Panduit Terminal Connector — Vibration-Resistant Female Brass Disconnect

The Panduit Terminal Connector provides a rugged, vibration-resistant solution for secure electrical connections in high-motion environments. This vibration‑tolerant, non‑insulated female disconnect is crafted from durable brass to deliver lasting performance in automotive, industrial, and harsh-duty applications. Designed for versatility, it accommodates common wiring gauges while maintaining a compact footprint that fits tightly engineered harnesses and panel layouts. If you need a dependable terminal that minimizes intermittent contacts caused by vibration, this Panduit connector is engineered to meet those demanding needs while delivering consistent electrical reliability and corrosion resistance.

• Vibration-resistant design: Engineered to withstand continuous mechanical movement, reducing the risk of fretting, loose connections, and intermittent power loss in environments with constant vibration, shock, or engine motion. This makes it an ideal choice for automotive harnesses, off-road equipment, marine electronics, and industrial machinery where reliability matters most.
• Durable brass construction: The non‑insulated brass body delivers excellent conductivity and structural strength, providing stable current transfer and long-term corrosion resistance. Brass also offers favorable machinability for precise tab dimensions, ensuring a snug fit with mating connectors while maintaining durability across temperature fluctuations and exposure to typical environmental contaminants.
• Precise tab geometry: Features a tab size of 0.250 x 0.032 inches (6.3 x 0.8 mm), a standard dimension that ensures broad compatibility with widely used female receptacles and mating blades in many electrical harnesses. The compact tab design supports clean routing in tight spaces without compromising crimp integrity or electrical contact area.
• Wire range compatibility: Supports 16-14 AWG (1.5-2.5 mm²) conductor sizes, covering a broad spectrum of power and signal wiring found in automotive, HVAC, equipment control panels, and industrial control circuits. This range provides flexibility for designers and technicians working on multi-gauge harnesses or retrofit projects without needing multiple termination options.
• Compact, space-saving footprint: With a length of 0.66" (16.8 mm) and a width of 0.3" (7.6 mm), this terminal fits into tight enclosures and densely packed harness assemblies. The non-insulated style offers straightforward use in environments where space is at a premium and where insulation is provided elsewhere in the circuit or enclosure.

Technical Details of Panduit Terminal Connector

• Material: Brass
• Connector type: Female disconnect
• Tab size: 0.250 x 0.032 inches (6.3 x 0.8 mm)
• Wire range: 16-14 AWG (1.5-2.5 mm²)
• Length: 0.66 inches (16.8 mm)
• Width: 0.3 inches (7.6 mm)
• Insulation: Non-insulated
• Vibration resistance: Yes
• Brand: Panduit

How to Install Panduit Terminal Connector

• Verify compatibility: Ensure the mating tab is compatible with the corresponding female disconnect and that the conductor gauge falls within the 16-14 AWG (1.5-2.5 mm²) range. Confirm the circuit design calls for a non-insulated terminal and that the environment permits a brass, non-insulated termination.
• Prepare the conductor: Strip the wire to the appropriate length for a secure crimp while avoiding nicking or damaging the conductor strands. Keep all strands untangled and neatly aligned to maximize contact area and crimp uniformity. Do not strip more insulation than required for a reliable crimp.
• Insert the conductor: Insert the stripped wire into the barrel of the female disconnect until the conductive strands are fully seated and visible at the crimp interface. Ensure there is no insulation inside the barrel and that the wire is fully seated to avoid a loose termination.
• Crimp the terminal: Use a crimping tool and the correct die setting for 16-14 AWG non-insulated brass terminals. Apply steady, even pressure to achieve a secure crimp that captures the conductor without crushing insulation or deforming the terminal. Verify that the crimp is complete and that the conductor cannot be pulled out with a moderate tug.
• Inspect and route: Visually inspect the crimp for proper compression and absence of copper deformation beyond the crimp zone. Route the terminated lead to its harness or panel location, ensuring strain-relief paths and avoiding sharp bends that could compromise the connection under vibration. Perform a light continuity check if testing equipment is available to confirm a solid electrical path.

Frequently Asked Questions

• Q: What makes the Panduit Terminal Connector vibration resistant? A: Its brass, non-insulated body and robust crimp design are optimized to reduce fretting and intermittent connections in environments with continuous vibration or shock, delivering stable electrical contact over time.
• Q: Is this terminal insulated? A: No. This is a non-insulated female disconnect, suitable for direct termination where insulation is provided by surrounding components or enclosure walls.
• Q: What wire sizes does it support? A: It supports 16-14 AWG (1.5-2.5 mm²) conductors, making it compatible with common automotive, industrial, and general electrical wiring used in harnesses.
• Q: What are the key compatibility considerations? A: Ensure the mating tab size (0.250 x 0.032 inches) matches the corresponding female receptacle, verify the enclosure or harness space allows for the 0.66" length and 0.3" width, and confirm that the environment does not require insulation directly on the terminal.
