Description
Sharp NEC Display Intel Smart Display Module (SDM)
The SDM-HDBT from Sharp NEC Display is a compact Intel® Smart Display Module designed to deliver remote video over a single CAT6 cable with outstanding reliability. Built for demanding environments and 24/7 operation, this SDM enables a truly cable-free installation in both small and large slots, simplifying deployment while preserving pristine image quality. With support for 4K at 60 Hz (4:4:4) over extended distances, up to 100 meters, this module is ideal for digital signage, control rooms, retail installations, and professional corporate environments where consistent performance and minimal downtime matter most. Optimized for seamless integration with Sharp NEC displays, the SDM-HDBT combines modular scalability, robust reliability, and top-tier video performance to power high-impact visual communications.
- Single-cable remote video solution with CAT6 support, delivering 4K at 60 Hz (4:4:4) over distances up to 100 meters for clear, life-like imagery.
- Industrial-grade components engineered for continuous 24/7 operation, ensuring reliability in mission-critical signage and control-room deployments.
- SDM form factor enables cable-free installation in both compact and large slot configurations, reducing clutter and simplifying maintenance.
- Intel Smart Display Module (SDM) technology provides scalable performance, secure updates, and straightforward management within Sharp NEC display ecosystems.
- Optimized integration with Sharp NEC displays, offering a streamlined upgrade path, consistent image quality, and reduced downtime across enterprise deployments.
Technical Details of Sharp NEC Display Intel Smart Display Module (SDM)
- Video support: 4K at 60 Hz with 4:4:4 chroma sampling.
- Transmission distance: Up to 100 meters over CAT6 cable.
- Form factor: SDM-HDBT variant designed for modular installation inside compatible Sharp NEC displays.
- Operating environment: Industrial-grade components designed for continuous, high-availability operation.
- Installation: Cable-free integration within small or large SDM slots to minimize cabling and optimize space.
How to Install Sharp NEC Display Intel Smart Display Module (SDM)
- Power down the display and disconnect from power and network resources before beginning installation.
- Open or remove the display’s back casing as required by the model’s maintenance guidelines to access the SDM slot.
- Align the SDM-HDBT module with the display’s SDM connector and slide it into the slot until it seats securely.
- Connect the remote video CAT6 cable between the SDM and the designated video source or controller per the display’s installation manual.
- Power on the display, then use the OSD or management software to configure SDM settings and verify 4K@60Hz (4:4:4) output and signal integrity for 24/7 operation.
Frequently asked questions
Q: What is the Sharp NEC SDM-HDBT?
A: The SDM-HDBT is an Intel® Smart Display Module that provides a single-cable solution for remote video within Sharp NEC displays. It is designed to deliver high-quality 4K video over CAT6 while supporting long cable runs and reliable 24/7 operation.
Q: What resolutions and distances does the SDM support?
A: It supports 4K at 60 Hz with 4:4:4 chroma sampling, using CAT6 to transmit signals up to 100 meters, making it suitable for large venue and control-room installations.
Q: Is the SDM-HDBT suitable for 24/7 operation?
A: Yes. The SDM employs industrial-grade components engineered for continuous, high-availability operation in mission-critical environments.
Q: How does installation work with different slot sizes?
A: The SDM form factor is designed for cable-free installation in both small and large slots, allowing flexibility in mounting and reducing cable clutter once installed.
Q: How do I manage or upgrade the SDM after installation?
A: The Intel SDM supports streamlined management and updates within the Sharp NEC ecosystem, with configuration options accessible via the display’s OSD or compatible management software. Regular firmware updates help maintain performance and security.
