Winsted 64264 Mounting Tray for Electrical Box – Black

Designed for professional electrical enclosures, the Winsted 64264 Mounting Tray for Electrical Box in black delivers a robust, internal cable management solution. This tray is engineered to reside in the lower chase compartment, offering a large, stable surface for routing, organizing, and mounting cables with ease. Its four spring pins enable tool-free installation and quick adjustments, so you can adapt cable layouts as systems evolve, without sacrificing security or accessibility. With a clean black finish, it blends seamlessly into most enclosure interiors, helping you maintain a professional, clutter-free look while safeguarding critical wiring from interference and damage.

• Internal cable tray with a generous surface area to route, manage, and mount cables inside electrical enclosures, reducing clutter and improving airflow.
• Four spring pins provide fast, tool-free installation and adjustable positioning to accommodate changing cable runs or component layouts.
• Specifically designed to mount in the lower chase compartment, helping organize cables out of the main enclosure path and keeping critical components accessible.
• Low-profile, professional black finish that complements standard enclosure interiors and existing hardware while maintaining a clean, orderly appearance.
• Generous overall dimensions (1.31 inches high, 7.75 inches deep, 48 inches wide) support long cable runs and flexible routing without crowding other components.

Technical Details of Winsted 64264 Mounting Tray for Electrical Box – Black

• Model: 64264
• Overall dimensions: 1.31" H x 7.75" D x 48" W (33 x 169 x 1176 mm)
• Color/Finish: Black
• Mounting location: Internal cable tray designed for lower chase compartments
• Special features: Four spring pins for quick, adjustable installation
• Material: Not specified in available data
• Compatibility: Intended for use with Winsted enclosures and similar internal cable routing setups

How to Install Winsted 64264 Mounting Tray for Electrical Box

• Plan cable routing and identify the lower chase compartment where the tray will be mounted, ensuring adequate clearance for cables and any adjacent components.
• Position the mounting tray inside the lower chase compartment so that the desired cable paths align with your enclosure’s interior routing needs.
• Engage all four spring pins to secure the tray in place, making any necessary adjustments to achieve a stable, level installation with unobstructed access to the tray surface.
• Begin routing cables across the tray, using separate runs for power, data, and auxiliary cables as appropriate to minimize interference and simplify future maintenance.
• Secure cables as needed with ties or clamps, then reassemble the enclosure and verify that all cables are fully supported and have adequate clearance from doors, hinges, and other moving parts.

Frequently asked questions

• What is the overall size of the tray? The mounting tray measures 1.31 inches in height, 7.75 inches in depth, and 48 inches in width (33 x 169 x 1176 mm).
• Where is the tray installed? It is designed for internal use within a lower chase compartment of compatible electrical enclosures.
• How many mounting pins does it have? The tray features four spring pins to enable quick, tool-free installation and adjustable positioning.
• What color is the tray? The tray is finished in black for a professional, low-profile appearance that blends with most interiors.
• Is this tray compatible with all electrical boxes? The tray is intended for use with Winsted enclosures and similar internal cable management setups; verify compatibility with your specific enclosure model and available interior space before installation.
