Description
The FE9380-HV from VIVOTEK is a premier 5-megapixel outdoor HD network camera built for expansive, color-rich surveillance with a truly immersive 360° fisheye lens. This camera blends versatility and reliability by offering color imagery in daylight and high-contrast monochrome at night, powered by a removable IR-cut filter for true day/night performance. Its 360° IR illumination ensures consistent coverage with minimal blind spots, reaching up to a 10-meter radius. Designed to excel in dynamic environments—from storefronts and parking lots to campuses and critical infrastructure—the FE9380-HV captures crisp detail, maintains legible imagery under challenging lighting thanks to WDR Pro 120dB, and provides flexible video management options through its robust IP network camera platform. Acknowledging the needs of professional security deployments, this model is TAA compliant, meeting procurement standards for public-sector and enterprise installations while delivering a wide, dependable field of view and reliable performance in any weather.
- Unmatched 360° coverage with a dedicated fisheye lens supports color imagery by day and monochrome night vision, enabling comprehensive situational awareness across large spaces and complex layouts.
- True Day/Night capability with a removable IR-cut filter ensures accurate color rendering in daylight and high-contrast monochrome imagery after dark, while 360° IR illumination provides uniform lighting up to 10 meters to minimize shadows and glare.
- High-detail 5MP resolution with smooth performance up to 30 frames per second at full resolution, delivering sharp video for monitoring fast-moving activity and identifying critical details in real time.
- WDR Pro 120dB wide dynamic range preserves image detail in scenes with extreme brightness and deep shadows, ensuring readability of faces, license plates, and signage under varied lighting conditions.
- Rugged outdoor design and TAA compliance make the FE9380-HV suitable for a wide range of deployments—from retail and education to transportation and government—while meeting procurement and security standards for external installations.
Technical Details of FE9380-HV
- Model: FE9380-HV
- Image sensor: 5 Megapixel progressive CMOS
- Resolution: Up to 5MP, with support for 30 frames per second at full resolution
- Lens: Fisheye lens providing a 360° field of view for immersive surveillance and flexible dewarping options
- Day/Night: True Day/Night operation with removable IR-cut filter
- IR Illumination: 360° infrared lighting with up to 10 meters of effective range for night coverage
- Dynamic Range: WDR Pro 120dB for consistent detail across bright and dark areas
- Environment: Outdoor-ready design intended for external installations and wide-area monitoring
- Compliance: TAA Compliant, suitable for government and enterprise procurement
How to Install FE9380-HV
- Plan the installation location to maximize 360° coverage and minimize obstructions. Consider entry points, high-traffic areas, and corners that benefit from panoramic observation.
- Mount the FE9380-HV securely using the provided hardware and ensure the bracket is oriented to capture the desired coverage area. Verify stability and adjust for a level, unobstructed view.
- Connect the camera to your network and provide power according to your site’s infrastructure. Configure network settings via the camera’s web interface or your NVR/VMS to establish a stable IP address, gateway, and DNS as needed.
- Access the camera’s web UI to enable True Day/Night mode, configure WDR Pro 120dB, set IR illumination parameters, and choose the preferred dewarping mode for the fisheye image. Test viewing angles and adjust brightness, contrast, and saturation for optimal clarity.
- Calibrate dewarping and ROI as required for your application. Validate 360° coverage, verify object detection zones, and ensure video streams are correctly routed to your recording platform. Schedule maintenance windows to test performance across day and night cycles.
- Test performance under varying lighting conditions, ensure monitoring alerts are functioning, and document the installation for future updates or expansion. Regularly verify firmware updates from VIVOTEK to retain security and feature parity.
Frequently asked questions
- What makes the FE9380-HV unique? It combines a 5MP outdoor IP camera with a fisheye lens that delivers full 360° coverage, true day/night capability with a removable IR-cut filter, and 360° IR illumination up to 10 meters, all powered by WDR Pro 120dB for exceptional image fidelity in mixed lighting.
- What resolution and frame rate does it support? The FE9380-HV supports up to 5MP resolution at up to 30 frames per second, ensuring smooth video for real-time monitoring and accurate scene analysis.
- Is this camera suitable for outdoor installations? Yes. It is designed for outdoor use and provides features such as 360° coverage, IR illumination, and day/night performance, making it ideal for exterior surveillance across multiple environments.
- Is the FE9380-HV compliant with procurement requirements? Yes. It is listed as TAA compliant, which aligns with standards for government and enterprise purchasing in many regions.
- How does dewarping work with the 360° fisheye lens? The FE9380-HV supports standard dewarping within VIVOTEK’s software ecosystem and compatible video management systems, allowing you to view and export stabilized, deskewed views of specific zones while maintaining the full panoramic coverage.
