Wiremold S4000 Internal Elbow Fitting

WiremoldSKU: 7101559

Price:
Sale price$130.27

Description

Wiremold S4000 Internal Elbow Fitting

The Wiremold S4000 Internal Elbow Fitting is a precision-engineered steel elbow designed to deliver clean, reliable 90-degree turns inside the Wiremold S4000 Raceway System. Built for durability and ease of installation, this internal elbow creates smooth interior corners without the need for additional couplings, reducing parts, installation time, and potential points of failure. Ideal for commercial and residential applications alike, it helps you achieve a neat, professional finish with concealed wiring that meets industry standards.

  • Durable steel construction built to withstand everyday use in commercial and residential environments, offering long-term performance and reliable electrical routing inside the S4000 system.
  • 90-degree internal elbow design that provides seamless interior corners, eliminating the need for couplings and minimizing clutter along the run for a cleaner, more professional appearance.
  • Specifically engineered for Wiremold S4000 Raceway System compatibility, ensuring a tight fit and consistent alignment with existing channels, covers, and accessories.
  • Smooth interior surface reduces wire snagging and supports safe, efficient cable management, aiding compliance with electrical codes and reducing the risk of damage during installation.
  • Simple installation with an integrated fit that helps contractors and DIY enthusiasts save time and labor. No extra parts or complicated assembly required beyond the elbow itself.

Technical Details of Wiremold S4000 Internal Elbow Fitting

  • Product type: Internal elbow fitting for the Wiremold S4000 Raceway System
  • Material: Steel
  • Finish: Electro-galvanized steel finish (typical for corrosion resistance and durability)
  • Angle: 90-degree interior elbow
  • Couplings: No couplings required for the elbow itself; designed for use within the S4000 channel network
  • System compatibility: Specifically designed for the Wiremold S4000 Raceway System
  • Application: Indoor, dry-location use within exposed or semi-exposed raceway runs

How to install Wiremold S4000 Internal Elbow Fitting

  • Plan the run and verify that the S4000 channel sections are clean and ready for a new elbow at the desired corner location.
  • Turn off power to the area and confirm there is no live wiring in the installation zone before beginning work.
  • Position the elbow inside the S4000 channel, aligning the internal corner with the planned turn. Ensure the elbow seats fully into the channel and sits flush with adjacent sections.
  • Secure the elbow as required by your specific S4000 configuration. This may involve snap-fit engagement with accompanying fittings or light fastening to maintain alignment during cable installation.
  • Install any covers or additional channel components to complete the concealed run, verify alignment across the run, and then proceed with wiring. If necessary, trim or adjust adjacent sections to ensure a clean, continuous path for cables.

Frequently asked questions

  • What is the Wiremold S4000 Internal Elbow Fitting used for? It provides a precise 90-degree interior corner inside the Wiremold S4000 Raceway System, enabling clean, concealed wiring runs without the need for additional couplings.
  • Do I need couplings with this elbow? No. This elbow is designed to create internal corners without requiring separate couplings, simplifying installation and reducing part count.
  • What material is the elbow made of? The elbow is constructed from steel, offering durability and strength for long-term use in both commercial and residential settings.
  • Is it compatible with other Wiremold series? This elbow is specifically designed for the Wiremold S4000 Raceway System. For other series, verify compatibility with their respective fittings and channel profiles.
  • How long does installation take? Installations are typically quick for professionals familiar with the S4000 system. The internal elbow reduces the number of fittings required and can expedite corner transitions, especially on longer runs or tighter indoor spaces.
