Vertiv Liebert POD PD5-004: 2x NEMA L5-30R, 4x NEMA L5-20R, UPS Maintenance Bypass for GXT5

The Vertiv Liebert POD PD5-004 is a purpose-built Power Output Distribution (POD) unit with a built-in maintenance bypass designed to keep critical operations running even when UPS maintenance is required. Specifically engineered for the GXT5 series 5–10 kVA UPS systems, this POD bridges the gap between protection and accessibility, enabling seamless service, replacement, and upgrades without interrupting the power supply to connected equipment.

• Reliable UPS maintenance bypass: perform necessary UPS service and component swaps without powering down critical loads, reducing downtime and preserving uptime for essential systems.
• Flexible receptacle configuration: (2) NEMA L5-30R outlets and (4) NEMA L5-20R outlets provide ample outlets to connect diverse equipment while keeping cords organized and properly grouped around your rack or cabinet.
• Designed for GXT5 5–10kVA UPS models: tailor-made to integrate with Liebert GXT5 systems, ensuring compatibility, electrical harmony, and streamlined maintenance workflows.
• Easy integration with PD5 architecture: built to complement Liebert PD5 power distribution architecture, offering a scalable solution for growing data centers, server rooms, and critical facilities.
• Enhanced safety and reliability: engineered to support uninterrupted service during maintenance events, helping protect both personnel and equipment in demanding environments.

Technical Details of Vertiv Liebert POD PD5-004

• Receptacle configuration: 2 x NEMA L5-30R and 4 x NEMA L5-20R outlets for versatile power distribution across equipment and peripherals.
• Maintenance bypass: integrated maintenance bypass feature to enable UPS maintenance or replacement without interrupting the load connected to the POD.
• Model code: PD5-004, part of the Liebert POD PD5 family designed for compatibility with Liebert GXT5 UPS systems.
• Compatibility: specifically engineered for GXT5 5–10 kVA UPS models, delivering coordinated protection and distribution.
• Primary purpose: power output distribution with an embedded bypass path to simplify maintenance workflows and minimize downtime for critical systems.
• Application environment: ideal for data centers, server rooms, telecom closets, and any facility requiring reliable UPS-supported distribution with maintenance continuity.

How to install Vertiv Liebert POD PD5-004

Installing the Vertiv Liebert POD PD5-004 should be performed by qualified electrical personnel following all local codes and the manufacturer’s guidelines. Below is a practical, high-level overview to help you understand the typical installation sequence and best practices.

• Prepare and plan: verify that your GXT5 UPS is compatible with the PD5-004 and that you have the correct mounting space, cabling, and labeling. Review the installation manual for wiring diagrams and safety instructions before starting.
• Mount and secure: install the POD PD5 in a suitable rack, cabinet, or enclosure according to your facility’s layout. Ensure there is adequate clearance for cooling, cable access, and serviceability.
• Wire the assembly: connect the PD5 between the UPS output and your critical load distribution. Adhere to the recommended conduit and wiring practices, routing feeds to the two L5-30R outlets and the four L5-20R outlets as required by your equipment configuration.
• Enable the bypass: engage the maintenance bypass path per the PD5-004 manual. This step ensures that power can flow to connected loads even when the UPS is offline for service or replacement, enabling safe, uninterrupted maintenance work.
• Test and verify: with loads connected, perform functional checks to confirm that normal operation is restored when the UPS is online and that the bypass path properly maintains load power during maintenance scenarios. Label circuits and outlets for quick identification during future maintenance.

Frequently asked questions

• Q: What is the primary purpose of the Vertiv Liebert POD PD5-004? A: The PD5-004 is a Power Output Distribution unit with a built-in maintenance bypass designed to work with GXT5 UPS models, enabling maintenance without interrupting power to connected equipment.
• Q: How many outlets does the PD5-004 provide? A: It features (2) NEMA L5-30R outlets and (4) NEMA L5-20R outlets, offering six total outlets for distributing power to critical devices.
• Q: Which UPS models are compatible with the PD5-004? A: The PD5-004 is designed for Liebert GXT5 series UPS units in the 5–10 kVA range, ensuring cohesive protection and distribution.
• Q: Can maintenance be performed without shutting down loads? A: Yes. The built-in maintenance bypass allows UPS maintenance or replacement to be performed without interrupting power to the connected equipment, minimizing downtime.
• Q: Is installation complex? A: Installation should be performed by qualified personnel following the manufacturer’s wiring diagrams and safety practices. The PD5-004 is designed to integrate smoothly with the GXT5 system and Liebert PD5 distribution approach.
• Q: Where is the PD5-004 best used? A: It is ideal for data centers, server rooms, and other facilities requiring reliable UPS-backed power distribution with the ability to maintain service during maintenance events.
