Vertiv Liebert Rack Mount Brackets – Flush Mount for Vertiv GXT5 UPS Shelf Support

Effortlessly integrate your Vertiv Liebert GXT UPS into a standard 19-inch telecom/relay rack with these flush-mount rack brackets. Engineered to create a seamless, low-profile shelf for the UPS, these brackets are designed to maximize space, simplify serviceability, and maintain clean cable management in mission-critical environments. Specifically optimized for Vertiv Liebert GXT3 and GXT4 UPS systems, they provide a secure, professional installation that keeps your power protection hardware neatly tucked away at the front of the rack for easy access and maintenance. Whether you’re outfitting data centers, telecom facilities, or any 19-inch rack environment, these brackets deliver dependable performance and a tidy, professional appearance while preserving airflow and accessibility.

• Flush-mount design for 19-inch telecom/relay racks: Create a sleek, sit-flat UPS shelf that blends with standard 19" equipment racks. The flush-mount approach minimizes protrusion, reduces front-edge clutter, and preserves valuable rack space for other equipment.
• Single mounting rail compatibility for telecom/relay racks: Built to fit single-rail mounting configurations, ensuring straightforward installation in racks used for telecom or relay applications while maintaining secure, stable support for the UPS unit.
• Compatibility with Vertiv Liebert GXT3 and GXT4 UPS Systems: Integrates smoothly with Liebert GXT3 and GXT4 lineups, enabling clean-front installations that keep the UPS readily accessible for maintenance and battery checks. Note: the product’s primary documentation references GXT3/GXT4 compatibility; verify GXT5 fitment with your rack setup if required.
• Durable, service-friendly design: Engineered for reliability in busy environments, the brackets provide sturdy support and straightforward hardware-assisted mounting. The setup is designed to stay secure under normal rack conditions while allowing quick removal for service or upgrades.
• Improved cable management and airflow: By positioning the UPS on a dedicated shelf with a flush profile, cable runs stay organized, and airflow around the equipment remains unobstructed, helping maintain optimal cooling in dense rack environments.

Technical Details of Vertiv Liebert Rack Mount Brackets - Flush Mount Vertiv GXT5 UPS Shelf Support

• Rack compatibility: 19-inch wide telecom/relay racks.
• Mounting style: Flush mount using a single mounting rail configuration for clean front access.
• UPS compatibility: Designed for Vertiv Liebert GXT3 and GXT4 series; GXT5 compatibility should be confirmed with your specific rack and cabinet setup.
• Installation orientation: Front-accessible shelf solution that keeps the UPS within easy reach for maintenance and battery checks.
• Included hardware: Brackets (with mounting hardware) provided to simplify installation in compatible racks.

how to install Vertiv Liebert Rack Mount Brackets – Flush Mount Vertiv GXT5 UPS Shelf Support

Follow these steps to install the flush-mount rack brackets and mount your Vertiv Liebert UPS for a tidy, front-accessible shelf:

• Power down the UPS and disconnect all power and communication cables before beginning installation to ensure safety and prevent equipment damage.
• Prepare the 19-inch rack by locating a suitable mounting area on the front rails where the brackets will be attached. Ensure there is adequate clearance for ventilation and front access to the UPS controls.
• Attach the brackets to the rack rails using the included mounting screws or hardware. Align the brackets so that they form a stable, level platform for the UPS and sit flush with the front edge of the rack to achieve the intended shelf look.
• Slide the Vertiv Liebert GXT3 or GXT4 UPS (as applicable) onto the mounted brackets. Make sure the unit is evenly seated and aligned with the rack rails to prevent tilt or misalignment.
• Secure the UPS to the brackets with the remaining hardware, ensuring all fasteners are tight but not over-tightened. Check that the unit remains level and that there is no interference with other equipment or cables.
• Reconnect power and data cables, organize cable routing to maintain airflow, and power up the system to verify proper operation. Confirm that the UPS front panel is accessible for status indicators and maintenance checks.

Frequently asked questions

• Q: What racks are compatible with these brackets? A: The brackets are designed for 19-inch wide telecom/relay racks with a single mounting rail configuration, enabling flush-mount installation of the UPS shelf.
• Q: Which Vertiv Liebert UPS models work with these brackets? A: The brackets are designed to be compatible with Vertiv Liebert GXT3 and GXT4 UPS systems. For GXT5 deployments, verify compatibility with your specific rack and cabinet arrangement before installation.
• Q: Do the brackets come with all mounting hardware? A: Yes, the brackets include the necessary mounting hardware to secure the shelf within a standard 19-inch rack, simplifying the installation process.
• Q: Will this solution affect airflow inside the rack? A: The flush-mount, shelf-style design is intended to minimize protrusion and maintain good airflow around the UPS, contributing to effective cooling in dense rack environments when cables are neatly managed.
• Q: Is professional installation recommended? A: While many users can install these brackets with standard hand tools, following the provided steps will help ensure a secure, flush-mount installation. If your rack has non-standard rails or additional constraints, consult your rack manufacturer or a professional technician.
