Tyan Desktop Motherboard — Intel C206 Chipset, LGA-1155 Socket, Micro ATX

Engineered for reliability and expandable performance, the Tyan Desktop Motherboard delivers enterprise-grade capabilities in a compact Micro ATX package. Built around the Intel C206 chipset and the LGA-1155 socket (Socket H2), this motherboard is designed for budgets-conscious builds that demand stability, robust I/O, and scalable connectivity. Its emphasis on RAID reliability, Gigabit Ethernet, and thoughtful thermal management makes it an ideal foundation for small business servers, home labs, and workstation setups where data integrity, network performance, and expansion flexibility matter most.

• Intel C206 chipset delivers solid, efficient performance for everyday computing, data access, and virtualization tasks, providing dependable I/O and system responsiveness for value-focused builds.
• Socket H2 LGA-1155 compatibility paired with a Micro ATX form factor offers a flexible, space-efficient platform that fits a wide range of cases and power configurations while preserving essential expansion possibilities.
• RAID-supported levels enable data reliability and fault tolerance, helping protect critical workloads and improve uptime when paired with suitable storage configurations.
• Gigabit Ethernet provides fast, stable network connectivity for file sharing, remote management, virtualization networking, and streamlined access to network-attached storage resources.
• Micro ATX design with a generous array of PCI/expansion slots and enhanced heat dissipation ensures cooler, quieter operation and ample room for add-on cards and peripherals as your needs grow.

Technical Details of Tyan Desktop Motherboard

• Chipset: Intel C206
• CPU Socket: LGA-1155 (Socket H2)
• Form Factor: Micro ATX
• Networking: Gigabit Ethernet
• RAID: RAID-supported levels (as provided by compatible controllers)
• Expansion: Multiple PCI/PCIe expansion slots to accommodate peripherals and add-ons
• Thermal Management: Enhanced heat dissipation design to help maintain performance under load

How to Install Tyan Desktop Motherboard

• Prepare a clean workspace and gather essential tools. Disconnect all power sources and electrostatic discharge precautions before handling the motherboard.
• Install the chassis standoffs in the case in positions corresponding to the motherboard’s mounting holes. Ensure the standoffs align with the I/O shield cutouts and will support the board securely.
• Place the motherboard into the case, align the I/O shield with the back panel cutouts, and gently seat the board. Secure it with screws without overtightening the mounting points.
• Install the CPU into the LGA-1155 socket according to the processor’s orientation, then apply a thin, even layer of thermal interface material (thermal paste) if your cooler requires it. Attach the CPU cooler securely, ensuring proper clearance for RAM and heatsinks.
• Insert memory modules (RAM) into the appropriate DIMM slots as specified by the motherboard's manual. Ensure they are fully seated and locked in place for optimal contact.
• Connect the 24-pin ATX power connector and any required 8-pin (or 4+4) CPU power connector. Attach case power/reset connectors to the correct pins on the front panel header as directed by the motherboard manual.
• Install any PCIe or PCI expansion cards into the available slots. Secure cards with screws and re-check clearance to prevent cable interference or contact with cooling components.
• Connect data and power cables for storage drives, fans, and other peripherals as needed. Route cables neatly to promote airflow and reduce vibration or snag hazards.
• Power on the system and enter BIOS/UEFI to configure basic settings, set boot order, enable RAID if desired, and apply any necessary firmware updates provided by the manufacturer.
• Install an operating system compatible with the hardware, install drivers, and configure RAID, networking, and other features as required for your workload.

Frequently Asked Questions

• Q: What processors are compatible with this motherboard?
• A: This motherboard uses the LGA-1155 socket and Intel C206 chipset. For exact CPU compatibility, refer to official CPU support lists and BIOS guidance from the manufacturer, as compatibility can depend on BIOS version and processor generation.
• Q: Does it support RAID?
• A: Yes, the board supports RAID-enabled configurations, with RAID levels available through compatible controllers and BIOS settings. Verify the specific RAID levels supported by your storage controller and firmware.
• Q: How many expansion slots does it have?
• A: The Micro ATX form factor typically includes multiple PCI and PCIe expansion slots to accommodate add-on cards and peripherals. The exact counts may vary by model and revision; consult the product’s official specifications for precise details.
• Q: What type of memory is supported?
• A: Memory specifications (type, speed, capacity) vary by model and BIOS. Please check the official product specifications for exact RAM compatibility and maximum supported capacity.
