TSItouch Touchscreen Overlay — Infrared Multi-Input Overlay for Interactive Displays

The TSItouch Touchscreen Overlay is an infrared (IR) based interactive solution designed to transform any standard display into a precise, responsive touch interface. Built with a rugged steel chassis, this overlay delivers dependable performance in high-traffic environments such as public kiosks, digital signage, classrooms, control rooms, and collaborative spaces. By leveraging infrared technology, TSItouch detects a wide range of input methods with exceptional accuracy and minimal latency, including pens, styluses, fingers, palms, and even gloved fingers. This makes it ideal for settings that require flexibility in input modalities—from precise annotation with a stylus to intuitive finger navigation during collaborative sessions. The TSItouch overlay is engineered to endure the demands of busy installations while providing a smooth, natural user experience that users expect from modern interactive displays.

• Infrared precision — high-accuracy touch sensing with low latency to deliver a natural, responsive experience across the entire display surface.
• Input versatility — detects pens, styluses, fingers, palms, and even gloved fingers, making it suitable for education, retail, healthcare, and industrial environments.
• Rugged construction — a full steel chassis and reinforced overlay designed to withstand heavy use, public exposure, and long service life.
• Seamless compatibility — engineered to integrate with a wide range of flat-panel displays, signage modules, and mounting arrangements for quick deployment.
• Effortless installation — designed for straightforward, plug‑and‑play setup with minimal maintenance and little to no calibration in many deployments.

Technical Details of TSItouch Touchscreen Overlay

• Technology: Infrared (IR) touch sensing that supports diverse input methods for versatile interaction.
• Construction: Full steel chassis with a durable overlay built to endure high-traffic environments and public usage.
• Input modalities: Works with pens, styluses, fingertips, palms, and gloved fingers for flexible operation across scenarios.
• Display compatibility: Designed to integrate with most LCD/LED displays and standard mounting solutions for signage and kiosks.
• Durability and maintenance: Engineered for long life in commercial settings with minimal calibration requirements and low upkeep.

How to Install TSItouch Touchscreen Overlay

To begin, ensure your display is clean, flat, and ready for overlay installation. Gather the supplied mounting hardware and verify you have the correct brackets or adapters for your specific screen size and VESA pattern. Begin by aligning the TSItouch overlay with the display bezel or active area, using the built‑in guides to achieve precise positioning. Secure the steel chassis to the display housing or mounting surface with the appropriate screws, ensuring the overlay sits flush and stable without warping or gaps that could affect touch accuracy. Connect the IR sensing module or controller to the overlay’s interface and attach the power supply according to the manufacturer’s guidelines. Power on the system and perform any required calibration or alignment steps as recommended for your installation; in many cases, the TSItouch will operate with minimal or no calibration after mounting. Finally, run a quick touch test across the entire surface to confirm reliable detection from edge to edge and across all supported input modalities. If needed, adjust sensitivity settings through the control panel or software utility provided by the manufacturer to tailor the experience to your environment and use case.

This installation process is designed to be straightforward for installers with standard AV mounting experience. Using common mounting equipment and precise alignment reduces installation time and ensures a clean, professional look. Post-installation checks should include a public‑facing touch test, ensuring consistent performance across users with different input styles, including those wearing gloves. With the TSItouch overlay correctly installed, you’ll unlock a robust interactive experience that supports dynamic signage, engaging kiosks, educational tools, and collaborative workspaces.

Frequently Asked Questions

Q: What exactly is the TSItouch Overlay?

A: The TSItouch Overlay is an infrared-based touchscreen solution that sits over a display to convert it into an interactive surface. It detects a wide range of input methods—pens, styluses, fingers, palms, and gloved fingers—delivering precise touch interaction for signage, kiosks, classrooms, and control rooms.

Q: What input types does TSItouch support?

A: TSItouch is designed to detect multiple input modalities, including traditional finger touch, stylus or pen input for annotations, and even gloved finger input suitable for environments where gloves are required.

Q: Is the overlay durable enough for public installations?

A: Yes. The overlay features a full steel chassis and a rugged overlay designed to withstand high-traffic use, accidental touches, and long-term operational demands typical of public-facing displays and professional environments.

Q: How easy is it to install and set up?

A: Installation is streamlined for quick deployment. The overlay is engineered for straightforward mounting to most compatible displays, with simple plug‑and‑play connections and minimal ongoing maintenance. Many setups require little to no calibration after installation, depending on the display and configuration.

Q: What types of displays and mounting configurations are supported?

A: TSItouch is designed to integrate with a wide range of LCD/LED displays and signage systems. It supports common mounting patterns and can be adapted to various enclosure configurations, making it suitable for digital signage, kiosks, classrooms, and control rooms.
