Panduit Twin-70 Base Coupling

PanduitSKU: 12755863

Price:
Sale price$87.14

Description

Panduit Twin-70 Base Coupling

The Panduit Twin-70 Base Coupling is a versatile, modular conduit fitting designed to streamline the distribution of power and data in commercial and industrial installations. Built to support Panduit’s Twin-70 system, this base coupling helps keep electrical and data pathways organized, compliant, and easy to service. It features T-70 tee divider inserts that separate power and data within the tee fitting, a transition fitting to connect to LD profiles or T-45 raceways, and a complete set of corners, end caps, and base and cover couplers. With these components, installers can maintain the critical 1" minimum bend radius required by TIA/EIA standards while achieving flexible routing, quick reconfigurations, and reliable operation in tight spaces. Whether upgrading a data center, an office environment, or manufacturing floor, the Twin-70 Base Coupling provides a cohesive, scalable solution that reduces complexity and improves overall installation quality.

  • Power and data separation: The T-70 tee divider inserts are designed to partition power and data within the tee fitting, helping minimize electrical interference, reduce crosstalk, and protect data integrity across runs.
  • Transition versatility: A transition fitting is included to connect to any LD profile or T-45 raceway, enabling flexible routing across different wall thicknesses and mounting surfaces without sacrificing alignment or support.
  • Comprehensive accessory set: The Twin-70 Base Coupling includes inside and outside corner fittings, end caps, and base and cover coupler fittings, allowing you to complete corners, terminations, and transitions in a single, cohesive system.
  • Code-compliant performance: Engineered to maintain the TIA/EIA-required 1" minimum bend radius, this coupling helps installers meet strict industry standards while avoiding cable stress and signal degradation at bends.
  • Installation efficiency and maintainability: The modular design reduces field labor, simplifies future reconfigurations, and streamlines spare-parts management by keeping essential components within a single, compatible family.

Technical Details of Panduit Twin-70 Base Coupling

  • Fittings included: T-70 tee divider inserts separate power and data within the tee fitting; transition fitting to LD profile or T-45 raceway; inside and outside corner fittings; end caps; base and cover coupler fittings.
  • Bend radius compliance: Maintains the TIA/EIA required 1" minimum bend radius to protect cable integrity and ensure safe, reliable operation in constrained spaces.
  • System compatibility: Part of the Panduit Twin-70 family, designed to work together with LD profile channels and T-45 raceways for scalable installations and easy expansion.
  • Material and finish: Specific material composition and finish are not provided in the current product data; typical installations rely on standard engineering plastics chosen for rigidity and durability in conduit environments.
  • Application focus: Ideal for floors, ceilings, and wall-mounted runs where power and data sharing a pathway must be separated and organized with minimal footprint.

How to Install Panduit Twin-70 Base Coupling

  • Plan the layout: Before assembling, map out the run length, determine where the T-70 tee divider inserts will separate power and data, and identify where LD profiles or T-45 raceways will transition within the path. Ensure you have the full complement of corner fittings, end caps, and couplers needed for the run.
  • Prepare components: Inspect each piece for damage, confirm that the T-70 tee divider inserts fit properly within the tee section, and verify that the transition fittings align with the LD profile or T-45 raceway to be used. Keep fasteners and mounting hardware on hand to minimize interruptions.
  • Assemble the base and coupler: Install the base and cover coupler fittings around the components, ensuring that all joints have a snug, even seating. Align the tee section with the divider inserts so that power and data paths remain distinct and protected within the system.
  • Install transitions and corners: Attach the transition fitting to the LD profile or T-45 raceway, then secure inside and outside corner fittings as needed to navigate corners and edges. Place end caps at the terminal ends to seal the run against dust and moisture ingress.
  • Finalize and verify: Once all sections are joined, re-check the entire path for proper alignment and bend radii, confirm that the TIA/EIA guidelines are met, and perform any required tests (mechanical fit, continuity checks, or insulation verification) according to local codes and company standards.

Frequently Asked Questions

  • Q: What is Panduit Twin-70 Base Coupling? A: It is a modular conduit fitting set designed to route power and data with separation and transition options for LD profiles and T-45 raceways.
  • Q: Does it maintain a 1" minimum bend radius? A: Yes, the design adheres to the TIA/EIA requirement for bend radius, helping to preserve cable integrity in tight spaces.
  • Q: What fittings are included? A: The package includes T-70 tee divider inserts, a transition fitting to LD profile or T-45 raceway, inside and outside corner fittings, end caps, and base and cover coupler fittings.
  • Q: Is installation complicated? A: The Twin-70 Base Coupling is designed for modular, straightforward installation with standard tools, and its components are intended to simplify reconfigurations and future upgrades.
  • Q: Who should use the Twin-70 Base Coupling? A: Electricians, data installers, and facilities engineers who need a unified system to route power and data along shared pathways in commercial and industrial environments.
