Raritan PX3-1106X2-V2 12-Outlets PDU – Metered, 230V, 60A, Network-Managed

The Raritan PX3-1106X2-V2 12-Outlets PDU is a purpose-built power distribution solution designed to maximize efficiency and control in data centers, server rooms, and network closets. This metered PDU provides precise energy data, robust overload protection, and flexible installation options to support dense IT environments. With 12 IEC 60320 C19 outlets, it caters to the high-current, 230V AC requirements of modern servers, storage devices, and networking gear, while its three-phase input (IEC 60309 3P+E) and 60A capacity (3P4W) ensure reliable power delivery across multiple circuits. The PX3-1106X2-V2 is engineered for reliability in 19-inch racks and offers a combination of local metering and remote management capabilities, enabling IT staff to monitor energy usage, identify peak loads, and implement smarter capacity planning. Whether you’re upgrading a single rack or outfitting an entire data center, this PDU’s metered design, overload protection, and network connectivity deliver not only power distribution but also the visibility and control that modern IT infrastructure demands.

• 12 x IEC 60320 C19 outlets at 230V creates ample, flexible access for servers, blade enclosures, storage arrays, and other high-density IT gear, helping you optimize rack space and minimize outlet crowding.
• Metered power distribution provides real-time energy data and per-PDU measurements, enabling accurate cost allocation, trend analysis, and proactive capacity planning across your IT environment.
• Robust input and protection features IEC 60309 3P+E input with a 60A capacity (3P4W) and built-in overload protection to safeguard equipment and prevent circuit-level disruptions in busy data centers.
• Network-enabled management with an RJ-45 interface supports remote monitoring, alerting, and control through compatible management software or SNMP-enabled tools, improving uptime and operational efficiency.
• Flexible installation with a 9.84 ft (3 m) cord and rack-mountable design, including button-mount options, facilitates easy integration into standard 19-inch racks and tight IT spaces while maintaining clean cable management.

Technical Details of Raritan PX3-1106X2-V2 12-Outlets PDU

• Model: PX3-1106X2-V2
• Type: Metered PDU
• Outlets: 12 x IEC 60320 C19
• Input: IEC 60309 3P+E, 230V AC
• Current rating: 60A, 3P4W
• Cord length: 9.84 ft (3 m)
• Network interface: RJ-45 for remote management, monitoring, and alerts
• Mounting: Rack-mountable with button-mount capability for secure and versatile installation
• Protection: Overload protection to prevent damage from power surges or circuit overloads
• Standards: Compliant with IEC 60309 (input) and IEC 60320 (outlets) specifications for reliability and compatibility

How to install Raritan PX3-1106X2-V2 12-Outlets PDU

• Identify a suitable rack location that provides adequate clearance for cable management and airflow. Prepare the rack and confirm there is access to a 230V, 60A supply per your facility’s electrical planning.
• Mount the PX3-1106X2-V2 in the rack using the provided mounting hardware. Choose the preferred mounting method (traditional rack ears or button-mount) based on your rack design and serviceability needs.
• Connect the PDU input cable to a compatible 230V power source using the IEC 60309 connector. Verify that the circuit is protected by an appropriate breaker and that the supply can safely handle 60A across the three phases.
• Route and secure power and data cables to minimize clutter and ensure proper airflow. Connect IT devices to the 12 x IEC 60320 C19 outlets, distributing load evenly to prevent overload on any single outlet or circuit.
• Connect the PDU’s RJ-45 network port to your management network. Configure IP addressing and any SNMP or web UI settings required by your monitoring system, then enable alerts for overloads, thermal events, or abnormal power usage.
• Power on the PDU and verify that outlet monitoring readings appear in your management software. Test a representative load to confirm accurate metering, monitor indicators, and alert functionality. Regularly review energy usage trends to optimize capacity and identify potential savings.

Frequently asked questions

• Q: What does “Metered” mean for the PX3-1106X2-V2? A: Metered means the PDU provides real-time energy usage data and measurements for the entire unit, enabling cost allocation, performance analysis, and capacity planning.
• Q: How many outlets does this PDU have? A: It has 12 IEC 60320 C19 outlets to support a wide range of servers, storage, and network devices.
• Q: What voltage and current ratings does it support? A: The PDU is designed for 230V AC input with a 60A capacity (3P4W), suitable for high-density IT deployments.
• Q: How can I monitor and manage this PDU remotely? A: It includes an RJ-45 network interface for remote monitoring, alerting, and control via compatible management software or SNMP-enabled tools.
• Q: Is this PDU rack-mountable? A: Yes. It is designed for 19-inch racks and offers both rack-mount and button-mount options for secure installation and flexible deployment.
