Veracity HIGHWIRE Longstar Lite Non POE Long Range Ethernet over Coax

The Veracity HIGHWIRE Longstar Lite Non POE Long Range Ethernet over Coax is engineered to bridge large distances with uncompromised 100Base-T Ethernet performance over existing coax cabling. Designed for installations where running new fiber or power-over-coax is impractical, Longstar Lite reuses legacy coax to extend high-speed networks across campuses, warehouses, campuses, and remote sites. This non-POE solution delivers dependable bandwidth, strong signal integrity, and simplified deployment, enabling secure data transmission over coax for surveillance, industrial automation, and enterprise backbones. With rugged construction, straightforward setup, and an emphasis on cost savings, Longstar Lite makes it possible to leverage existing infrastructure without changing network architecture or power distribution schemes.

• Long-range 100Base-T Ethernet over coax up to 1400 meters, allowing installations to span large outdoor areas, multi-building sites, or remote facilities without new cabling.
• Non-POE design—Power is supplied independently at the device ends—preserving existing PoE plans and avoiding power over coax complexity on the network path.
• Reuse of legacy coax cabling dramatically cuts installation costs and time by eliminating the need for new fiber or copper runs while preserving current pathways.
• Rigid, industrial-grade build with shielding and robust connectors to withstand challenging environments, temperature variations, and long-term operation in field deployments.
• Plug-and-play deployment with auto-negotiation, simple two-device link establishment, and clear status indicators to ease installation, troubleshooting, and ongoing maintenance.

Technical Details of Veracity HIGHWIRE Longstar Lite Non POE Long Range Ethernet over Coax

• Product type: Non POE Long Range Ethernet over Coax bridge
• Ethernet standard: 100Base-TX
• Maximum distance over coax: Up to 1400 meters
• Coax compatibility: Utilizes existing RG-59/6-type coaxial cabling (recommend RG-6 for best performance)
• Power: External power supply required at each device end; no power over coax
• Connectors: RJ-45 Ethernet port on device; coaxial interface for the long-haul connection
• Data rate: Up to 100 Mbps full-duplex
• Operating temperature: -10°C to 60°C (typical industrial range)
• Enclosure rating: Rugged, field-ready housing suitable for harsh environments
• Compliance: CE/FCC-compliant components and materials
• Warranty: Limited warranty (specifications may vary by region and distributor)

how to install Veracity HIGHWIRE Longstar Lite Non POE Long Range Ethernet over Coax

• Plan your topology: Identify two endpoints where the Longstar Lite devices will reside, ensuring coax runs between them and power outlets are accessible at each location.
• Prepare the coax path: Inspect the existing coax run for damage, impedance characteristics, and routing. Replace or clean connectors if needed to maximize signal integrity.
• Connect the devices: Attach the Longstar Lite unit at each end to the existing network via the RJ-45 port, then connect the coaxial link between the two units using the appropriate coax connectors.
• Provide power: Supply external DC power to both units per the included adapter specifications. Ensure power sources are reliable and surge-protected.
• Power up and verify: Turn on both devices and confirm link status via the LED indicators. Check for a stable Ethernet link at the connected network equipment.
• Configure as needed: If required, adjust basic network settings to align with your LAN (VLANs, MTU, or specific network policies) and test data transmission across the link.
• Test in real conditions: Validate performance to ensure 100 Mbps throughput across the full coax distance and verify reliability under normal operating loads.
• Document for maintenance: Record the path, device locations, power sources, and any site-specific considerations to simplify future maintenance and upgrades.

Frequently asked questions

• Q: Does Veracity HIGHWIRE Longstar Lite provide Power over Coax (PoE)? A: No. This is a non-POE solution; power must be supplied independently at each device end with a dedicated power supply.
• Q: How far can I run Ethernet over coax with Longstar Lite? A: Up to 1400 meters of coax can support a 100Base-T connection, making it suitable for long-haul campus and industrial deployments.
• Q: What Ethernet standard does it support? A: It supports 100Base-TX for reliable, 100 Mbps performance over coax.
• Q: Can I reuse existing coax cabling I already have in place? A: Yes. One of the core benefits of Longstar Lite is the ability to reuse legacy coax cabling, reducing installation costs and downtime.
• Q: Is this suitable for outdoor or harsh environments? A: Yes. The Longstar Lite is designed with rugged construction and shielding to withstand industrial and outdoor environments, along with a broad operating temperature range.
• Q: Do I need special coax types or adapters? A: The unit is designed to work with common coax types (RG-59/6; RG-6 recommended for best results). Ensure connectors are clean and properly terminated for optimal performance.
• Q: Can I monitor or manage the connection remotely? A: Basic monitoring is provided via link indicators on the unit; advanced remote management would depend on integrating the link with your existing network monitoring tools.
• Q: What applications best suit Longstar Lite? A: Long-range Ethernet over coax is ideal for security camera backbones, industrial automation networks, campus-wide data distribution, and scenarios where laying new fiber or PoE over coax is impractical.
