Panduit OM5 2f 1.6mm PC OFNR LC Dup/SC Dup Std Polarity Std IL 37m Patch Cable

This Panduit OM5 patch cable is a high-performance, data-center-ready fiber optic solution designed to deliver reliable, low-loss connectivity between network devices. Built with OM5 multi-mode fiber and a durable 1.6 mm PC OFNR jacket, this 37-meter duplex cable features LC duplex (Male) on one end and SC duplex (Male) on the other, providing flexible interconnectivity for switches, routers, patch panels, and media converters. With standard polarity and OFNR-rated construction, it offers a scalable, future-proof option for dense data-center deployments and enterprise networks that demand robust bandwidth, reduced cross-talk, and long-term reliability. Whether you are upgrading existing infrastructure or deploying a new SWDM-enabled environment, this patch cable is designed to meet the needs of modern fiber networks while staying compatible with a wide range of equipment and configurations.

• High-bandwidth OM5 multi-mode fiber combined with SWDM-ready capabilities supports wider channels and higher data throughput across 850 nm and 1310/1550 nm windows, enabling efficient 10 GbE, 40 GbE, and 100 GbE connections where SWDM is employed for greater uplink and interconnect capacity.
• Duplex LC on one end and duplex SC on the other end provides flexible cross-connect options for data-center racks, switch-to-firewall links, and patch-panel deployments. The male connectors are designed for quick insertion, secure latching, and reliable contact with minimal signal loss, reducing rework and downtime.
• 1.6 mm PC OFNR jacket offers a balance of durability and flexibility suitable for crowded cable trays and tightly routed ductwork. OFNR (Optical Fiber Non-conductive) construction ensures non-metallic, fire-safe performance appropriate for indoor riser environments and standard data-center operations.
• Standard polarity configuration ensures compatibility with typical OM5 infrastructure and fiber routing practices. It supports straightforward splicing, terminations, and device interoperability without requiring special polarity corrections, simplifying installation and future expansions.
• 37 meters (121.39 feet) in length provides ample reach for cross-rack and inter-r cabinet connections, reducing slack, easing management inside dense racks, and enabling clean deployment paths across data-center floors and equipment rooms without sacrificing performance.

Technical Details of Panduit OM5 2f 1.6mm PC OFNR LC Dup/SC Dup Std Polarity Std IL 37m

• Fiber Optic Cable Type: OM5 Multimode
• End 1 Connector: LC Duplex (Male)
• End 2 Connector: SC Duplex (Male)
• Jacket Diameter / Type: 1.6 mm PC OFNR
• Polarity: Standard
• Length: 37 m (121.39 ft)
• Fiber Count: 2-fiber
• Rating: OFNR
• Packaging: 1.0 Piece
• Application: Patch cable for network devices, switches, patch panels, and interconnects in data centers

how to install Panduit OM5 2f 1.6mm PC OFNR LC Dup/SC Dup Std Polarity Std IL 37m

Prepare the workspace by powering down equipment if possible and ensuring rubber-soled footwear and clean hands to prevent accidental contamination of connector ferrules. Plan the cable path to minimize bending and avoid sharp twists near connectors. Uncoil the cable gradually, and route it through cable trays or guides with a minimum bend radius that preserves signal integrity. On connector ends, handle LC and SC ferrules carefully to prevent micro-scratches; avoid touching the polished ends and keep the ferrule faces clean with approved fiber cleaning tools. Align the LC duplex end with the corresponding LC port on the device and gently push until the latch engages. Repeat with the SC duplex end into its corresponding port, ensuring proper polarity as standard. Secure the cable using strain relief or cable ties in a way that does not pinch or kink the fiber. Perform a basic continuity test and, if available, a connector inspection with a verification tool to confirm clean, undamaged ends before powering up the network.

Frequently asked questions

• Q: What is OM5? A: OM5 is a wideband multimode fiber designed to support higher bandwidth and shorter-wreach applications, enabling SWDM-capable networks and improved data-center performance compared to older OM3/OM4 fibers.
• Q: What connectors are on this cable? A: The cable features LC duplex (Male) on one end and SC duplex (Male) on the other, making it suitable for connecting standard LC and SC ports in data-center equipment.
• Q: Is this cable suitable for indoor use? A: Yes. The 1.6 mm PC OFNR jacket is designed for indoor riser environments, providing non-conductive, fire-safe performance in typical data-center and enterprise installations.
• Q: How long is the cable? A: The cable length is 37 meters (121.39 feet), offering sufficient reach for cross-rack deployments and flexible routing inside equipment rooms.
• Q: What is standard polarity? A: Standard polarity means the fiber and connector orientation align with typical OM5 installations, ensuring compatibility with most data-center wiring schemes without requiring reconfiguration.
• Q: Can I use this cable with SWDM-enabled devices? A: Yes. The OM5 fiber is designed to support SWDM-based high-bandwidth communication when paired with compatible transceivers and devices in the data center.
