Panduit Terminal Connector — Vibration Resistant Female Disconnect

The Panduit Terminal Connector is a purpose-built, vibration resistant female disconnect designed to deliver secure, high-integrity connections in demanding electrical environments. Crafted from brass and tin-plated for superior conductivity and corrosion resistance, this connector features a blue vinyl insulated barrel that not only helps with quick visual identification but also adds durable insulation and strain relief. With a compact form factor and precise dimensions, it fits neatly into electrical harnesses, control panels, and automotive wiring projects where space is at a premium and reliability is non-negotiable.

Built to perform in environments characterized by movement and vibration, this terminal connector maintains a solid electrical contact even when equipment vibrates, shakes, or experiences thermal cycling. The combination of robust materials, secure crimp geometry, and color-coded insulation makes it an ideal choice for engineers and technicians who demand repeatable results during assembly and maintenance. Whether you’re wiring industrial machinery, automotive harnesses, or panel-mounted controls, this Panduit terminal connector delivers dependable performance backed by Panduit’s reputation for quality in electrical connectivity.

The 0.250 x 0.032" tab size aligns with standard female receptacles, allowing for broad compatibility across a wide range of crimp-on connectors and harness systems. The connector supports wire sizes from 16 to 14 AWG (1.5 to 2.5 mm²), covering common power and control wiring needs. At 0.81" (20.6 mm) long and 0.29" (7.4 mm) wide, it provides a compact footprint that helps keep dense wiring bundles organized without sacrificing performance. The blue vinyl insulation adds an extra layer of protection against abrasion and short circuits while offering easy identification on complex wiring harnesses. In short, this Panduit terminal connector is a reliable, user-friendly solution for secure connections that stay put in high-vibration environments.

• Premium construction for demanding environments: This terminal connector uses brass as the contact material with tin plating to minimize contact resistance and resist corrosion across temperature changes, ensuring long-term reliability in harsh industrial and automotive settings.
• Vibration-resistant design for stability: Engineered to maintain a secure connection even when equipment experiences continuous movement, vibration, or mechanical stress, reducing the risk of intermittent failures.
• Wide wire compatibility: Supports 16-14 AWG wires (1.5-2.5 mm²), making it suitable for a broad range of power and control wiring applications in panels, machinery, and harness assemblies.
• Insulated, color-coded barrel: Blue vinyl insulation on the barrel provides practical insulation, helps prevent shorts, and aids in fast circuit identification during assembly and maintenance.
• Compact and precise dimensions: With a length of 0.81" (20.6 mm) and a width of 0.29" (7.4 mm), the connector fits neatly into tight spaces while maintaining solid mechanical integrity.

Technical Details of Panduit Terminal Connector

• Connection type: Vibration resistant female disconnect
• Material: Brass, tin-plated
• Insulation: Blue vinyl housing
• Tab size: 0.250 x 0.032 inches (6.3 x 0.8 mm)
• Wire range: 16-14 AWG (1.5-2.5 mm²)
• Overall dimensions: 0.81 inches long (20.6 mm), 0.29 inches wide (7.4 mm)

How to install Panduit Terminal Connector

Installing this terminal connector is straightforward and designed to provide a reliable, repeatable crimped connection when using the appropriate tools and procedures. Follow these steps to ensure best results:

• Prepare the wire: Strip insulation to expose an appropriate conductor length (typically 3-5 mm for 16-14 AWG, following tooling guidelines).
• Inspect the conductor: Check that copper conductors are clean, undamaged, and free of nicks or corrosion to ensure a solid crimp.
• Insert the wire into the barrel: Slide the stripped conductor fully into the barrel of the female disconnect until it reaches the backstop, ensuring the conductor sits properly within the crimp zone.
• Crimp with the correct tool: Use a crimping tool sized for 16-14 AWG, calibrated for the connector type, and verify that the crimp shows a solid, uniform deformation with no loose strands.
• Mate and test: Insert the crimped terminal into the corresponding 0.250" tab receptacle until seated, then perform a continuity and pull-test to confirm a secure, dependable connection.

Frequently asked questions

• Q: What wire gauges does this Panduit terminal connector accept?
  A: It supports 16-14 AWG wires (1.5-2.5 mm²).
• Q: What color is the insulation and what is its purpose?
  A: The connector features a blue vinyl insulated barrel, which provides insulation, protection against shorts, and visual identification in wiring harnesses.
• Q: What is the tab size of the connector?
  A: The tab size is 0.250 x 0.032 inches (6.3 x 0.8 mm), compatible with standard female receptacles.
• Q: Is this connector suitable for high-vibration equipment?
• A: Yes. It is specifically described as vibration resistant, engineered to maintain a secure connection under vibration and mechanical stress common in industrial and automotive applications.
• Q: What are the overall dimensions?


• A: The connector is 0.81 inches long (20.6 mm) and 0.29 inches wide (7.4 mm), offering a compact profile for tight spaces.
