Panduit Terminal Connector Ring Term Vinyl 22 18Awg 4 Pk100

PanduitSKU: 12737591

Price:
Sale price$76.74

Description

Experience dependable, high-performance terminations with the Panduit Terminal Connector Ring Terminal. Designed for 22–18 AWG wires, this tin-plated copper ring terminal delivers excellent conductivity, robust mechanical strength, and exceptional corrosion resistance in demanding environments—from automotive wiring harnesses to industrial control panels. This listing provides a convenient 4-pack of 100-ring terminals, ensuring you have ample inventory for large projects, fleet maintenance, or ongoing production runs without frequent reordering. The red color-coding provides quick visual identification for fast, accurate wiring work, helping you stay productive even in busy or dimly lit environments.

  • Premium tin-plated copper for reliability: Tin plating offers superior conductivity and enhanced corrosion resistance, ensuring a long service life even in humid, exposed, or vibration-rich settings. The material combination creates a stable electrical connection that resists oxidation and maintains a low contact resistance under temperature changes and repeated crimping cycles.
  • Color-coded for quick size identification: Red color-coding helps technicians distinguish size quickly, reducing the chance of mismatches during complex wiring harnesses and multi-terminal installations. This feature is especially valuable on automotive and general electrical projects where time is of the essence.
  • Consistent crimp performance for secure connections: Each terminal is engineered to deliver uniform crimping results—forming a solid mechanical bond and a reliable electrical path that stands up to routine maintenance, vibrations, and occasional tugging on harnesses.
  • 4-pack of 100 terminals for cost efficiency and ready inventory: This bulk configuration ensures you’re prepared for large-scale installations, fleet servicing, or manufacturing environments, minimizing downtime and procurement hassles. The 4×100 setup provides a steady supply to keep projects moving quickly without frequent reorders.
  • Broad compatibility and versatile applications: Ideal for automotive wiring, electrical panels, control systems, and general-purpose wiring where a sturdy, ring-style terminal is needed to fasten conductors to studs or bolts. Suitable for a wide range of harness designs and panel configurations, these terminals are a trusted choice for professional electricians and DIY enthusiasts alike.

Technical Details of Panduit Terminal Connector

  • Product type: Ring Terminal
  • Material: Tin-plated copper
  • Color: Red (size identification)
  • Pack size: 100 pieces per pack (4-pack in this listing)
  • Brand: Panduit
  • Termination: Crimp-on ring terminal
  • Recommended usage: General electrical, automotive, and industrial wiring
  • UPC/SKU: Not provided

How to install Panduit Terminal Connector

  • Prepare the wire: Use a wire stripper to remove the correct length of insulation, exposing only the conductor you intend to terminate. Ensure there are no stray strands that could cause a poor crimp.
  • Inspect the conductor: Check for frays, nicks, or damaged insulation near the stripped end. If present, trim and re-strip to maintain a clean termination surface.
  • Insert the wire into the terminal: The stripped conductor should insert fully into the barrel of the ring terminal with no exposed conductor beyond the crimp area. Ensure the wire sits properly and touches the back of the barrel.
  • Choose the proper crimping tool: Use a crimping tool that matches the terminal size and type, applying even, steady pressure to form a tight, uniform crimp. A quality tool helps achieve consistent crimp heights and secure electrical contact.
  • Crimp and inspect: Perform the crimp and then gently tug on the wire to verify a secure hold. Confirm that the terminal barrel collapses evenly and there are no gaps or loose strands. Inspect visually for a clean, solid crimp profile and test continuity if necessary.
  • Final checks: After crimping, ensure the ring is properly aligned with the stud or bolt, and tighten to the manufacturer's recommended torque specification if applicable. Verify there is no insulation bite into the conductor and that the connection remains secure during vibration or movement.

Frequently asked questions

  • Q: What wire sizes are compatible with these ring terminals?
    A: They are designed for 22–18 AWG conductors, making them suitable for a broad range of small to mid-size wiring tasks, including automotive and general electrical harnesses.
  • Q: What does the red color coding indicate?
    A: The red color is used for quick size identification, helping installers distinguish this terminal size at a glance and reduce the risk of mismatches during wiring.
  • Q: Are these tin-plated terminals corrosion resistant?
    A: Yes. The tin plating on copper provides excellent conductivity and enhanced corrosion resistance, contributing to longer service life in challenging environments.
  • Q: How many terminals are included in this pack?
    A: The listing comprises four packs of 100 terminals each, for a total of 400 terminals, designed to support large-scale projects and ongoing maintenance needs.
  • Q: Is a specific crimping tool required?
    A: A crimping tool that matches the terminal size (and type) is recommended. Use even, steady pressure to achieve a tight, uniform crimp and to maintain a strong mechanical and electrical bond.
