Tyan Drive Bay Module

TyanSKU: 1142624

Price:
Sale price$210.30

Description

Tyan Drive Bay Module

The Tyan Drive Bay Module is a compact, high-density storage expansion designed for enterprise servers and workstations. This 1/3U, front-accessible enclosure houses four 3.5-inch drive bays, providing scalable internal storage in a compact footprint. Built for reliability in demanding data-center environments, the Tyan Drive Bay Module supports hot-swappable operation, enabling drive maintenance and replacement without a full system shutdown. Its internal design is optimized for clean integration with compatible chassis and backplanes, helping you maximize storage capacity while keeping cabling neat and airflow unimpeded. Whether you’re expanding a virtualization host, building a storage-dense server cluster, or adding local data storage for analytics workloads, this module delivers flexible, dependable performance within a compact, rack-friendly form factor.

  • Four 3.5-inch drive bays in a single, space-efficient 1/3U module for scalable internal storage expansion.
  • Front-accessible design enables quick drive replacement and maintenance without disassembly or tools, reducing downtime.
  • 1/3U form factor fits into tight server chassis and blade enclosures, maximizing rack density while preserving airflow and cable management.
  • Internal, hot-swappable capability supports operational continuity by allowing drive swaps while the system remains online when supported by the backplane.
  • Integrated storage expansion for servers ideal for data centers, labs, and enterprise environments needing reliable, scalable local storage.

Technical Details of Tyan Drive Bay Module

  • Get this information from the "specifications" section of the product on the Synnex EC site (https://ec.synnex.com/) using the product UPC or SKU as reference. Exact values appear in the Specifications section of the listing.

how to install Tyan Drive Bay Module

Installing the Tyan Drive Bay Module is a straightforward process that should be performed with the server powered down and disconnected from power. Begin by consulting your server chassis manual to identify the correct 1/3U drive bay slot and ensure there is an available backplane or backplane-compatible connection for four 3.5-inch drives. Prepare a clean, static-free workspace and wear proper electrostatic discharge protection to protect sensitive components.

Next, remove the chassis cover and locate the designated drive bay area where the module will be installed. Align the Tyan Drive Bay Module with the chassis rails or mounting points, ensuring that the backplane connectors (or drive backplane interface) line up with the module’s interface. Gently slide the module into place until it seats securely in the chassis, taking care not to bend any connectors or force the component. Once seated, secure the module with the appropriate mounting screws or latches as specified by the chassis design.

With the module secured, connect the required backplane or data cables to the drive backplane connectors. Double-check that all four drive bays are properly aligned with the backplane, and inspect cabling for clearance and airflow to avoid obstruction. Reinstall the server cover, reconnect power, and boot the system. Use the server’s management interface or operating system disk management utilities to verify that all four drives are detected and presented by the backplane. If additional driver or firmware updates are required for optimal compatibility, follow the vendor-recommended upgrade path before placing the system into production.

During initial operation, monitor drive health indicators and perform a consistency check on the drives to ensure the backplane is functioning correctly. The Tyan Drive Bay Module is designed to be a dependable, hot-swappable storage expansion; always follow your server’s maintenance and safety guidelines, including proper grounding and handling procedures, to minimize the risk of component damage or data loss.

Frequently asked questions

  • Q: How many drives does the module support? A: It supports four 3.5-inch drives, providing substantial internal storage within a compact 1/3U footprint.
  • Q: What does 1/3H mean? A: 1/3H refers to 1/3 of a rack unit height, a compact form factor that allows high-density installations in compatible servers and chassis.
  • Q: Is the drive bay hot-swappable? A: Yes. The module is designed for hot-swappable operation, enabling drive replacement without a full system shutdown when used with a compatible backplane.
  • Q: Is this module internal or external? A: This is an internal drive bay module intended to be installed inside the server chassis and connected to the internal backplane.
  • Q: How do I verify compatibility? A: Check that your server chassis supports a front-accessible 1/3U 4-disk 3.5-inch bay module, and ensure the backplane is compatible with the module’s interface and power requirements.
  • Q: Do I need special tools for installation? A: Installation typically uses standard server mounting hardware. For precise mounting and compatibility with your chassis, refer to the chassis manual and the server’s installation guide.
  • Q: Can I mix drive sizes or types in the four bays? A: The module is designed for 3.5-inch drives; check your backplane’s specifications to confirm supported drive types and capacities for optimal performance and reliability.
