Raritan PX3 42-Outlets PDU – 42-Receptacle Power Distribution with Active Metering and Superior Circuit Protection

The Raritan PX3 42-Outlets PDU is a high-density, intelligent power distribution unit designed for modern data centers, server rooms, and networking racks where reliability, visibility, and control matter most. Engineered to deliver consistent power delivery across a dense array of outlets, this PDU combines robust electrical design with advanced metering to help IT teams optimize energy use, extend equipment life, and reduce operational risk. With a NEMA L6-30P input and a balanced mix of IEC 60320 C13 and C19 outlets, the PX3 is built to handle demanding workloads while providing precise monitoring and flexible management. If you’re looking to improve data center efficiency without sacrificing power availability, the PX3 is engineered to support your goals.

• Active metering for precise energy insight: The PX3 goes beyond simple power distribution by delivering real-time measurements of voltage, current, power, and energy for every outlet and the entire bank. This enables proactive capacity planning, energy optimization, and cost containment. IT teams can track consumption trends, identify anomalous spikes, and verify the effectiveness of load-balancing strategies without leaving the data center floor.
• High-density, versatile outlet layout: The unit consolidates 42 outlets into a compact footprint: 36 IEC 60320 C13 receptacles and 6 IEC 60320 C19 receptacles. This mix provides broad compatibility for servers, storage devices, and network equipment while preserving easy cable management. The arrangement supports staged power provisioning and clean, organized cabling that reduces rack clutter and improves airflow around critical gear.
• NEMA L6-30P input for dependable single-phase power: The PX3 is designed for reliable input from a NEMA L6-30P connector, delivering robust single-phase power suitable for data center racks and equipment rooms that rely on stable, monitored power. The configuration supports smooth integration with standard data center electrical systems and ensures consistent performance even under load.
• Intelligent monitoring with remote accessibility: Beyond metering, the PX3 provides remote management options that streamline administration, enable alerts, and simplify fault isolation. When connected to the network, administrators can view live power metrics, configure alarms, and perform remote power cycling to quickly recover from issues without on-site visits.
• Enhanced protection and reliability for critical workloads: With active metering, outlet-level visibility, and built-in protection features, the PX3 helps safeguard critical devices from power disturbances. The combination of accurate measurements and responsive control helps prevent overloading, reduces the risk of downtime, and supports proactive maintenance planning.

Technical Details of Raritan PX3 42-Outlets PDU

• Model: Raritan PX3 42-Outlets PDU
• Input: NEMA L6-30P, single-phase, 30A
• Output: 42 outlets total — 36 x IEC 60320 C13 and 6 x IEC 60320 C19
• Metering: Active metering with real-time readings for voltage, current, power, and energy (per-outlet and overall)
• Management: Remote monitoring and control via standard network interface; supports alerting and event logging
• Protection and compliance: Built to meet relevant IEC/UL standards for reliability and safety; designed to protect connected equipment through monitored power delivery

How to install Raritan PX3 42-Outlets PDU

• Mount the PX3 securely in a compatible rack enclosure, ensuring there is adequate clearance for airflow and access to the IEC outlets. Verify the mounting rails are correctly aligned and tightened to prevent vibration or shift during operation.
• Connect the PDU input cord or plug to a properly rated NEMA L6-30P power source that matches your data center’s electrical distribution. Confirm that the circuit is appropriately protected by a breaker sized for the PDU’s input rating.
• Power up the PDU and connect it to your network using the available Ethernet port. Ensure the network configuration (IP address, gateway, and DNS) is set so that the PDU can be reached by your management system or DCIM tool.
• Access the PDU’s web interface or management console to configure metering thresholds, alerting policies, and outlet groupings. Enable per-outlet monitoring and set notification channels (email, SNMP, or other supported methods) to receive proactive alerts.
• Organize cabling and label each outlet group to simplify ongoing management. Validate that connected devices power on correctly and that energy readings align with expected load. Perform a controlled power cycle if needed to confirm remote control functionality and proper restart sequencing.

Frequently asked questions

• Q: What outlets are available on the PX3, and how are they arranged? A: The PX3 provides 36 IEC 60320 C13 receptacles and 6 IEC 60320 C19 receptacles, arranged to balance dense power distribution with cable management and accessibility for common rack gear.
• Q: Does the PX3 offer active metering for energy management? A: Yes. The PX3 includes active metering that reports voltage, current, power, and energy, enabling precise energy visibility and informed capacity planning.
• Q: Can I monitor and control the PX3 remotely? A: Yes. The PX3 supports network-based monitoring and remote control, allowing you to view live measurements, set thresholds, and perform remote power cycling to recover from issues without site visits.
• Q: What power input does the PX3 require? A: The PX3 uses a NEMA L6-30P input, designed for single-phase, 30A power distribution suitable for many data center environments.
• Q: Is the PX3 compatible with standard DCIM tools? A: The PX3 is designed to integrate with standard data center infrastructure management solutions, enabling centralized monitoring and alerting for power distribution across racks.
