Description
Planar Wall Mount for Video Wall - TAA Compliant
Elevate your video wall installations with a purpose-built Planar wall mount engineered for Planar VM Series displays in landscape orientation. This mount combines robust engineering with user-friendly features to deliver rapid deployment, rear-access serviceability, and precise alignment for seamless, high-impact visuals. Built to meet government procurement standards, it’s TAA compliant and ships with a universal hardware kit for versatile compatibility across diverse VM configurations.
- Landscape-only design tailored to Planar VM Series displays, ensuring optimal balance, stability, and visual alignment across large-format video walls. The mount’s geometry is optimized to maintain a clean, uninterrupted bezel-to-bezel presentation while supporting consistent image quality across the entire wall.
- Spring-loaded scissor extension provides smooth, controlled reach from the wall, enabling quick access to rear cables and components without removing the displays. This feature minimizes downtime during maintenance, replacements, or upgrades while preserving wall integrity.
- Integrated service kickstand offers a secure, temporary support for the display when it is detached from the wall, allowing technicians to access connectors and hardware safely. This reduces handling risk and accelerates servicing tasks in busy installation environments.
- Precise lateral alignment capability ensures that adjacent screens sit in perfect alignment, preserving a uniform, professional look across multi-panel video walls. This feature helps prevent gaps or misalignment that can detract from the viewing experience.
- Ships with a universal hardware kit for straightforward installation and broad compatibility with Planar VM Series models and related mounting patterns. The kit simplifies procurement and reduces the need for multiple, model-specific fasteners.
Technical Details of Planar Wall Mount for Video Wall - TAA Compliant
- Compatibility: Designed for Planar VM Series displays in landscape orientation, providing a secure mounting solution that aligns with Planar’s engineering standards.
- Mounting type: Wall-mount system with spring-loaded scissor extension to extend the display away from the wall for easy rear access and servicing.
- Access features: Integrated service kickstand supports rear access during maintenance, enabling safer and faster component work without removing the entire wall assembly.
- Alignment: Precision lateral adjustment allows fine-tuning to achieve uniform spacing and alignment across multiple displays, contributing to a cohesive video wall presentation.
- Hardware inclusion: Includes a universal hardware kit to accommodate a wide range of mounting patterns and VM Series configurations, reducing setup complexity.
- Compliance: TAA compliant, suitable for government and regulated procurement environments.
- Build quality: Crafted from rigid, durable materials designed to withstand the demands of commercial and institutional installations and to hold heavy VM displays securely over time.
How to install Planar Wall Mount for Video Wall
Follow these general steps to install the Planar wall mount for your VM Series video wall. Prepare your workspace, verify weight ratings, and ensure you have the universal hardware kit on hand to support your specific VM model. If you are installing a full wall of displays, complete mounting one unit at a time to maintain level alignment and reduce the risk of misinstalling components.
- Inspect components and mounting hardware to confirm you have the Planar wall mount, universal hardware kit, alignment shims (if included), and all required fasteners. Confirm that the wall structure can support the combined weight of the VM displays plus the mount assembly.
- Locate optimal mounting locations on the wall using a laser or spirit level to establish a true horizontal line for the bottom edge of the first display. Mark anchor points according to the mounting pattern specified for the VM Series.
- Attach the wall plate or mounting bracket to the wall stud or masonry anchors as appropriate, ensuring the wall plate is plumb and level. Tighten fasteners to manufacturer-recommended torque values to prevent any movement after installation.
- Mount the first Planar VM display onto the wall mount carriage, then secure it with the provided hardware kit. Verify that the spring-loaded extension operates smoothly and that the display locks firmly in place with minimal play.
- Extend the scissor mechanism to create accessible clearance behind the mounted display, then route and secure cables to prevent interference with the extension. Use the integrated service kickstand to support the display if you must detach it for internal servicing.
- Repeat the process for any additional displays in the video wall, ensuring precise lateral alignment between units. Perform a final wide-screen check to confirm bezel-to-bezel uniformity, level orientation, and secure cable management.
Frequently asked questions
-
Q: Is this wall mount compatible with all Planar VM Series displays?
A: The mount is designed for Planar VM Series displays in landscape orientation. Always verify the specific VM model’s weight and mounting patterns against the universal hardware kit provided to ensure compatibility.
-
Q: Does the mount extend away from the wall for service access?
A: Yes. The spring-loaded scissor extension provides controlled extension from the wall, enabling easy rear access to cables and components without removing the display from the wall.
-
Q: What is the advantage of the integrated service kickstand?
A: The service kickstand offers temporary, secure support for the display during maintenance or component replacements, allowing technicians to work safely and efficiently without holding the display manually.
-
Q: Can I align multiple displays precisely?
A: Yes. The mount provides precise lateral alignment capability to maintain uniform gaps and level alignment across a multi-display video wall, delivering a seamless, professional appearance.
-
Q: What comes in the universal hardware kit?
A: The universal hardware kit includes fasteners and adapters compatible with a broad range of VM Series configurations, simplifying installation and reducing the need for model-specific components.
