Tycon Power PoE Injector

Tycon PowerSKU: 4076388

Price:
Sale price$78.80

Description

Tycon Power PoE Injector TP-POE-1824

The TP-POE-1824 from Tycon Power is a compact, robust Power over Ethernet injector that converts a 48VDC PoE input into a regulated, passive PoE output. This device is IEEE 802.3af/at compatible at the input and features an external jumper to select between 18V and 24V output. Delivering up to 25W of power, it is an ideal solution for powering high-demand PoE devices such as IP cameras, wireless access points, and other networked edge devices where a fixed or non-standard voltage is required. With its easy integration into existing PoE networks, the TP-POE-1824 helps simplify deployments, reduce cable clutter, and improve reliability in both commercial and industrial environments.

  • IEEE 802.3af/at Input Compatibility: Designed to work with standard PoE switches and midspan injectors that supply 48V DC, ensuring safe, compliant power delivery to your network devices.
  • External Jumper-Selectable Output: Choose between 18V or 24V DC output using a simple external jumper, giving you flexibility to power a broader range of PoE devices without a separate DC-DC converter.
  • Regulated Passive PoE Output up to 25W: Provides a stable, regulated output suitable for cameras, access points, and other Ethernet-powered equipment that require higher wattage in a passive PoE setup.
  • Rugged, Industrial-Grade Design: Built to endure challenging installation environments, with a compact form factor that fits easily into enclosures and tight cabinets while maintaining reliable performance.
  • Simple Integration and Deployment: A straightforward solution for upgrading existing PoE networks, enabling flexible device placement and eliminating the need for additional power adapters on every remote device.

Technical Details of Tycon Power PoE Injector TP-POE-1824

  • Model: TP-POE-1824
  • Input: 48V DC, IEEE 802.3af/at compatible
  • Output: 18V or 24V DC regulated passive PoE output (external jumper selectable)
  • Output Power: Up to 25W
  • PoE Type: Passive PoE output
  • Voltage Selection: Jumper-based external setting for 18V or 24V
  • Application: Suitable for powering PoE devices that require non-standard or regulated voltages from a 48V input
  • Compatibility: Designed to work with IEEE 802.3af/at compliant systems on the input side

how to install Tycon Power PoE Injector TP-POE-1824

  • Ensure the installation environment matches the device’s specifications and that power sources are de-energized before wiring.
  • Connect a compliant 48V DC PoE supply to the TP-POE-1824 input terminals or connector following standard PoE wiring practices.
  • Set the output voltage using the external jumper to the desired setting: 18V or 24V, depending on the requirements of your PoE-powered device.
  • Connect the PoE-powered device to the TP-POE-1824’s output port or designated PoE output connection, ensuring proper data and power delivery paths.
  • Power up the system and verify operation with the connected device. Confirm that the device receives the expected voltage and operates normally, then monitor for any abnormal heat or performance issues.

Frequently asked questions

  • Q: What devices can I power with the TP-POE-1824?
    A: The injector is designed to deliver up to 25W of regulated passive PoE output at 18V or 24V, suitable for IP cameras, wireless access points, and other PoE devices that require a non-standard voltage or a regulated output from a 48V input.
  • Q: Do I need any special cables or adapters?
    A: Standard PoE cabling is used for input and output connections. The key is to ensure the 48V PoE input is IEEE 802.3af/at compliant and that the output voltage is set correctly with the external jumper.
  • Q: Is the output truly passive PoE?
    A: Yes, the TP-POE-1824 provides a passive PoE output once the external voltage is selected, allowing you to power compatible devices that can accept non-signal-based PoE power.
  • Q: What about safety and protection?
    A: The device is designed to meet standard PoE requirements on the input side and to provide a regulated output. Always verify that your installation follows electrical safety guidelines and manufacturer recommendations.
  • Q: Can I use this with non-PoE devices?
    A: The TP-POE-1824 is intended for PoE-enabled devices. It should only be used with devices designed to accept PoE power at the specified voltage and current limits.
