TSItouch Touchscreen Overlay for 65" LCD Displays

Upgrade your large-format LCD with the TSItouch Touchscreen Overlay, a precision infrared (IR) multi-touch solution engineered to transform a 65" display into a vibrant, interactive canvas. This overlay is designed to deliver fast, accurate touch input across the entire screen while preserving the original image quality of your LCD panel. Ideal for classrooms, corporate training rooms, interactive digital signage, retail kiosks, and entertainment venues, the TSItouch overlay enables natural, collaborative interactions with up to 10 simultaneous touch points. Built to withstand the rigors of busy environments, it combines robust infrared technology with a slim, optically clear profile that won’t compromise brightness, contrast, or color fidelity. Whether you need to annotate presentations, run interactive demonstrations, or empower multi-user collaboration, TSItouch offers a reliable, plug-and-play upgrade path that blends seamlessly with your existing display infrastructure.

• 10-point multi‑touch precision: Enjoy up to ten independent touch inputs at once, enabling multiple users to annotate, resize, drag, rotate, and interact with on-screen content in real time for dynamic collaboration.
• 65‑inch IR touch coverage: Infrared (IrDA) technology detects touches across the entire 65" surface with minimal parallax, ensuring accurate input from edge to edge even during fast gestures.
• LCD-friendly overlay design: A slim, optically clear overlay that preserves screen brightness, contrast, and color accuracy while maintaining a natural touch experience on your existing LCD panel.
• Durable, professional construction: Built for high-traffic environments, the TSItouch overlay resists wear and tear while delivering consistent calibration and long‑term reliability in classrooms, conferences, and storefronts.
• Plug-and-play connectivity with easy calibration: Quick USB touch data connection and a straightforward calibration workflow, compatible with Windows, macOS, and many Android devices for fast deployment across diverse setups.

Technical Details of TSItouch Touchscreen Overlay

• Display Compatibility: LCD panels designed for 65" displays.
• Touch Technology: Infrared (IrDA) multi-touch overlay for reliable and responsive input.
• Touch Points: 10-point touch support for multi-user interaction.
• Overlay Type: Active touchscreen overlay designed to mount over the existing LCD panel without replacing the display itself.
• Connectivity: USB interface to transmit touch data to the host system, typically recognized as a human interface device (HID).

How to Install TSItouch Touchscreen Overlay

Installing the TSItouch overlay on a 65" LCD is a straightforward process that preserves your screen’s image quality while delivering a responsive touch experience. Follow these steps to ensure precise alignment, stable calibration, and reliable performance from day one.

Step 1: Prepare the display and workspace. Power down the 65" LCD and disconnect it from power sources. Clean the screen surface gently with a microfiber cloth to remove dust, fingerprints, and residues. A clean, debris-free surface ensures the overlay sits flat and aligns correctly with the bezel, preventing touch misalignment or glare issues after installation.

Step 2: Inspect and position the overlay. Unpack the TSItouch touchscreen overlay and verify all mounting components are present. Align the overlay with the display’s corners and edges, taking care to match the overlay’s cutouts and mounting points with the screen bezels. If your kit uses mounting brackets or clips, attach them securely before proceeding. A precise alignment is crucial for accurate touch input, especially near the edges and corners of a 65" panel.

Step 3: Secure the overlay and ensure clearance. Gently place the overlay onto the screen surface, ensuring there is adequate clearance between the overlay frame and any surrounding hardware or cabinet components. If adhesive or mounting tape is included, apply it evenly to prevent warping or lift. Confirm that the overlay rests flush against the screen without gaps that could trap dust or cause calibration drift.

Step 4: Connect the USB touch data to the host. Locate the USB data cable from the overlay and connect it to a compatible USB port on your controller, media player, or computer. Use a USB port with sufficient bandwidth and avoid hubs if possible to reduce input latency. Power on the LCD after the USB connection is established so the system can recognize the touch input as a HID device.

Step 5: Calibrate and align touch input. Launch the calibration utility provided with the TSItouch kit or use the operating system’s native calibration tools if prompted. Follow on-screen instructions to touch several target points across the screen, ensuring touch coordinates align precisely with visual targets. Recalibrate if you notice drift or if touches do not correspond to on-screen selections, especially in the far corners.

Step 6: Test, secure, and finalize setup. After calibration, perform a thorough test across the entire surface by using multiple fingers simultaneously, dragging objects, and performing pinch gestures if supported. If any misalignment remains, adjust mounting tension or re-run calibration. Once satisfied, secure any mounting hardware and confirm there are no obstructing cables or loose components. Clean the surface again to remove fingerprints from the installation process, and you’re ready to begin interactive sessions, teaching demonstrations, or dynamic signage activities.

Frequently asked questions

Q: What size of display does the TSItouch overlay support?

A: The TSItouch Overlay is designed for 65" LCD displays. It is purpose-built to align with 65" panels, ensuring a seamless integration that preserves screen geometry and touch accuracy across the entire surface.

Q: How many touch points does it support?

A: It supports 10-point multi-touch, enabling multiple users to engage with the screen simultaneously. This makes it ideal for collaborative learning, team brainstorming, and interactive demonstrations where several participants interact at once.

Q: Which operating systems are compatible?

A: USB touch input is typically recognized as a standard HID device, offering broad compatibility with Windows, macOS, Linux, and many Android-based systems. It’s recommended to confirm driver and OS support based on your specific hardware and software environment.

Q: Is calibration required after installation?

A: Yes. A quick calibration is recommended after installation to guarantee precise alignment between touch input and on-screen coordinates. Recalibration may be helpful after relocation or if the display is moved frequently.

Q: Can the TSItouch overlay be used for public-facing kiosks or signage?

A: Yes. The IR-based, multi-touch solution is well-suited for interactive signage, kiosks, classrooms, conference rooms, and retail applications where durable touch performance and multi-user interaction are beneficial. Ensure appropriate mounting and enclosure considerations for high-traffic environments.
