Raritan MasterConsole MCD-LED17116 LCD Rack Console
Discover the unparalleled efficiency and reliability of the Raritan MasterConsole MCD-LED17116 LCD Rack Console. This 17-inch LCD rack-mounted console combines a high-contrast LED-backlit display with a built-in 16-port CAT5 KVM switch, designed for single-user operation in dense data centers, server rooms, and IT closets. The MCD-LED17116 streamlines server management by consolidating console, keyboard, mouse, and video into a compact, space-saving unit that reduces cable clutter and minimizes rack footprint. Whether you’re performing routine maintenance, BIOS-level troubleshooting, or ongoing server administration, this master console gives you fast, secure access to up to sixteen servers from a single ergonomic workstation, enabling administrators to rapidly identify issues, monitor status, and take corrective action with confidence.
- Space-saving, 17" LCD rack integration: The 17-inch LED-backlit display is integrated into a compact, slide-out rack console designed to fit standard 19" racks. This configuration preserves valuable data-center real estate while placing the administrator’s control surface at eye level for comfortable, hours-long operation. The slim profile, robust hinges, and easy-access front panel controls help technicians stay productive during busy maintenance windows.
- Powerful Cat5 KVM switching for scalable server access: With a built-in 16-port CAT5 KVM switch, you can manage up to sixteen servers from a single console. This design minimizes front-end clutter and simplifies remote connectivity—servers can be connected via Cat5/Cat5e cables to the KVM switch, enabling cross-location control without needing dedicated direct-video cables for each machine.
- Single-user workflow optimized for efficiency: The MasterConsole is engineered for a single administrator workflow, delivering fast port switching, responsive keyboard/mouse input, and straightforward BIOS-level access. This focus on one-user efficiency reduces latency when moving between servers, speeds up problem isolation, and enhances uptime by ensuring that the right server is targeted quickly and accurately.
- Clear, reliable display with LED illumination: The LED-backlit 17" LCD delivers crisp text and vivid imagery in a variety of environments—from dim data-center aisles to brightly lit data halls. High-contrast visuals improve console readability during long diagnostic sessions, while the energy-efficient LED backlight minimizes heat output and power consumption in rack deployments.
- Rugged, rack-ready design with easy maintenance: Built to endure the rigors of continuous operation, the MCD-LED17116 features a robust chassis and a user-friendly form factor that fits seamlessly into standard rack configurations. Its design supports quick installation, easy port labeling, and uncomplicated routine checks, helping IT staff maintain consistent performance across a fleet of servers with reduced risk of misconfiguration.
Technical Details of Raritan MasterConsole MCD-LED17116 LCD Rack Console
- Model: MCD-LED17116
- Display: 17-inch LED-backlit LCD
- KVM: 16-port CAT5 KVM switch for multi-server control
- User access: 1 local user
- Rack compatibility: 19" standard rack, 1U console height
- Interface options: USB keyboard/mouse; VGA video passthrough to the built-in LCD
how to install Raritan MasterConsole MCD-LED17116 LCD Rack Console
- Prepare the rack: Confirm that your equipment rack is a standard 19" rack and has at least 1U of available space for the MasterConsole. Clear the area around the installation site to ensure safe mounting and cable routing.
- Unpack and inspect: Remove all packaging, verify that the MCD-LED17116 unit, mounting rails (if included), and all accessories are present. Check for any shipping damage and ensure cables are intact before proceeding.
- Mount the console: Attach the slide-out rack rails or brackets as provided by Raritan and secure the MasterConsole in the designated 1U space. Ensure the unit sits squarely in the rack with all mounting screws tightened to specification.
- Connect servers and peripherals: Use Cat5 (or Cat5e/Cat6) cables to link up to the 16 KVM ports on the console’s switch. Connect each server’s video/keyboard/mouse paths to the appropriate ports as directed in the installation guide.
- Power and boot: Connect the MasterConsole to a reliable power source and power on the unit. Verify that the LCD powers up correctly and that the KVM switch recognizes connected servers. Label ports clearly to simplify future maintenance.
- Initial configuration: Use the local USB keyboard and mouse to configure port order, naming, and any preferred hotkeys for port switching. Test each port by selecting a server and confirming keyboard/mouse input and video output on the LCD.
- Security and maintenance: If your environment requires, configure user access controls and consider implementing tamper-evident seals or a locked rack enclosure to prevent unauthorized access. Schedule regular checks to ensure cables remain firmly seated and that firmware is up to date where applicable.
Frequently asked questions
- Q: What is the Raritan MasterConsole MCD-LED17116? A: It is a 17-inch LCD rack console with an integrated 16-port CAT5 KVM switch, designed for single-user management of multiple servers from a single, space-saving console.
- Q: How many servers can I manage with this console? A: Up to sixteen servers can be connected and controlled via the built-in Cat5 KVM switch.
- Q: What type of connections are used? A: The console uses Cat5 cables to connect to each server’s KVM port, and the local console connects via USB for keyboard and mouse input, with VGA video output routed to the 17" LCD display.
- Q: Is this device suitable for full data-center use? A: Yes, it is designed for rack environments and is ideal for data centers, server rooms, and IT closets where space efficiency and centralized server management are important. For extended management beyond local control, consider pairing with a KVM-over-IP solution if needed.
- Q: How do I ensure optimal performance? A: Keep cables organized and labeled, maintain clean power and grounding practices, regularly update any firmware or software provided by the manufacturer, and perform periodic switches test to confirm that each port operates correctly.
