SunBriteTV SB-CMSAK Mounting Adapter for Flat Panel Display - Black, Gray, Silver

Designed to elevate outdoor viewing experiences, the SunBriteTV SB-CMSAK Mounting Adapter is a rugged, weatherproof ceiling mount solution built to endure the elements while delivering precise, secure positioning for your flat panel display. Whether you’re mounting a bright outdoor screen for a stadium concourse, a restaurant patio, or a public venue, this swivel adapter offers smooth axis rotation with a dependable locking mechanism, ensuring optimal visibility from every seat. The SB-CMSAK is engineered to withstand rust and corrosion, so your investment remains sturdy and stylish, season after season.

• Weatherproof and rust-resistant construction: Constructed with durable materials to resist moisture, humidity, and outdoor exposure, keeping your mount looking and performing like new even in harsh conditions.
• Precise swivel with locking position: Enjoy smooth axis rotation from 0 degrees to 330 degrees with a secure lock to hold your display at the perfect angle, reducing glare and improving sightlines for all viewers.
• 3" fixed pipe; compatible with 1" NPT extension column: A robust 3-inch fixed pipe provides solid support, while the standard 1" NPT threaded extension column ensures flexible installation options for ceiling setups.
• High weight capacity: Designed to support up to 500 lbs, allowing compatibility with a wide range of flat-panel displays and outdoor TV configurations.
• Compatibility with multiple screen sizes: Suitable for use with 32", 46", and 55" displays, making it a versatile choice for SunBriteTV outdoor models and other compatible flat panels in outdoor environments.

Technical Details of SunBriteTV SB-CMSAK

• Model: SB-CMSAK Mounting Adapter
• Type: Ceiling mount swivel adapter with a 3" fixed pipe
• Finish/color options: Black, Gray, Silver (color options to match outdoor aesthetics)
• Weight capacity: Up to 500 lbs (approximately 227 kg)
• Rotation range: 0° to 330° with a locking mechanism to secure the display in place
• Extension: Attaches to a 1" NPT threaded extension column for flexible ceiling installations
• Compatibility: Designed for use with 32", 46", and 55" flat-panel displays, including outdoor SunBriteTV models
• Construction: Weatherproof and rust-resistant materials optimized for outdoor use
• Mounting interface: Ceiling-mount adapter compatible with standard ceiling installations and supporting hardware

How to install SunBriteTV SB-CMSAK

• Begin by identifying a secure ceiling structure capable of supporting the combined weight of the mount and the display. Ensure your mounting surface is compliant with local building codes and use appropriate anchors for the ceiling material.
• Attach the SB-CMSAK ceiling plate to the ceiling using the per-mounting hardware specified by the installation environment. Use level tools to ensure the plate sits perfectly horizontal to prevent uneven load distribution.
• Thread the 1" NPT extension column into the SB-CMSAK adapter. Tighten securely to avoid any wobble, then connect the 3" fixed pipe as part of the swiveling assembly for stable rotation.
• Mount the selected flat-panel display onto the adapter’s mounting interface. Align the display’s mounting holes with the adapter’s pattern, and secure it using appropriate fasteners that fit your device’s VESA pattern and weight.
• Power on the system and test the swivel action. Rotate gradually from 0° to 330° while applying light pressure to confirm smooth operation, then engage the locking mechanism to fix the screen angle when you reach the desired view.
• Perform a final safety check, ensuring all fasteners are tight and the display remains stable under routine use. Verify cable management to keep wires protected and off the rotating path.

Frequently asked questions

• Q: What is the SB-CMSAK designed for? A: The SB-CMSAK is a weatherproof ceiling mount swivel adapter designed to securely hold flat-panel displays in outdoor or challenging environments, offering a wide rotation range with a locking feature.
• Q: How wide is the rotation range? A: The adapter provides 0° to 330° of rotation, enabling flexible viewing angles from nearly any position. The lock ensures the display stays in place once you’ve chosen the ideal angle.
• Q: What is the weight capacity? A: The support capacity is up to 500 lbs, making it suitable for large outdoor displays and rugged installations.
• Q: Which display sizes can be mounted? A: It is compatible with 32", 46", and 55" flat-panel displays, particularlySunBriteTV outdoor models that require a robust ceiling-mount solution.
• Q: Is this mount suitable for harsh outdoor conditions? A: Yes. The SB-CMSAK is designed to resist rust and weather exposure, helping preserve performance and appearance in outdoor environments.
• Q: What kind of extension does it require? A: The adapter attaches to a 1" NPT threaded extension column, which provides a versatile mounting option for various ceiling heights and installation configurations.
