Wiremold Evolution Series 4-Gang Hinged Wall Box

WiremoldSKU: 7100686

Price:
Sale price$246.74

Description

Wiremold Evolution Series 4-Gang Hinged Wall Box for 16" OC Walls

The Wiremold Evolution Series 4-Gang Hinged Wall Box is a purpose-built solution for modern electrical and data installations tucked neatly into standard wall cavities. Engineered to fit the common 16" on center (406 mm) opening between studs in a standard 2" x 4" (51 mm x 102 mm) wall, this box delivers a clean, professional installation for power, communications, and A/V devices. Its hinged design provides quick, effortless access to internal wiring and mounted devices, reducing wall damage during install and future service. Suitable for both new work and remodel projects, it blends rugged durability with flexible performance to meet the evolving needs of residential, commercial, and office environments.

  • The 4-gang standard NEMA-size openings give you a generous, versatile footprint capable of hosting a wide range of electrical, data, and audio/visual components without crowding or crowding out space for future upgrades.
  • Hinged access and a robust enclosure simplify device mounting and wire management. This design minimizes wall disturbances and speeds up installation, service, and future reconfigurations.
  • Specifically engineered to fit the 16" on center opening between studs in a typical 2x4 wall, ensuring a precise, secure fit with fewer adjustments and better wall integrity.
  • Designed for both new work and old work applications, giving contractors and homeowners flexibility during construction, renovation, or retrofit projects while maintaining a clean, professional appearance.
  • Optimized for power, communications, and A/V devices, supporting a wide range of faceplates, modules, and accessories to accommodate evolving technology and layered connectivity needs.

Technical Details of Wiremold Evolution Series 4-Gang Hinged Wall Box

  • 4-gang standard NEMA size openings provide ample space for multiple devices within a single installed unit.
  • Designed to fit the 16" on center (406 mm) opening between studs in a standard 2" x 4" wall, ensuring alignment with common wall framing for straightforward installation.
  • Compatible with both new work and old work applications, enabling seamless use in new construction or during renovations.
  • Intended for use with power, communications, and A/V devices, offering a versatile housing that can support a variety of devices and faceplates.
  • Hinged wall box design enables easy access to wires and devices, facilitating faster wiring, testing, and future upgrades without removing the entire box from the wall.

How to Install Wiremold Evolution Series 4-Gang Hinged Wall Box

  • Plan the installation by confirming the wall cavity dimensions, stud layout, and the location of the 16" OC opening. Ensure the area is free of obstructions and maintain clearances for the planned devices.
  • Mark the opening on the wall according to the box dimensions, then cut the opening carefully to the required size. Use proper safety equipment and follow local building codes for electrical installations.
  • Route and manage the necessary power, communications, and A/V cables through the wall cavity to the box site, ensuring all cables are properly labeled and meet applicable code requirements for separation and bend radii.
  • Mount the 4-gang hinged wall box into the wall opening, securing it to the stud framing with appropriate mounting hardware. Verify that the box sits plumb and level without excessive force on the surrounding wall material.
  • Install the desired devices and faceplates into the box, connect the wiring per respective device guidelines, and close the hinged cover to complete the installation. Perform a final inspection to verify proper clearance, device function, and neat cable management.

Frequently asked questions

  • Q: What opening size does this box fit?

    A: The box is designed to fit a 16" on center opening between studs in a standard 2" x 4" wall, providing a precise, secure fit for typical residential and commercial framing.

  • Q: Can it accommodate different types of devices (power, data, and A/V)?

    A: Yes. The 4-gang configuration is intended to host a variety of devices and faceplates, making it suitable for power outlets, data jacks, Ethernet, coax, HDMI, and other A/V connections within a single, organized enclosure.

  • Q: Is the wall box suitable for both new work and old work installations?

    A: Absolutely. The Evolution Series 4-Gang Hinged Wall Box is designed to support both new construction and retrofit/remodel scenarios, allowing flexible use across job types.

  • Q: What makes the hinged design advantageous?

    A: The hinged design provides easy access to cables and devices, simplifying wiring changes, testing, and upgrades without removing the box from the wall or disturbing surrounding material.
