Transition Networks SGPAT1013-105 Transceiver/Media Converter

The SGPAT1013-105 is a high-performance Gigabit Ethernet media converter designed to bridge copper and fiber networks with ease. This device converts 10/100/1000Base-T copper Ethernet to 1000Base-SX/LX fiber, providing a robust, scalable solution for expanding network backbones or extending reach between disparate segments. Ideal for businesses that need to preserve existing copper cabling while taking advantage of modern fiber optics, the SGPAT1013-105 also injects PoE+ power through the copper RJ-45 port, enabling seamless deployment of power-hungry devices such as IP cameras, wireless APs, and VoIP phones without adding extra power runs. As a Power Sourcing Equipment (PSE) device, it ensures reliable PoE+ provisioning to attached devices, simplifying installation in edge or remote locations while maintaining centralized power control. This combination of copper-to-fiber conversion and PoE+ capability makes the SGPAT1013-105 a versatile cornerstone for mixed-media networks, data centers, and enterprise installations that demand both flexibility and efficiency.

• Gigabit copper-to-fiber versatility: The SGPAT1013-105 seamlessly converts 10/100/1000Base-T copper Ethernet to 1000Base-SX/LX fiber, enabling high-speed backbone links and extended reach between switches, servers, and storage. This copper-to-fiber bridge preserves existing copper investments while unlocking the performance and distance advantages of fiber, empowering businesses to design scalable networks that grow with their needs.
• PoE+ power on the copper port: This media converter delivers PoE+ power through the RJ-45 copper port, allowing compatible devices such as IP cameras, wireless access points, and VoIP phones to be powered directly from the network link. By consolidating data and power delivery over a single cable, the SGPAT1013-105 reduces clutter, simplifies installation, and supports energy-efficient network layouts in both office and industrial environments.
• Plug-and-play, unmanaged operation: Designed for straightforward deployments, the SGPAT1013-105 offers plug-and-play operation with auto-negotiation and auto-MDIX. No complex configuration is required—just connect the copper and fiber cables, power the unit, and establish your links. LED indicators provide at-a-glance status for link, activity, PoE, and power, helping technicians diagnose connectivity quickly.
• Robust, compact design for diverse environments: Built with a durable metal enclosure, the SGPAT1013-105 is engineered to perform in a range of settings—from desktop workstations to wall-mounted or modest rack-style deployments. Its quiet, fanless design ensures silent operation in offices or data centers, while the compact footprint makes it easy to integrate into tight spaces or equipment cabinets.
• Flexible deployment and integration: The media converter supports a variety of network architectures, enabling edge devices to connect to fiber backbones or to extend fiber corridors to access switches and core networks. Whether upgrading a campus network, enabling a remote site link, or adding a fiber extension in a data center, the SGPAT1013-105 delivers reliable performance with minimal disruption to existing cabling infrastructure.

Technical Details of SGPAT1013-105

• Model: SGPAT1013-105
• Interfaces: 1× 10/100/1000Base-T RJ-45 copper Ethernet port (PoE+ capable) and 1× 1000Base-SX/LX fiber port for 1000Base fiber connectivity
• PoE Capability: Power Sourcing Equipment (PSE) on the copper port with PoE+ power delivery to connected devices
• Performance: Unmanaged, plug-and-play operation with store-and-forward switching for reliable data integrity
• LED Indicators: Link/Activity, PoE, and Power status LEDs for quick diagnostics
• Enclosure: Compact, robust metal housing suitable for desktop, wall-mount, or limited rack installation
• Power Supply: External power input (non-exclusive to any specific power standard); designed for easy integration into standard network deployments
• Target Applications: Bridges copper-based devices to fiber backbones, powers PoE endpoints over a single cable, and supports scalable network topologies in small to mid-sized environments

how to install SGPAT1013-105

Install the SGPAT1013-105 quickly and with minimal disruption by following these straightforward steps. This process is designed to be accessible for technicians and network administrators while ensuring secure, stable connections in mixed-media environments.

Step 1: Plan the placement and cabling. Identify a suitable location near the equipment that will connect to both copper and fiber networks. Ensure the device has adequate ventilation and is protected from dust or moisture. Consider a position that minimizes cable bends and avoids strain on ports.

Step 2: Connect copper devices. Use a Category 5e/6 Ethernet cable to connect your switch, router, or other copper-based devices to the SGPAT1013-105’s RJ-45 copper port. If you are powering PoE-enabled endpoints, ensure they are within the PoE+ capability of the device and that the overall load complies with your network design.

Step 3: Connect fiber devices. Attach the appropriate fiber optic cable to the 1000Base-SX/LX fiber interface. Select the fiber type (SX for multimode, LX for single-mode) based on your link distance and fiber availability. Use the correct connector type (SC/LC) as specified by your fiber cable and the converter’s port configuration. Ensure the fiber link is clean and securely connected to maintain signal integrity.

Step 4: Apply power and verify. Connect the external power supply to the SGPAT1013-105 and plug it into a powered outlet. Once powered, observe the LED indicators: a steady link indicator on the copper and fiber ports, a PoE LED if PoE+ power is active, and a Power LED showing the device is energized. If any link is not established, recheck cable connections, port configuration (if applicable), and ensure fiber connectors are properly mated.

Step 5: Test the link and throughput. With both sides connected, test connectivity between devices on the copper side and fiber side. Perform a basic throughput and latency check to confirm the converter is properly bridging segments. If port speeds or link quality are degraded, inspect cable quality, shorten fiber spans if possible, and verify that there are no adjacent heat sources or interference on the rack or desk area.

Step 6: Maintain and monitor. Periodically inspect the LEDs and physical condition of cabling. For edge deployments with PoE devices, monitor power consumption to ensure the PoE+ budget remains within design specifications. If your network evolves, the SGPAT1013-105 can be integrated into broader transitions from copper to fiber without replacing existing network hardware—an efficient way to scale performance while preserving investments.

Frequently asked questions

• Q: What does the SGPAT1013-105 do? A: It is a Gigabit Ethernet media converter that bridges 10/100/1000Base-T copper Ethernet to 1000Base-SX/LX fiber while providing PoE+ power on the copper port, enabling power delivery to connected devices over the same cable used for data.
• Q: Does the SGPAT1013-105 support PoE+? A: Yes. The device injects PoE+ power through the copper RJ-45 port, allowing compatible endpoints to receive power directly from the network connection.
• Q: Is this device managed or unmanaged? A: The SGPAT1013-105 is an unmanaged, plug-and-play media converter designed for straightforward installation without software configuration.
• Q: What fiber types and distances are supported? A: The converter supports 1000Base-SX (multimode) and 1000Base-LX (single-mode) fiber interfaces. Distances depend on the fiber type and link length; SX typically supports shorter MMF links, while LX supports longer SMF links. Always verify the appropriate fiber type for your deployment.
• Q: Can I mount or place the converter in a rack or cabinet? A: The SGPAT1013-105 features a compact metal enclosure suitable for desktop use and compatible mounting options in various environments. Check your installation space and mounting rails or brackets to ensure secure placement.
• Q: Do I need to configure the device? A: No. As an unmanaged media converter, the SGPAT1013-105 operates in a plug-and-play mode without requiring software or complex setup. Simply connect the copper and fiber links and power the unit.
