Panduit NetKey NK688MIW-Q Punchdown Modular Insert – 25 Pack, RJ-45, Off White

Discover a scalable, tidy solution for terminating Ethernet connections with the Panduit NetKey NK688MIW-Q Punchdown Modular Insert. This 25-pack of 8-position RJ-45 modular inserts is designed to work seamlessly within Panduit’s NetKey system, delivering reliable performance, simplified installation, and a professional appearance for data centers, office networks, and commercial deployments. The NK688MIW-Q module is built for durability and long-term use, making it ideal for both new installations and upgrades where consistent, repeatable terminations are critical. With an off-white finish that blends with standard Panduit NetKey faceplates, these inserts help you achieve a cohesive, low-profile look while maintaining high network integrity. Each RJ-45 connector supports standard Ethernet requirements, enabling clean, low-latency connections for workstations, printers, VoIP phones, and network devices. Whether you’re equipping a single office or an entire building, this 25-pack provides the right balance of value and performance to keep your network edge organized and ready for growth.

• 8-position RJ-45 modular insert: Delivers 8 ports per module in a compact form, enabling efficient, high-density terminations for Ethernet networks and simplifying cable management in patch panels and wall plates.
• NetKey compatibility & design: Engineered to snap into Panduit NetKey frames and faceplates, offering a plug-and-play installation that keeps terminations aligned, secure, and easy to replace or expand.
• Bulk pack for large deployments: Comes in a 25-pack, ideal for multi-room rollouts, data centers, or facilities upgrades where uniform terminations are required across many outlets, reducing admin overhead and inventory fragmentation.
• Off-white finish for professional aesthetics: The subtle off-white color complements standard office interiors and NetKey components, helping terms remain organized while preserving a clean, professional look in network spaces.
• RJ-45 performance you can trust: Uses standard RJ-45 (8P8C) interfaces suitable for Cat5e and higher network configurations, enabling reliable, consistent connectivity and easy compatibility with a wide range of devices and switches.

Technical Details of Panduit NetKey NK688MIW-Q Punchdown Modular Insert

• Part Number: NK688MIW-Q
• Product Type: Punchdown modular insert for NetKey system
• Port Configuration: 8-position RJ-45 (8P8C) female connectors
• Pack Quantity: 25 inserts per pack
• Color: Off White
• System Compatibility: Panduit NetKey modular system (frames, faceplates, and keystone components)
• Material: Durable thermoplastic designed for field terminations
• Termination Method: Punchdown termination compatible with standard 110-style tools
• Application: Suitable for Ethernet networks, residential and commercial installations requiring organized, scalable keystone terminations

How to install Panduit NetKey NK688MIW-Q Punchdown Modular Insert

• Turn off power to any equipment in the area and ensure you are installing into a compatible NetKey frame or wall plate.
• Open the NetKey frame or faceplate assembly and locate the appropriate slot for the NK688MIW-Q module.
• Align the module with the guide rails and gently insert it into the frame, ensuring a proper seating and alignment before termination.
• Terminate all eight conductors using a standard 110-style punchdown tool, making clean, crisp connections to the 8P8C RJ-45 contacts.
• Check each termination for proper seating and ensure there are no stray wires or loose connections that could affect performance.
• Snap the NK688MIW-Q module securely into place, then reassemble the panel or cover as required and verify alignment with neighboring modules.
• Connect cables to the RJ-45 ports and perform a basic connectivity test to confirm that each outlet is functioning correctly.
• Label the outlet or port positions for future maintenance and future expansions, and keep spare NK688MIW-Q inserts on hand for quick replacements.

Frequently asked questions

• Q: What is the NK688MIW-Q used for? A: It is a Panduit NetKey 8-port punchdown modular insert designed to terminate RJ-45 Ethernet connections within the NetKey modular system, offered in a 25-pack with an off-white finish.
• Q: How many ports does each insert support? A: Each NK688MIW-Q module provides 8 RJ-45 ports (8P8C).
• Q: Is it compatible with Cat5e networks? A: Yes. The insert uses standard RJ-45 connectors suitable for Cat5e Ethernet implementations and compatible with typical office networking equipment when used with NetKey frames and appropriate faceplates.
• Q: What color is the NK688MIW-Q? A: Off White, designed to match Panduit NetKey components for a cohesive installation.
• Q: How many inserts come in a pack? A: 25 modular inserts are included per pack, making it convenient for bulk deployments and inventory management.
• Q: How do I install this insert? A: Install into a compatible NetKey frame, terminate each of the eight conductors with a punchdown tool, ensure the module seats properly, and then attach the corresponding faceplate or patch panel for testing and use.
