Q: What does the Panduit Mounting Clip combine?
A: It combines a beam clamp for 9/16"–3/4" flanges with a snap-closed conduit clip for 1/2"–3/4" conduits, all in a side-mount design to maximize mounting efficiency.

Q: What is the vertical load capacity?
A: The mounting clip supports up to 25 pounds vertically, providing dependable support for cables and conduits in typical industrial and commercial installations.

Q: Which conduit sizes are compatible?
A: The snap-closed conduit clip accommodates 1/2" to 3/4" conduits, making it suitable for a broad range of standard electrical and data cabling applications.

Q: Is the clip suitable for side-mount installations?
A: Yes. The product is designed with a side-mount configuration to simplify routing, improve access, and reduce clutter around the mounted components.

Q: How does this mounting clip improve installation efficiency?
A: By integrating beam clamping and conduit securing in a single, compact unit, it reduces the number of separate components, minimizes installation steps, and helps achieve a neater, faster mounting solution that stays organized over time.
