The QXP-W6-AX200 is a PCIe Gen 2x1 Wi-Fi 6 wireless adapter with an Intel® Wi-Fi 6 AX200 module that supports the IEEE 802.11ax standard (backwards compatible with 802.11a/b/g/n/ac), MIMO 2Tx2R, MU-MIMO TX/RX and Bluetooth 5.0. The QXP-W6-AX200 can be installed in a QNAP NAS, or Windows®/Linux® PC to provide fast Wi-Fi 6 connection speeds. The QXP-W6-AX200 can also be used with Wi-Fi 6 router to deploy Wi-Fi 6 network environment. A full-height bracket is pre-installed on the QXP-W6-AX200 and two low-profile brackets are also included.
The QXP-W6-AX200 supports Wi-Fi 6 802.11ax, provides up to 2400Mbps connection speeds, and is backwards compatible with 802.11acR2/ abgn.
The QXP-W6-AX200 supports MU-MIMO 2Tx2R, providing greater connectivity with multiple clients; OFDMA increases network efficiency and decreases packet delay.
The QXP-W6-AX200 has dual band 2.4GHz/ 5GHz antennae, multiple angle tilt, and a magnetic base for the best signal strength direction and location.
The QXP-W6-AX200 supports BSS coloring that marks shared frequencies with a number for easy differentiation.
Bluetooth® 5.0 provides faster speeds and wider range to easily connect to multiple devices.
Wi-Fi 6 uses 1024-QAM to provide a signal packed with more data, and enables 25% faster data rates than 256-QAM.
2.8x Faster Connectivity
The QXP-W6-AX200 dual band Wi-Fi 6 PCIe card supports 802.11ax 160MHz dual band connectivity, 1024-QAM and up to 2400Mbps connection speed which is 2.8 times faster than Wi-Fi 5(802.11ac).
Easy Access with a Wireless NAS
With a QXP-W6-AX200 installed in your NAS, you can free yourself from Ethernet cables and access all your stored files and multimedia over a high-speed wireless connection. A full-height bracket is pre-installed on the QXP-W6-AX200 and two low-profile brackets are also included.
Easily Set Up a NAS Wireless Network Connection
After installing the QXP-W6-AX200 in your NAS, use Network & Virtual Switch or Qfinder Pro to set up the Wi-Fi connection, guest network environment or captive portal.
Use Network & Virtual Switch
Open Network & Virtual Switch: Select the designated SSID and enter the password to connect your NAS to wireless network.
Use Qfinder Pro
Open Qfinder Pro: Select the designated SSID and enter the password to connect your NAS to the wireless network.
Use Browser Station to open a captive portal
Using Network & Virtual Switch or Qfinder Pro: Select the SSID and open Browser Station to enter a password for the captive portal.
Upgrade Your Windows® or Linux® PC with High-speed Wireless Networking!
The QXP-W6-AX200 is not just for NAS, it can be installed in a Windows® or Linux® PC to provide Wi-Fi 6 connectivity for enabling faster downloading speeds and low-latency connectivity.
Dual Band Antenna with Better Wi-Fi Signals
The QXP-W6-AX200 features a new antenna design that provides better Wi-Fi signals and transmission speeds.
Supports dual band 802.11ax 2.4GHz & 5GHz and provides better signal strength compared to traditional antenna designs.
The smart antenna function provides superior WI-FI signal transmission.
The multiple angle tilt and magnetic base allows you to get the best signal strength direction and location.
Add Bluetooth 5.0 to Your Windows® PC
When installed in a Windows® PC, the QXP-W6-AX200 provides Bluetooth® 5.0 connectivity. Please note that this requires connecting the QXP-W6-AX200 to an F_USB connector on your motherboard using the included USB cable.
