Panduit Terminal Connector - 0.187" Female Quick Disconnect, Tin-Plated Brass with Blue Vinyl Insulation

Designed for enduring performance in challenging electrical environments, the Panduit Terminal Connector is a vibration-resistant female disconnect that combines high-conductivity brass with robust tin plating for superb electrical reliability and long-term resistance to corrosion. The blue vinyl housing not only provides excellent insulation and strain relief but also makes identification in dense wiring harnesses fast and intuitive. This terminal is engineered for practical, real-world use across automotive, industrial, and consumer electronics applications, delivering a secure connection that stays put under vibration, temperature cycling, and demanding operational conditions. Whether you’re repairing a legacy harness, assembling a new control panel, or upgrading appliance wiring, this connector offers a precise fit, strong crimp performance, and compatibility with standard 0.187" tab sizes.

• Premium materials and durability: Crafted from brass and tin-plated for exceptional electrical conductivity and corrosion resistance, the Panduit Terminal Connector minimizes contact resistance and extends the life of your wiring harness in harsh environments. The tin plating helps protect against oxidation and ensures reliable performance even after repeated thermal cycling and vibration common in automotive and industrial settings.
• Intuitive insulation and identification: The blue vinyl housing provides durable insulation and clear visual identification, helping technicians quickly locate the right terminal in complex assemblies. The insulated design also protects against accidental shorts, improves grip during crimping, and reduces the risk of wire fatigue at the crimp junction.
• Precise size and versatile wire compatibility: This female disconnect features a tab size of 0.187 x 0.02 inches (4.8 x 0.5 mm) and supports a wire range of 16-14 AWG (1.5-2.5 mm²). The combination of a standard tab profile and broad wire compatibility makes it a flexible choice for repairing or building wiring harnesses across a wide range of devices and equipment.
• Compact, space-saving form factor: With a length of 0.79 inches (20.1 mm) and a width of 0.23 inches (5.8 mm), the connector is compact enough for tight installations where space is at a premium. The streamlined profile helps maintain clean, organized harnesses, reducing interference with adjacent components and enabling easier routing in panel boards and automotive enclosures.
• Reliable performance under vibration: Engineered for vibration resistance, this disconnect maintains a secure crimp and steady electrical contact even in high-vibration environments. This makes it an ideal choice for automotive, industrial machinery, and equipment exposed to constant movement or rough handling, where dependable connections are essential for safety and functionality.

Technical Details of Panduit Terminal Connector

• Material: Brass, tin-plated for improved conductivity and corrosion resistance
• Insulation: Blue vinyl housing with barrel insulation
• Tab size: 0.187 x 0.02 inches (4.8 x 0.5 mm)
• Wire range: 16-14 AWG (1.5-2.5 mm²)
• Length: 0.79 inches (20.1 mm)
• Width: 0.23 inches (5.8 mm)
• Type: Vibration-resistant female disconnect (quick disconnect)
• Applications: Automotive wiring, appliances, industrial control panels, and other environments requiring reliable, vibration-tolerant connections

how to install Panduit Terminal Connector

Installing the Panduit Terminal Connector is straightforward when using the right tools and following best practices for crimp connections. Start by selecting a crimp tool that is rated for 16-14 AWG wires and compatible with non-insulated or insulated female disconnect terminals. Verify that you have the correct terminal size and that your wire gauge matches the 16-14 AWG range. Before you begin, inspect the conductor for any nicks or fraying; trim and re-strip if necessary to ensure a clean, undamaged conductor.

Prepare the wire by stripping an appropriate length of insulation. The exposed conductor should be clean and straight, with all copper strands neatly aligned. If you are using a blade-type crimp tool, ensure the stripping length aligns with the tool’s die specifications to yield a secure transition from conductor to crimp barrel. Insert the stripped wire fully into the terminal’s barrel until it seats against the interior stop. The insulation should extend just beyond the barrel edge to support strain relief without impeding the crimp or contact.

Crimp the terminal using the properly matched die for 16-14 AWG insulated female disconnects. Apply firm, even pressure until the crimp is fully formed, and then inspect the crimped junction for a solid, uniform bite on the conductor with no loose strands. The blue vinyl insulation should be flush with the crimp face, and the conductor should be securely captured within the barrel. A successful crimp will show no gaps between the wire, the insulation, or the terminal body, and there should be no visible copper fibers protruding beyond the crimp. If your crimp shows any irregularities, re-crimp with the appropriate tool settings or use a fresh terminal to ensure reliability in service.

Once crimped, test the connection by gently tugging on the wire to confirm a secure hold. Visually inspect for proper seating of the conductor in the barrel and verify that the insulation remains properly aligned within the blue housing. When integrating into a larger harness, route the terminal so that the ferrule, insulation, and barrel do not bear against sharp edges or powerful vibration sources. In automotive or rugged industrial environments, securing the harness with clamps or cable ties can reduce movement and further protect the integrity of the termination. By following these steps, you’ll achieve a dependable, vibration-resistant connection suitable for critical electrical circuits.

Frequently asked questions

• Q: What wire sizes does this terminal support? A: It supports 16-14 AWG (1.5-2.5 mm²) conductors.
• Q: What is the tab size of the terminal? A: The tab size is 0.187 x 0.02 inches (4.8 x 0.5 mm).
• Q: What color is the insulation, and what is its purpose? A: The insulation is blue vinyl, which provides electrical insulation, strain relief, and quick visual identification in crowded wiring harnesses.
• Q: How long and wide is the connector? A: It measures 0.79 inches (20.1 mm) in length and 0.23 inches (5.8 mm) in width, making it compact for tight spaces.
• Q: Is this connector suitable for high-vibration environments? A: Yes. It is specifically designed for vibration resistance, making it well-suited for automotive, marine, and other vibration-prone applications where reliable electrical connections are essential.
