Wiremold Flange – One-Gang Aluminum Tile Flange for Floor Boxes

Upgrade your floor box installations with the Wiremold Flange, a purpose-built, one-gang tile flange crafted from powder-coated aluminum. Measuring 4.5 inches by 3.5 inches (114 mm x 89 mm), this flange is designed to deliver a precise, flush finish when used with select Wiremold floor boxes. It’s ideal for tile, terrazzo, and carpet flooring, providing a durable, code-compliant solution that combines modern aesthetics with long-lasting performance. The aluminum construction resists corrosion and wear, ensuring a professional look even in high-traffic environments. UL Listed for tile, terrazzo, and carpet floors, this flange delivers peace of mind for commercial installations where reliability and safety are paramount. Brass covers and flanges are not interchangeable with aluminum or nonmetallic covers and flanges, reinforcing system integrity and ensuring consistent performance across installations. Whether you’re renovating an office lobby, updating a conference room, or completing a retrofit in a residential setting, this flange enables a clean, tile-appropriate transition from floor to surface while maintaining a sleek, contemporary appearance.

• Optimized compatibility for precise fit with 880S1, 880M1, 880CS1-1, and 880M1-1 Floor Boxes, ensuring dependable performance and a seamless integration into your existing Wiremold system.
• Durable, long-lasting construction with a powder-coated aluminum tile flange that stands up to daily foot traffic, cleaning agents, and routine maintenance without chipping or dulling in high-use spaces.
• Tile-ready design that supports tile, terrazzo, and carpet installations, backed by UL Listing to confirm safe, code-compliant operation across common floor coverings.
• Professional, refined finish: aluminum flange provides a sleek, contemporary look, while clear guidance on compatibility helps protect against mis-matches; note that brass covers and flanges are not interchangeable with aluminum or nonmetallic covers and flanges.
• Easy integration with existing floor box configurations, enabling fast upgrades and renovations with minimal disruption to surrounding flooring and a clean, uniform appearance upon completion.

Technical Details of Wiremold Flange

• Product type: Tile flange for one-gang floor box installations
• Material: Powder-coated aluminum for durability and corrosion resistance
• Dimensions: 4.5" x 3.5" (114 mm x 89 mm)
• Compatibility: For use on 880S1, 880M1, 880CS1-1, and 880M1-1 Floor Boxes
• Flooring compatibility: UL Listed for tile, terrazzo, and carpet floors
• Finish and interchangeability: Brass covers and flanges are not interchangeable with aluminum or nonmetallic covers and flanges

How to Install Wiremold Flange

Installing the Wiremold Flange is straightforward and designed to minimize downtime while delivering a professional, high-quality result. Follow these steps to ensure a secure, flush fit that complements your flooring choice and maintains safe, ADA-compliant pathways where applicable:

• Prepare the site: Verify that your floor box model (880S1, 880M1, 880CS1-1, or 880M1-1) is compatible with the aluminum tile flange. Ensure the flooring material is installed to the manufacturer’s specifications and that the subfloor is stable and clean.
• Turn off power: For any electrical work, ensure the circuit is de-energized and follow all applicable safety protocols before handling the floor box and flange components.
• Position the flange: Align the 4.5" x 3.5" flange precisely over the floor opening and ensure the mounting holes on the flange align with the floor box or mounting surface. The flange should sit flat against the subfloor or tile backing to prevent any gaps.
• Secure the flange: Use appropriate fasteners recommended by the floor box manufacturer to secure the flange to the mounting surface. Tighten screws until flush with the flange surface, taking care not to over-tighten and distort the finish.
• Finish surface around the flange: If tile or terrazzo is being installed, route or trim the surrounding material to create a seamless transition with the flange edge. For carpet installations, ensure the carpet edge is flush and does not overlap the flange to maintain a clean line.
• Inspect and test: Reconnect power and test the floor box operation, ensuring the flange remains firmly in place and that there is no movement or damage to the surrounding flooring. Confirm that the installed flange provides a flush, professional appearance and meets any local code requirements.

Frequently asked questions

• What floors are supported by the Wiremold Flange? The flange is UL Listed for tile, terrazzo, and carpet floors, making it suitable for a wide range of common commercial and residential flooring installations.
• Which floor boxes does this flange fit? It is designed for use with the 880S1, 880M1, 880CS1-1, and 880M1-1 Floor Boxes, providing a reliable, flush finish when paired with these models.
• Are brass covers compatible with aluminum flanges? Brass covers and flanges are not interchangeable with aluminum or nonmetallic covers and flanges, so select the correct finish to ensure proper fit and performance.
• What are the exact dimensions of the flange? The flange measures 4.5 inches by 3.5 inches (114 mm x 89 mm), designed to match standard floor box openings for a clean, professional look.
• Is this flange suitable for new construction and renovations? Yes. Its sturdy aluminum construction and tile-friendly profile make it appropriate for new builds and retrofit projects alike, enabling a fast, dependable upgrade to floor box installations with minimal disruption to surrounding flooring.
